Panasonic SA-PT875GA Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's DVD mechanism unit is DLS6. Please refer to the original service manual
(Order No. MD0801003CE) for this mechanism

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 4
1.1. GENERAL GUIDELINES -------------------------------- 4
1.2. Before Use -------------------------------------------------- 4
1.3. Before Repair and Adjustment ------------------------- 4
1.4. Protection Circuitry ---------------------------------------- 6
1.5. Safety Parts Information --------------------------------- 6
1.6. Caution for AC Cord -------------------------------------- 7
2 Warning -------------------------------------------------------------- 8
DVD Home Theater Sound System
Model No.
Product Color: (K)...Black Type
PAGE
2.2. Precaution of Laser Diode -------------------------------9
3 Service Navigation --------------------------------------------- 13
3.1. Service Information -------------------------------------- 13
4 Specifications ---------------------------------------------------- 14
© Panasonic Corporation 2009. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
SA-PT875GA
SA-PT875GC
SA-PT875GS
PSG0903011CE
PAGE
