Operating Instructions (EN)
Scan With Phone for more Information
Read these Instructions before
using the machine.
Read these Safety Messages
before using the machine.
V18.234
TC-CARBON-OP-EN
Advertisement
Table of Contents
Related Manuals for Tomcat CARBON 26'' Disk
Summary of Contents for Tomcat CARBON 26'' Disk
- Page 1 Operating Instructions (EN) Read these Instructions before using the machine. Read these Safety Messages before using the machine. Scan With Phone for more Information www.tomcatequip.com 1711 South Street Racine, WI 53404 (USA) (800) 450-9824 | (+001) 262-681-6470 V18.234 © 2018 RPS Corporation TC-CARBON-OP-EN...
-
Page 2: Introduction
INTRODUCTION This manual is furnished with each new machine. This manual will allow the Operator to get the best performance out of your RPS manufactured Scrubber-Drier, Sweeper, Burnisher, or Orbital Scrubber. Read this manual thoroughly before operating or servicing the machine. This machine will provide excellent performance, but the best results will be obtained at the most minimum costs if: •... -
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Fill Solution Tank Locate Serial Number Operation - Scrubbing Table Of Contents Draining Recovery Tank Safety Messages Draining Solution Tank Safety Labels Flushing Recovery Tank LCD Screen Clean Drain Saver Operation Controls Clean Cylindrical Hopper Touch Screen (Optional) Clean Vac Box System Touch Screen Symbols (Optional) Remove Disk Brushes... -
Page 4: Safety Messages
SAFETY MESSAGES You will see four kinds of safety reminders in this manual: DANGER WARNING DANGER indicates a hazardous situation which, if not WARNING indicates a potentially hazardous situation avoided, will result in death or serious injury. which, if not avoided, could result in death or serious injury. NOTICE CAUTION NOTICE indicates information considered important, but... - Page 5 WARNING WARNING The Batteries in this machine produce hazardous Dress safely. Do not wear rings or metal wrist watches voltage which can cause electrical shock, burns and/ when servicing this machine, as they can cause an or electrocution. Always disconnect Batteries before electrical short circuit which can cause serious burns.
-
Page 6: Safety Labels
DANGER SAFETY LABELS Read and obey all Safety Labels on your CARBON Floor Scrubber. If you have questions about these labels, ask your supervisor. These images indicate where on the CARBON Safety Labels are located. If ever the labels become illegible, worn off, or torn, promptly report it to your supervisor and replace it. -
Page 7: Lcd Screen
LCD SCREEN SCREEN #1 (OPERATOR) SCREEN #2 (MAINTENANCE) SCREEN #3 (WITH ERROR CODE) ** USE GREEN MENU SELECTION BUTTON ON CONTROL PANEL TO CHANGE SCREENS ** 1. BATTERY LEVEL INDICATOR - Indicates the energy level remaining in the Batteries (Shown on all menu displays) 2. -
Page 8: Operation Controls
OPERATION CONTROLS - 8 - TC-CARBON-OP-EN... -
Page 9: Touch Screen (Optional)
#1 NAME TOUCH SCREEN (OPTIONAL) SUDS SUDS SUDS SUDS 24.9 22.5 34.2 1. SOLUTION OUTPUT - Indicates the level of solution that is being dispensed when in operation 2. TECHNICAL / MANAGER SETUP - Access ‘Error Code History’ and Manager Programming 3. -
Page 10: Touch Screen Symbols (Optional)
#1 NAME TOUCH SCREEN SYMBOLS (OPTIONAL) SUDS SUDS Mode Selection Transport Only Single Scrub Double Scrub Vacuum Only Solution Setting Down Pressure Setting Transport Motor Scrub Deck Motor(s) Working Active Inactive Working Active Inactive Solution Pump Vacuum Motor Working Active Inactive Working Active... -
Page 11: Touch Screen Zone Operation (Optional)
#1 NAME TOUCH SCREEN ZONE OPERATION (OPTIONAL) SUDS SUDS The touch screen is designed to be programmed to three specifi c zones. Each zone can be named and custom programmed or even disabled if not needed. #1 NAME The zone you are working in is highlighted as indication. In Figure 1. the zone selected is Zone 1. -
Page 12: Touch Screen Zone Progamming (Optional)
#1 NAME TOUCH SCREEN ZONE PROGAMMING (OPTIONAL) SUDS SUDS To program the Zones, go to the Setup page by clicking on the Setup wrench and gear icon to the left of the Zone number buttons. #1 NAME SUDS SUDS From here you will be prompted with a passcode screen. Enter the manager passcode to get access to setup. -
Page 13: Battery Setup
BATTERY SETUP NOTICE Batteries are a possible environmental hazard. Consult your Battery supplier for safe disposal methods. NOTICE Orientation of Batteries is critical for cables to reach. Ensure proper torque values when installing batteries. (Between 8 - 12 ft/lbs) 24 VOLTS TC-CARBON-OP-EN - 13 -... -
Page 14: Remove Squeegee
REMOVE SQUEEGEE - 14 - TC-CARBON-OP-EN... -
Page 15: Adjust Squeegee
ADJUST SQUEEGEE TC-CARBON-OP-EN - 15 -... -
Page 16: Remove From Battery Charger
REMOVE FROM BATTERY CHARGER Please refer to OEM Charger Operating Instructions for more information. - 16 - TC-CARBON-OP-EN... -
Page 17: Transportation - Forward
TRANSPORTATION - FORWARD ½ SPEED TC-CARBON-OP-EN - 17 -... -
Page 18: Transportation - Reverse
TRANSPORTATION - REVERSE - 18 - TC-CARBON-OP-EN... -
Page 19: Fill Solution Tank
FILL SOLUTION TANK < 21 Gal. ( 79.5 l ) < 21 Gal. ( 79.5 l ) < 130°F / 54°C < 130°F / 54°C DANGER CAUTION EXPLOSION RISK! Flammable materials can cause an TO AVOID DAMAGE TO THIS MACHINE: •... -
Page 20: Operation - Scrubbing
OPERATION - SCRUBBING ½ SPEED - 20 - TC-CARBON-OP-EN... -
Page 21: Draining Recovery Tank
WASTE WATER DRAINS ONLY! DRAINING RECOVERY TANK WASTE WATER DRAINS ONLY! TC-CARBON-OP-EN - 21 -... -
Page 22: Draining Solution Tank
WASTE WATER DRAINS ONLY! DRAINING SOLUTION TANK WASTE WATER DRAINS ONLY! - 22 - TC-CARBON-OP-EN... -
Page 23: Flushing Recovery Tank
FLUSHING RECOVERY TANK TC-CARBON-OP-EN - 23 -... -
Page 24: Clean Drain Saver
CLEAN DRAIN SAVER - 24 - TC-CARBON-OP-EN... -
Page 25: Clean Cylindrical Hopper
CLEAN CYLINDRICAL HOPPER TC-CARBON-OP-EN - 25 -... -
Page 26: Clean Vac Box System
CLEAN VAC BOX SYSTEM - 26 - TC-CARBON-OP-EN... -
Page 27: Remove Disk Brushes
REMOVE DISK BRUSHES Rotate after 25 hrs TC-CARBON-OP-EN - 27 -... -
Page 28: Remove Cylindrical Brushes
REMOVE CYLINDRICAL BRUSHES Rotate after 25 hrs - 28 - TC-CARBON-OP-EN... -
Page 29: Remove Edge Pads
REMOVE EDGE PADS Grip Face Spacer Prep Pad Never place Prep Pad directly on Grip Face! TC-CARBON-OP-EN - 29 -... -
Page 30: Charge Batteries
CHARGE BATTERIES Please refer to OEM Charger Operating Instructions for more information. - 30 - TC-CARBON-OP-EN... -
Page 31: Battery Chargers
BATTERY CHARGERS Console / WET / Domestic Chargers: AC Power IN: 120VAC / 60Hz DC Power OUT: 24VDC / 25A Please refer to OEM Charger Operating Instructions for more information. Onboard / AGM / International Chargers: AC Power: 80-270VAC / 50-60Hz DC Power OUT: 24VDC / 27A Please refer to OEM Charger Operating Instructions for more information. -
Page 32: Common Wear Parts
COMMON WEAR PARTS ROUND DISK BRUSHES: ROUND DISK PADS: NOTICE NOTICE The ## in Disk Column Denotes Desk Pad Size: 13'' or The ## in Disk Column Denotes Desk Pad Size: 13'' or 14'' 14'' DISK PADS DISK LEVEL COLOR BRUSHES DISK LEVEL... - Page 33 80 Grit Sand Paper 100 Grit Sand Paper 400 Grit Diamond Polishing Pad EDGE-4013 800 Grit Diamond Polishing Pad EDGE-4014 1500 Grit Diamond Polishing Pad EDGE-4015 3000 Grit Diamond Polishing Pad EDGE-4016 6000 Grit Diamond Polishing Pad EDGE-4070 Tile/Grout Renovator Pad EDGE-4048 Dominator HD Strip Pad EDGE-4055...
-
Page 34: P&G Controller Common Error Codes
P&G CONTROLLER COMMON ERROR CODES Below are common diagnostic codes and some typical causes / remedies. If the information provided in the "Correction" section does not cure the code, seek technical support from your local authorized RPS Corporation distributor. Diagnostic Code Cause Correction 1501 Parking brake is released or the parking brake coil... - Page 35 BLANK THIS PAGE WAS INTENTIONALLY LEFT BLANK...
- Page 36 1711 South Street Racine, WI 53404 www.tomcatequip.com Tel. US: 800-450-9824 Tel. Int: (+001) 262-681-6470 © RPS Corporation 2018...
