Summary of Contents for TCP Smart TBUWTRVZIG
- Page 1 GB. TCP Smart Instructions Radiator Valve & Hub - Quick Start Guide TCP hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC and 2011/65/EU.
- Page 3 Thank you for purchasing this TCP Smart Radiator Valve and Hub. This is a quick start guide to install and get your device connected to our App and your home network. Before you get started you will need the following: •...
- Page 4 LCD display screen. It can be used individually and can be added to the TCP Smart App to make it an intelligent thermostat. After joining the TCP Smart system, you can select the mode, set the temperature, set the child lock and set the window detection function inside the TCP Smart App.
- Page 5 TCP Smart Radiator Valve 1. LCD Screen 2. Twist ring a. Press: Setting mode b. Rotate: Adjusting temperature 3. LED 4. Interface nut LCD Screen 1. Fault 2. Low battery 3. Temperature you set 4. Window detection 5. Automatic mode 6.
- Page 6 1. Twist the bottom of the 2. Insert 2x AA batteries. Radiator Valve towards (Note that rechargeable the unlock symbol and batteries cannot be used). pull the outer case off to reveal the battery holder. 3. Once the batteries 4. Replace the outer case have been installed the and twist towards the lock LCD screen will light...
- Page 7 7. Attach the Radiator 8. Press down on the LCD Valve to your radiator by screen once and F2 will screwing to the top of the appear on the screen. valve and tighten the nut until it is secure. 9. After about 10 seconds, The Radiator Valve will the wrench symbol close the valve at a...
- Page 8 10. The Radiator Valve is 11 Once the app has now ready to connect to downloaded select the TCP Smart App. Register from the opening screen. You will then be Download the TCP Smart presented with a Privacy App from the Apple App Policy.
- Page 9 12 On the registration 13 You have 60 seconds page, at the top you to enter the verification can choose to register code which would have with either your email or been sent to your email or mobile number. mobile phone. Once you have entered If this time expires go back your details press the...
- Page 10 14 Set a Password. This 15 Create a family for password must contain your devices, this can be 6-20 characters, and anything you wish. You include a combination of can select rooms you wish letters and numbers. to have in your family. Once entered press You can also enable your complete.
- Page 11 17 You can choose from a the app is now ready to list of different products. add your Smart devices. As the TCP Smart Hub Do this by either pressing runs on Zigbee ®, select the + button in the top WiFi Zigbee ®...
- Page 12 18 Plug the Smart Hub 19 Choose your WiFi into the power. The Hub network & enter your should start to flash password. rapidly. If you are unsure of your If the light on the Hub details please check with does not flash quickly, your broadband provider.
- Page 13 20 The connection 21 Your Smart Hub is process will start, once now connected and can the App finds the device be renamed to suit your it will stop blinking and needs. the connection wheel will reach 100%. (If this does not happen please see trouble shooting).
- Page 14 22 The TCP Smart Hub is 23 Click “Add sub device”. now ready to use. Follow the next steps to link your Radiator Valves to the Hub.
- Page 15 24 Check that the 25 Press down on the Radiator Valve is in LCD screen 3 times to pairing mode. If not follow start the pairing process. the next step to start it.
- Page 16 26 The TCP Smart App 27 Once found the will start searching for Radiator Valves will start any Radiator Valves. connecting.
- Page 17 28 Your Radiator Valve is now connected and can be renamed to suit your needs. This stage is important if in the future you wish to connect to a Smart Home Assistant such as Amazon Alexa or Google Home.
- Page 18 21˚ C when you different modes. are at home, 17˚ C when you are sleeping, and 15˚ In the TCP Smart App to C when you are away select the mode press from home. the “mode” button at the bottom of the screen.
- Page 19 Manual mode Eco mode The temperature you set Anti freezing mode can be will not change because used when you are away of different situations. for long periods of time. The temperature can The temperature can be be set within the App set between 5˚...
- Page 20 Settings - Child lock Settings - Week program You can turn child lock You can set a weekly on in the settings tab schedules in the settings or manually by holding tab. down the LCD screen for 3 seconds. When the child lock function enables, all operations on the thermostat will...
- Page 21 Common trouble shooting: No WiFi connection during the connection process If your Smart Hub will not connect please ensure your router is set to 2.4 GHz your WiFi connection is working correctly and your details are correctly. Try resetting your router and if you have WiFi booster devices make sure they are turned off.
- Page 22 App can’t control the Radiator Valve The Radiator Valve is not connected to the App. Reference step 23. App can’t control the Radiator Valve The Radiator Valve is too far away from the Hub , or there are multiple obstacles in the middle. Move the Smart Hub closer to the Radiator Valves.
- Page 24 Fit. Connect. Play! www.tcpsmart.eu...
