5-Ton Dual-Wedge Log Splitter
model number 060-3895-8
Please read and understand this manual before beginning
any use or assembly of the product, and make sure all
parts are present.
Questions?
If you have any questions or need replacement parts,
please call our toll-free helpline at 1-866-523-5218.
Instruction
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 060-3895-8 and is the answer not in the manual?

Questions and answers

Related Manuals for Yardworks 060-3895-8

Summary of Contents for Yardworks 060-3895-8

  • Page 1 5-Ton Dual-Wedge Log Splitter model number 060-3895-8 Please read and understand this manual before beginning any use or assembly of the product, and make sure all parts are present. Instruction Questions? Manual If you have any questions or need replacement parts,...
  • Page 2 060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 Specifications Product Name 5-Ton Dual-Wedge Log Splitter Model Number 060-3895-8 Important Safety Instructions Motor 120 V 60 Hz 15 A 1 3/4 HP Symbols Log Capacity 10"...

  • Page 3: Personal Safety

    060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 IMPORTANT! READ AND UNDERSTAND power supply when it is not in use, and • Do not operate the log splitter in dangerous for help in freeing a jammed log.
  • Page 4 060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 Item Description Symbol Name Designation/Explanation Symbol Name Designation/Explanation Lever Mount Nut User must read and Always pay attention to Avoid Read the understand the instruction the movement of the log...
  • Page 5 060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 Item Description Item Description Seal Nut plug Flat Washer Groupware M18 Screw Valve Sleeve Motor O-Ring 12.5 x 1.8 Adjusting Screw Block Turn Steel Ball Shroud...
  • Page 6 060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 Item Description Log pusher Work table Wedge Support leg Log retaining plates Motor Pushbutton box Pushbutton switch Wheels (for minor moving only) Hydraulic control lever Control lever guard...

  • Page 7: Unpacking Instructions

    060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 TOOLS NEEDED FOR ASSEMBLY (NOT SUPPLIED): NOTE: The safe use of this product requires an understanding of the information on the product and this operator’s manual as well as knowledge of the project you are attempting.

  • Page 8: Electrical Requirements

    060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 ELECTRICAL REQUIREMENTS CAUTION! To avoid possible electric shock, switch off the power supply • Use a standard 120 V (±10%) 60 Hz (±1 Hz) AC only electrical supply that has under-...

  • Page 9: Check The Oil

    060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 Bleed screw 2. LOOSEN THE BLEED SCREW CAUTION! • Turn the bleed screw 3 full turns. • Leave the bleed screw in a vertical position aligned behind the wedge or in a horizontal •...
  • Page 10 060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 WARNING! Do not crouch on the ground, sit down on a log beside the WARNING! splitter, or kneel down by the log splitter (fig. 5). Always keep your hands and body out of the splitting or operating zone while using the log splitter.

  • Page 11: Replacing The Hydraulic Oil

    060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 f. Stop the log splitter by simultaneously WARNING! To avoid possible electric shock, always disconnect the releasing the hydraulic control lever and log splitter from the power supply and tighten the bleed screw before the switch (fig.

  • Page 12: Sharpening The Blade

    060-3895-8 | contact us 1.866.523.5218 model no. 060-3895-8 | contact us 1.866.523.5218 • Wipe the dipstick clean and insert it back into the oil tank to check for the oil level. SHARPENING THE BLADE • Remove the dipstick and check for oil level. The level of the refilled oil should be between After using the log splitter for some time, sharpen the blade or wedge using a fine-toothed the 2 grooves of the dipstick.

  • Page 13: Warranty

    Check the oil level, and refill the Not enough hydraulic oil and too For TWO YEARS from the date of purchase within Canada, YARDWORKS CANADA will, at its unfamiliar oil if necessary. If the problem much air in the hydraulic system.
  • Page 14 Imported by YardWorks Canada Toronto, Canada M4S 2B8...
