HT2000W modem specifications

The specifications for the HT2000W modem are listed in
Table 3: HT2000W modem specifications
Item
Weight
Height
Width
Depth
Operating temperature range
Operating humidity range
Altitude
Cooling method
Protocol support
Supported frequency ranges
Network interface ports
Specifications
Specifications
1.071lb (0.486 kg)
7.28 inches (184.92 mm)
2.766 inches (70.26 mm)
5.822 inches (147.88 mm)
41 °F to 104 °F (5 °C to 40 °C)
Above 5,000 ft (1,524 m) altitude, the maximum
temperature is reduced by 1 °C per 1,000 ft (305 m).
5% to 90% non-condensing
Up to 15,000 ft (4,572 m)
Convection
TCP/IP (Transmission Control Protocol / Internet
Protocol) protocol suite
Ka-band or Ku-band
RJ-45 Ethernet LAN port supporting 10BaseT,
100BaseT or 1000BaseT operation
Appendix A ● Specifications
Appendix A
Table 3.
1041264-0001 Revision A
43
