Maintenance
Fuse Box Locations
The fuse boxes are located beneath the
rider's seat. To allow access to the fuse
boxes, the passenger seat and then
the rider's seat must be removed (see
page 85 and page 86).
1. Fuse box 1–all models
2. Fuse box 2–all models
3. Fuse box 3–Tiger 900 GT Pro only
Note
The starter solenoid has an additional
30 Amp fuse, attached directly to the
solenoid under the battery, beneath the
rider's seat.

Fuse Identification

Tiger 850 Sport
The fuse identification numbers listed
in the tables correspond with those
printed on the fuse box covers, as
shown below.
164
3 2
1
Fuse Box 1
1 2 3
7 8
25A ABS
7
Position Circuit Protected
Chassis Control Unit, Cooling
Fan (Right Hand Side), Horn,
1
License Plate Light, Rear
Position Light
Chassis Control Unit, Brake
Light, Dip Beam Headlight,
2
Instrument Wake, Front Turn
Signals, Heated Grips
Chassis Control Unit, High
Beam Headlight, Rear Turn
3
Signals, USB Charger, Front
Position Light Power
Chassis Control Unit,
4
Passenger Accessory Socket
Chassis Control Unit, Cooling
5 Fan (Left Hand Side), Starter
Motor Solenoid, Fuel Pump
6 Engine Management System
7 ABS
8 Ignition Switch
Diagnostics Connector (OBDII),
9
Alarm
Fuse Box 2
Position Circuit Protected
1 Rider Accessory Socket
4 5 6
9
5A
5A OBDII
8 9
Rating
(Amps)
10
10
10
10
20
25
Rating
(Amps)
10
15
5
5
