Alesis HD24 Service Manual page 86

9-79-0233 0-16-8251 RES 8.25K OHM 1/10W 1% 0805
9-79-0233 1-08-0222 CAP 22uF ELEC 16V 20% 1.5x4x7mm
9-79-0233 1-55-0561 CAP 560pF NPO 0805
9-79-0233 1-56-0104 CAP 0.1uF X7R 0805 10% 50V
9-79-0233 1-56-0151 CAP 150pF NPO 0805
9-79-0233 2-11-7805 REG VOLTAGE LM7805C +5V TO-220
9-79-0233 2-71-3079 IC MC33079 QUAD-OP-AMP SOP-14
9-79-0233 2-75-1201 IC CONVERTER D/A 24-BIT AL1201 SOP-16
9-79-0233 4-02-0902 JACK 1/4" STEREO DUAL STACKED 180ø W/GRND LUG
9-79-0233 4-14-2601 HEADER DIL 26-PIN 0.1" MALE
SCREW 4-40 x 3/8" PPZ
9-79-0233 5-00-0021
WASHER FLAT #4 ZINC 0.25"OD
9-79-0233 5-01-0029
9-79-0233 5-02-4402 NUT HEX 4-40
9-79-0233 5-04-0007 WASHER #4 SPLITLOCK
9-79-0233 9-40-0233-A PCB D/A RL - REV A
RL 9-79-BD01 ASSY PCB POWER SUPPLY RL
9-79-BD01 0-00-0689 RES 6.8 OHM 1/8W 5%
9-79-BD01 0-01-1000 RES 100 OHM 1/8W 1%
9-79-BD01 0-01-1002 RES 10.0K OHM 1/8W 1%
9-79-BD01 0-01-1003 RES 100K OHM 1/8 1%
9-79-BD01 0-01-1022 RES 10.2K OHM 1/8W 1%
RES 150K OHM 1/8W 1%
9-79-BD01 0-01-1503
RES 200 OHM 1/8W 1%
9-79-BD01 0-01-2000
9-79-BD01 0-01-2491 RES 2.49K OHM 1/8W 1%
9-79-BD01 0-01-3652 RES 36.5K OHM 1/8W 1%
9-79-BD01 0-05-0362 RES 3.6K OHM 1/2W 5%
9-79-BD01 0-05-2513 RES 51K OHM 2W 5%
9-79-BD01 0-05-2621 RES 620 OHM 2W 5%
Confidential
Alesis ADAT HD-24 (RL)
BOM
R1 R7 R18 R20-21 R24 R35 R40-41 R47 R58 R60-61 R64 R75 R80-81
R87 R98 R100-101 R104 R115 R120-121 R127 R138 R140-141 R144
R155 R160 R162 R168 R179 R181-182 R185 R196 R201-202 R206
48 R219 R221 R223 R226 R237 R241
C1 C7 C12-13 C15 C19 C22 C25 C29 C35 C40-41 C43 C47 C50 C53
C59 C61 C67 C72-73 C75 C79 C82 C85 C89 C95 C100-101 C103
C107 C110 C113 C117 C121 C127 C132-133 C135 C139 C142 C145
50 C150 C155 C157 C160 C164 C169 C172 C174
C2-3 C5 C8 C21 C23 C27-28 C30-31 C33 C36 C49 C51 C55-56 C62-
63 C65 C68 C81 C83 C87-88 C90-91 C93 C96 C109 C111 C115-116
C122-123 C125 C128 C141 C143 C147-149 C151-152 C162-163 C166
48 C173 C176
C4 C14 C16 C26 C32 C42 C44 C54 C57-58 C60 C64 C74 C76 C86
C92 C102 C104 C114 C118-120 C124 C134 C136 C146 C153 C161
30 C165 C175
C6 C9-11 C17-18 C20 C24 C34 C37-39 C45-46 C48 C52 C66 C69-71
C77-78 C80 C84 C94 C97-99 C105-106 C108 C112 C126 C129-131
48 C137-138 C140 C144 C154 C156 C158-159 C167-168 C170-171
2 U7 U14
6 U2 U5 U9 U12 U16 U19
12 U1 U3-4 U6 U8 U10-11 U13 U15 U17-18 U20
12 J1-12
1 J13
INSTALL WITH U7 U14
2
INSTALL WITH U7 U14
2
2 INSTALL WITH U7 U14
2 INSTALL WITH U7 U14
1
1
1 R3
1 R9
3 R8 R13-14
1 R10
1 R6
R1-2
2
R4 R16
2
1 R7
1 R11
1 R12
1 R5
1 R15
Alesis Service Manual
05-16-02
8-31-0092-B
