Chapter 9. MEMORY CARD OPERATION

9-5 Error Message List

When an error occurs, error messages such as "
message panel during memory card operations. The table below lists the error codes and explain their meaning.
Memory card operations are aborted when an error occurs.
To return to the normal display mode, press the DISP key.
Code
Card insertion failure or card removed
1
Card write protect
2
Card read protect
3
Bad card
4
Invalid card format
5
Card full
6
Card busy
7
File write protect
8
Card access error
9
Card access sequence error
11
FAT abnormal
12
Card access sequence error
14
(in file control)
Card battery voltage drop (warning) Replace the card, replace the card battery (If
15
Wrong file version
16
Data or file are missing.
17
DCP551 data full (program load)
18
DCP551 hardware error (load error)
19
Card data invalid
20
Card data check sum error
21
(program data)
Card data check sum error
22 to 36
(parameter data)
Memory protect error
37
(loading the data is protected by the
variable parameter
No alternate areas remain on the
43
EEPROM card
Error occurred in writing to alternate
44
area on EEPROM card
Card battery voltage drop (error)
63
File abnormal (card was removed) Create new file, and create new data.
64
9-12
Card Error-XX
Meaning
PA02
.)
" (XX denotes error code) are displayed on the
Remedial measures
Do over.
Replace the card, or reset the protect by SLP550.
Replace the card, or reset the protect by SLP550.
Replace the card.
Initialize the card.
Erase unnecessary files, or initialize the card.
Do over.
Initialize the card.
Do over.
Do over.
Initialize the card.
Do over.
replaceable).
Create new file, and create new data.
Create new file, and create new data.
Delete unnecessary programs in the DCP551.
Do over.
Do over.
Operate the instrument again, or check
the program setting of the DCP551.
Operate the instrument again, or check
the parameter setting of the DCP551.
Set DCP551 variable parameter
cancel protection.
Replace the card.
Replace the card.
Replace the card, replace the card battery (If
replaceable).
PA02
