- Page 1 Quick Start Guide hybrid...
-
Page 2: What's In The Box
hybrid What’s in the box Stick Video Cable USB Cable Remote Activation Key... - Page 3 Connect a rabbit-ear type, or roof ATSC antenna Connect a rabbit-ear type, ATSC antenna Pull off the grey protective cap and connect EyeTV Hybrid to a free USB 2.0 port on your computer. You can connect the stick directly or via the supplied USB extension.
- Page 4 Connect cable line Connecting a cable line Pull off the grey protective cap and connect EyeTV Hybrid to a free USB 2.0 port on your computer. You can connect the stick directly or via the supplied USB extension. Now connect the socket which carries the signal for the cable connection using a coaxial cable (not included) to the antenna socket of EyeTV Hybrid.
- Page 5 Connect external source via S-VHS Connecting an external video source via S-Video (S-VHS) Pull off the grey protective cap and connect EyeTV Hybrid to a free USB 2.0 port on your computer. You can connect the stick directly or via the supplied USB extension.
- Page 6 Connect external source via RCA Connecting an external composite video source Pull off the grey protective cap and connect EyeTV Hybrid to a free USB 2.0 port on your computer. You can connect the stick directly or via the supplied USB extension.
