WHITE WIRE FROM
NECK PICKUP
BLUE WIRE FROM
NECK PICKUP
YELLOW WIRE FROM
BRIDGE PICKUP
BLUE WIRE FROM
BRIDGE PICKUP
WHITE WIRE FROM
OUTPUT JACK
BLACK WIRE FROM
OUTPUT JACK
BRIDGE ASSEMBLY
20
21
60's TELECASTER
CONTROL ASSEMBLY
22
23
0131600
14
15
12
16
12
Pg. 2 of 4
06-28-2001
Rev. A
