YP18KH38
Operator's Manual
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
581 04 31-26 Rev. 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YP18KH38 and is the answer not in the manual?

Questions and answers

Daniele Panozzo
March 19, 2025

Unable to read mower manual , print is too small to read. Need down load in A4 print size .

User image 67daa21b5ec1b
0

Related Manuals for Yard Pro YP18KH38

Summary of Contents for Yard Pro YP18KH38

  • Page 1 YP18KH38 Operator's Manual WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult in serious in ju ry. Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.

  • Page 2: Safety Rules

    SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. II. GENERAL OPERATION WARNING: In order to prevent ac ci den tal •...
  • Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. SLOPE OPERATION • Never remove gas cap or add fuel with the engine running. • Allow engine to cool before refueling. WARNING! When loading or unloading • Never fuel the machine indoors. this machine, do not exceed the maximum •...

  • Page 4: Table Of Contents

    PRODUCT SPECIFICATIONS CONGRATULATIONS on your purchase of a new tractor. It has been designed, engineered and manu fac tured to give you the best possible dependability and performance. Gasoline Capacity 1.50 Gallons/5,67 L and type: Regular Unleaded Should you experience any problem you cannot easily remedy, please contact your nearest authorized service Power Rating: 13,4 kW@3300 RPM...
  • Page 5 UNASSEMBLED PARTS Steering Wheel (1) Lock Washer Steering (1) Large Wheel Insert Flat Washer Steering Wheel (1) Hex Bolt Steering Steering Wheel Extension Adapter Steering Boot Shaft Seat (1) Bolt (1) Large Flat Washer (1) Seat Battery Keys Slope Sheet Oil Drain Extension (2) Hex Bolts Key(s)

  • Page 6: Assembly

    ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to ensure proper tightness.
  • Page 7 ASSEMBLY NOTE: You may now roll your tractor off the skid. Continue INSTALL SEAT (See Figs. 3 and 4) using the instructions that follow to remove the tractor from • Remove bolt and flat washer se cur ing seat to cardboard the skid.
  • Page 8 ASSEMBLY ✓ CHECKLIST BEFORE YOU OPERATE YOUR NEW TRAC TOR, WE WISH TO ASSURE THAT YOU RECEIVE THE BEST PERFORMANCE AND SATISFACTION FROM THIS QUALITY PRODUCT. PLEASE REVIEW THE FOLLOWING CHECKLIST: ✓ All assembly instructions have been com plet ed. ✓...

  • Page 9: Operation

    OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL HIGH CHOKE FAST SLOW IGNITION SWITCH ENGINE ENGINE ENGINE DIFFERENTIAL CLUTCH/ PARKING MOWER MOWER START LOCK BRAKE PEDAL BRAKE HEIGHT LIFT...
  • Page 10 OPERATION KNOW YOUR TRACTOR READ THIS MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Fig. 5 Our tractors conform to the applicable safety standards of the American National Standards Institute.
  • Page 11 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles.
  • Page 12 OPERATION TO MOVE FORWARD AND BACKWARD TO ADJUST GAUGE WHEELS (See Fig. 11) (See Fig.9) Gauge wheels are properly adjusted when they are slightly off the ground when mower is at the desired cutting height The direction and speed of movement is controlled by the in operating position.
  • Page 13 OPERATION TO OPERATE ON HILLS TO TRANSPORT (See Fig. 14) When push ing or tow ing your trac tor, ensure transmission CAUTION: Do not drive up or down hills is disengaged by placing freewheel control in free wheel ing with slopes greater than 15° and do not po si tion.
  • Page 14 OPERATION ADD GASOLINE TO START ENGINE (See Fig. 5) • Fill fuel tank to bottom of filler neck. Do not overfill. When starting the engine for the first time or if the engine Use fresh, clean, regular gasoline with a minimum of has run out of fuel, it will take extra cranking time to move 87 octane.
  • Page 15 OPERATION MOWING TIPS PURGE TRANSMISSION • DO NOT use tire chains when the mower hous ing is CAUTION: Never engage or disengage free- attached to tractor. wheel lever while the engine is run ning. • Mower should be properly leveled for best mowing performance.

  • Page 16: Maintenance Schedule

    MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris Off Steering Plate ck Transaxle Cooling...

  • Page 17: Maintenance

    MAINTENANCE TRACTOR BLADE CARE Always observe safety rules when per form ing any For best results mower blades must be kept sharp. Re place main te nance. bent or damaged blades. BRAKE OPERATION CAUTION: Use only a replacement blade ap- If tractor requires more than five (5) feet (1,5 m) to stop at proved by the manufacturer of your tractor.
  • Page 18 MAINTENANCE TO CHANGE ENGINE OIL (See Fig. 18 & 19) V-BELTS Determine temperature range expected before oil change. Check V-belts for deterioration and wear after 100 hours All oil must meet API service classification SG-SL. of operation and replace if necessary. The belts are not ad just able.
  • Page 19 MAINTENANCE CLEANING (See Fig. 21) ENGINE COOLING SYSTEM • Clean engine, battery, seat, finish, etc. of all foreign To ensure proper cooling, make sure the grass screen, matter. cooling fins, and other external surfaces of the engine are kept clean at all times. •...
  • Page 20 MAINTENANCE DECK WASHOUT PORT (See Fig. 22) Your tractor’s deck is equipped with a washout port on its surface as part of its deck wash system. It should be utilized after each use. • Drive the tractor to a level, clear spot on your lawn, near enough to a water spigot for your garden hose to reach.

  • Page 21: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •...
  • Page 22 SERVICE AND ADJUSTMENTS • ATTACH MOWER SIDE SUSPENSION ARMS (A) TO • Insert end of link (E) into hole in front mower bracket CHASSIS - Position hole in arm over pin (B) on outside and secure with washer and retainer spring (J). of tractor chassis and secure with retainer spring.
  • Page 23 SERVICE AND ADJUSTMENTS TO LEVEL MOWER FRONT-TO-BACK ADJUSTMENT (See Figs. 31 & 32) IMPORTANT: Deck must be level side-to-side. Make sure tires are properly inflated to the PSI shown on tires. If tires are over or under inflated, it may affect the To obtain the best cutting re sults, the mower blades should appearance of your lawn and lead you to think the mower be adjusted so the front tip is 1/8"...
  • Page 24 SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE DRIVE BELT (See Fig. 33) The mower blade drive belt may be replaced without tools. Park the tractor on level surface. Engage parking brake. BELT REMOVAL - • Remove mower from tractor (See “TO REMOVE MOW ER”...
  • Page 25 SERVICE AND ADJUSTMENTS TO REMOVE WHEEL (See Fig. 35) • Connect one end of the BLACK ca ble to the NEGA TIVE (-) terminal (C) of fully charged battery. • Block up axle securely. • Connect the other end of the BLACK cable (D) to good •...
  • Page 26 SERVICE AND ADJUSTMENTS TRANSMISSION TO REPLACE HEADLIGHT BULB • Raise hood. REMOVAL/RE PLACE MENT • Pull bulb holder out of the hole in the backside of the grill. Should your transmission require removal for service or • Replace bulb in holder and push bulb holder securely re place ment, it should be purged after reinstallation and back into the hole in the backside of the grill.

  • Page 27: Storage

    STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK...

  • Page 28: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4. Bad spark plug. 4.
  • Page 29 TROUBLESHOOTING PROBLEM CAUSE CORRECTION Engine continues to 1. Faulty operator-safety presence control 1. Check wiring, switches and connections. If not system. corrected, contact an authorized service center/ run when operator department. leaves seat with attachment clutch CAUTION: DO NOT operate machine until engaged problem is corrected.

  • Page 31: Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
  • Page 32 05.20.14 BD Printed in the U.S.A.
