Page 1: Table Of Contents
Welcome...9 Powering Your Computer ...11 Using AC Power...12 Connecting the AC adapter...12 Turning on the computer...13 Using the Battery...15 Inserting a battery ...15 Removing a battery ...16 Using a second battery ...17 Displaying battery information...18 Charging a battery...21 Notes on batteries...23 Frequently asked questions ...23 Conserving Battery Power ...24 Using power saving modes ...24...
Page 2 VAIO Computer Quick Start Connecting Another VAIO Computer ... 50 Connecting VAIO computers... 50 Disconnecting VAIO computers... 52 Frequently asked questions ... 52 CDs, DVDs, and Optical Drives...55 Inserting and Ejecting CDs or DVDs ... 56 Copying and Playing CDs... 59 Playing CDs ...
Page 3 Frequently asked questions ...100 Using the Multilingual User Interface Language Option...102 Changing Numbers, Currency, Time, and Date Formats 103 Changing the Window Design of Sony Programs ..104 Connecting Mice and Keyboards...105 Using External Mice and Keyboards ...106 Connecting a USB mouse or keyboard...106 Connecting a PS/2 mouse or keyboard ...107...
Page 4 VAIO Computer Quick Start Floppy Disk Drives and PC Cards ...111 Using Floppy Disk Drives ... 112 Connecting a floppy disk drive ... 112 Inserting and removing floppy disks... 113 Notes on handling floppy disks... 114 Disconnecting a floppy disk drive ... 115 Carrying the floppy disk drive ...
Page 5 Using Computer Monitors and Projectors...134 Connecting a computer monitor ...134 Connecting a TV ...135 Connecting a projector...139 Selecting a display mode ...140 Disconnecting a computer monitor or projector ...143 Using Speakers, CD Players, or Amplifiers ...144 Connecting standard speakers...144 Disconnecting standard speakers ...145 Connecting active speakers or amplifiers ...145 Disconnecting active speakers or amplifiers ...147 Connecting CD, MiniDisc, or audio cassette players ...147...
Page 6 VAIO Computer Quick Start Program Support Information ... 167 Sony Service Center... 169 Memory Upgrades...171 Upgrading Your Computer’s Memory ... 172 Precautions and procedures... 172 Typical expansion memory configuration ... 173 Removing and installing memory modules ... 173 Confirming added memory capacity... 176 Using the Recovery CDs ...179...
Page 7 Troubleshooting Memory Stick Media ...210 Troubleshooting Programs ...212 Computer Support Information ...213...
Page 8 VAIO Computer Quick Start...
Page 9: Welcome
Welcome Congratulations on your purchase of this Sony VAIO® computer, and welcome to the online VAIO® Computer User Guide. This user guide provides detailed information on all aspects of using your new VAIO computer, from keyboard functions to preinstalled software programs.
Page 10 VAIO Computer Quick Start...
Page 11: Powering Your Computer
Powering Your Computer Your VAIO® computer comes with a battery and an AC adapter. This chapter explains how to install and use these supplied accessories to power your computer. It also describes ways you can efficiently utilize the battery as a power source. ❑...
Page 12: Using Ac Power
VAIO Computer Quick Start Using AC Power The supplied battery is not charged when you receive your computer. To use your computer immediately, use the supplied AC adapter as the power source. While the computer uses AC power, it automatically charges the battery if it is inserted. See “Using the Battery”...
Page 13: Turning On The Computer
Turning on the computer To turn on the computer Slide the release lever to the right, and lift the cover while holding the bottom of the computer firmly. Opening the Computer R e l e a s e l e v e r Press the power button until the power indicator turns on.
Page 14 VAIO Computer Quick Start ❑ To increase brightness, press and release the Fn+F5 keys. Press the Up Arrow key ❑ To decrease brightness, press and release the Fn+F5 keys. Press the Down Arrow key or Right Arrow key or Left Arrow key...
Page 15: Using The Battery
Using the Battery A battery is an auxiliary power source you can use when your computer is not plugged into an AC outlet. Your computer may come equipped with one or two battery bays, depending on the model you purchased. If your computer comes with two battery bays, you can purchase a second rechargeable battery to extend your computing time.
Page 16: Removing A Battery
VAIO Computer Quick Start Slide the battery into the battery bay. If the computer is on, it automatically detects the battery. Inserting a Battery Push the battery bay cover up until it clicks into place. ✍ If the port replicator is attached to your computer, do not insert or remove the battery. Lifting and turning the computer with the port replicator attached could cause a temporary loss of power.
Page 17: Using A Second Battery
Removing a Battery Push in and lift up the battery bay cover until it clicks into place. Using a second battery To insert a second battery If another device is in the multipurpose bay, remove that device. Insert the battery into the multipurpose bay. When the computer uses the second battery, the Battery 2 indicator turns on.
Page 18: Displaying Battery Information
VAIO Computer Quick Start To remove the second battery Make sure the Battery 2 indicator is off and the Battery 1 indicator is on or the computer is connected to AC power. If the Battery 2 indicator is on: Double-click the CPU icon On the Battery tab, click Primary Battery in the Battery Switch box.
Page 19 ✍ If the Battery Information toolbar is hidden behind the taskbar icons, right-click the taskbar and click to cancel Lock the Taskbar. Click and drag the edge of the Battery Information toolbar to the left until it is in clear view. The total charge remaining in the battery is listed in percent and real-time values.
Page 20 VAIO Computer Quick Start Battery Information Window ❑ Power Profile — Displays the power management settings for various devices on your system. You can change the settings to conserve power. ❑ Battery tab — Displays the total charge remaining in the battery. You can click Advanced for specific information on the battery.
Page 21: Charging A Battery
Battery icon Battery status Charging Fully charged Discharging No battery Charging a battery You will need to charge the battery if battery power drops below 10 percent or you have not used the battery for a long time. The lithium-ion battery supplied with your computer may be recharged at any time, whether you wait until the battery is completely or partially discharged.
Page 22 VAIO Computer Quick Start Insert the battery into the battery bay. If you want to charge more than one battery, insert the second battery into the computer. See “To insert a second battery” for more information. Connect the AC adapter to the computer. The computer automatically charges the battery as long as the computer is using AC power.
Page 23: Notes On Batteries
Notes on batteries ❑ Never leave the battery in temperatures above 140°F (60°C), such as under direct sunlight or in a car parked in the sun. ❑ While the battery is in use or being discharged, the battery heats up. This is normal and is not cause for concern.
Page 24: Conserving Battery Power
VAIO Computer Quick Start Conserving Battery Power You may use the power saving modes and PowerPanel™ utility to conserve battery power. Conserving battery power may significantly extend your computing time, depending on how you use your computer. ❑ Using power saving modes ❑...
Page 25: Using The Powerpanel Utility
✍ If the computer does not activate Hibernate mode, see “Frequently asked questions” for more information. Using the PowerPanel utility The PowerPanel™ utility enables you to select and customize a predefined power management profile to conserve battery life. The following table describes all the predefined power management profiles in PowerPanel.
Page 26 VAIO Computer Quick Start Profile Icon Description Presentation Keeps the display on at all times while it conserves power. This option is ideal for slide show presentations. You can establish settings for LCD (Video) Standby, Hard Disk Standby, and Standby mode to optimize power management for your system.
Page 27 To select a profile Right-click the CPU icon Select Profiles, and click the profile on the shortcut menu. The profile settings are implemented instantly. See “Using the PowerPanel utility” for descriptions of available profiles. When you use the battery to power your computer, your system automatically selects the Maximum Battery Life power management profile by default.
Page 28 VAIO Computer Quick Start Power profile Description CPU Control Controls the processor speed. You can select either Performance, Adaptive, Battery Life, or More Battery Life. These selections are listed in order from the greatest to least amount of power consumed. System Standby Controls the time it takes the system to activate the Standby Timer...
Page 29: Frequently Asked Questions
Power profile Description LCD Standby Controls the time it takes the system to switch the computer Timer screen (LCD) to Standby mode when the system is idle. This setting only turns off power to the computer screen. The system itself still functions on full power. HDD Standby Controls the time it takes the system to switch the hard disk Timer...
Page 30 VAIO Computer Quick Start...
Page 31: Internet And Network Connections
Internet and Network Connections ❑ Internet Connections ❑ Network Connections ❑ Connecting Another VAIO Computer...
Page 32: Internet Connections
Internet and choosing an Internet service provider (ISP) or setting up an existing account. When you connect to the Internet, you can register your VAIO® computer, use online services, and gain access to Sony Computing Support.
Page 33 Connecting a Telephone Cable ✍ Your computer does not work with party lines, cannot be connected to a coin-operated telephone, and may not work with multiple telephone lines or a private branch exchange (PBX). Some of these connections may result in excess electrical current and could cause a malfunction in the internal modem.
Page 34: Setting Up An Ethernet Internet Connection
VAIO Computer Quick Start New Connection Wizard Click Next. If the Location Information dialog box appears, follow the on- screen instructions. If it is not already selected, click to select Connect to the Internet, and click Next. Follow the on-screen instructions. Setting up an Ethernet Internet connection Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending...
Page 35 To connect an Ethernet cable Locate the Ethernet port on your computer. For location information, see Locating Ports and Controls in the Setting Up chapter of your printed VAIO® Computer Quick Start. Connecting an Ethernet Cable E t h e r n e t p o r t Plug one end of the Ethernet cable into your computer’s Ethernet port and the other into the network connection.
Page 36: Customizing Your Internet Connection
VAIO Computer Quick Start New Connection Wizard Click Next. If the Location Information dialog box appears, follow the on- screen instructions. If it is not already selected, click to select Connect to the Internet, and click Next. Follow the on-screen instructions. Customizing your Internet connection The Internet Properties dialog box enables you to change the way you view the Internet.
Page 37: Frequently Asked Questions
Make sure the telephone number the program is dialing is correct. ❑ Make sure the software you are using is compatible with the computer’s modem. (All preinstalled Sony programs are compatible.) ❑ If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
Page 38: Network Connections
VAIO Computer Quick Start Network Connections With a Sony computer, you can easily set up or connect to a variety of networks. The New Connection Wizard and Network Setup Wizard make it easy to gain access to remote and local area networks (LANs) using wireless, Ethernet, or dial-up connections.
Page 39 accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending on the Ethernet cable. To set up an Ethernet LAN Plug one end of the Ethernet cable into your computer’s Ethernet port and the other into the network connection.
Page 40 VAIO Computer Quick Start The Network Setup Wizard Click Next. Follow the on-screen instructions. Only connect 10BASE-T and 100BASE-TX cables to the Ethernet port not connect any other type of network cable or any telephone cable. Connecting cables other than those listed above may result in an electric current overload and could cause a malfunction, excessive heat, or fire in the port.
Page 41: Using Wireless Lan Connections
Using wireless LAN connections A wireless local area network (LAN) is a network in which you can connect to a LAN through a wireless (radio) connection. You can opt to purchase a Sony Wireless LAN Access Point to set up a LAN.
Page 42 VAIO Computer Quick Start wireless LAN. The access point coordinates transmission and reception from multiple wireless devices within a specific range. ❑ A computer-to-computer (ad-hoc) network is one in which a local network is created only by the wireless devices themselves, with no other central controller or access point.
Page 43 Connecting to a Wireless LAN Select a network from the Available networks list box. Type the network key of the available network in the Network key box. See your network administrator for this information. Click Connect. To set up a wireless network Insert a Wireless LAN PC Card into the PC Card slot.
Page 44 VAIO Computer Quick Start Setting Wireless Network Connection Properties Type up to 32 ASCII characters in the Network name (SSID) box. Click to select the Data encryption (WEP enabled) check box. Click to select the Network Authentication (Shared mode) check box. Click to cancel the The key is provided for me automatically check box.
Page 45 To set up a computer-to-computer (ad-hoc) network Insert a Wireless LAN PC Card into the PC Card slot. See “Inserting PC Cards” for more information. The Wireless LAN indicator turns on. From the Start menu, click Control Panel, Network and Internet Connections, and then click Network Connections.
Page 46: Checking Your Network Connection Status
VAIO Computer Quick Start Click to select the Network Authentication (Shared mode) check box. Click to cancel the The key is provided for me automatically check box. Type between 5 to 13 ASCII characters or 10 to 26 hexadecimal characters in the Network key box.
Page 47: Frequently Asked Questions
Wireless Network Connection Status Window Frequently asked questions Why can’t my computer connect to a wireless LAN access point? ❑ Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using.
Page 48 VAIO Computer Quick Start Select the Wireless Networks tab, and make sure the access point is displayed in the Available networks box. If it is not displayed, see “To connect to an existing wireless network” for more information. ❑ Make sure the encryption key is correct. Why can’t I access the Internet? ❑...
Page 49 Wireless LAN communication occurs on divided frequency bands known as channels. Third-party wireless LAN access point channels may be preset to different channels from Sony devices. If you are using a wireless LAN access point, refer to connectivity information contained in your access point instructions.
Page 50: Connecting Another Vaio Computer
Click Network and Internet Connections, and click Set up or change your home or small office network. The Network Setup Wizard appears. * i.LINK is a trademark of Sony used to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software programs, operating system, and compatible i.LINK devices.
Page 51 The Network Setup Wizard window Follow the on-screen Network Setup Wizard instructions. When you are prompted, type in a unique computer name for each computer. You will use this unique name to differentiate the two computers once they are networked together. ✍...
Page 52: Disconnecting Vaio Computers
Disconnect the i.LINK cable * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Page 53 Connecting Another VAIO Computer and securely reconnect it to both computers. If neither computer responds after a few moments, restart both computers. ❑ If the computers do not recognize the i.LINK connection after resuming from a power saving mode (Standby or Hibernate), restart both computers. For more information on power saving modes, see “Using power saving modes”.
Page 54 VAIO Computer Quick Start...
Page 55: Cds, Dvds, And Optical Drives
CDs, DVDs, and Optical Drives ❑ Inserting and Ejecting CDs or DVDs ❑ Copying and Playing CDs ❑ Copying and Playing DVDs...
Page 56: Inserting And Ejecting Cds Or Dvds
VAIO Computer Quick Start Inserting and Ejecting CDs or DVDs ✍ Avoid using adhesive labels to identify your CDs or DVDs. Adhesive labels may damage the optical drive if they come off while the disc is in the drive. To insert a CD or DVD Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active.
Page 57 Inserting a Disc D i s c ( l a b e l f a c i n g u p ) Press the disc onto the hub until the disc clicks securely into place. If you do not seat the disc firmly over the hub, the disc may come loose while it is in the drive.
Page 58 VAIO Computer Quick Start Push the drive tray gently to close it.
Page 59: Copying And Playing Cds
Copying and Playing CDs You can use the optical drive installed in your computer to play CDs and copy files to CD-Rs and CD-RWs. ❑ Playing CDs ❑ Copying files to a CD-RW or CD-R Do not remove the optical drive when the computer is in a power saving mode (Standby or Hibernate).
Page 60: Copying Files To A Cd-Rw Or Cd-R
VAIO Computer Quick Start ❑ To decrease volume, press Fn+F4, then ❑ Using the Volume icon. Double click the Volume icon Volume Control dialog box appears. In the Volume Control and CD Audio columns, move the Volume sliders up to increase the volume and down to decrease the volume. To play an audio CD Insert the disc into the optical drive.
Page 61 Click Start, All Programs, and select the program you want to use from the submenu. ❑ For directions on how to use SonicStage and Drag’n Drop CD/DVD software, see the VAIO Multimedia Software Guide. To open this guide, follow these steps: Click Start and Help and Support.
Page 62: Copying And Playing Dvds
VAIO Computer Quick Start Copying and Playing DVDs The type of optical drive installed in your computer may vary, depending on the model you purchased. Computers equipped with a CD-RW/DVD drive can play DVDs and can read most DVD-R media. Computers equipped with a DVD-RW drive can play and copy files to DVDs.
Page 63 To play a DVD on the computer using battery power Set the power management profile to DVD. Close all open programs. Right-click the CPU icon Select Profiles from the shortcut menu, and then select DVD from the submenu. You can also select Automatic Profile Selection, which sets the power management profile to DVD whenever a DVD is inserted into the optical drive.
Page 64 VAIO Computer Quick Start Connecting a TV A / V O U T j a c k Switch the TV input channel to external input. ✍ See the guide that came with your peripheral device for more information on its installation and use.
Page 65: Disconnecting The Tv From The Computer
The Fn+F8 key combination will not work once a DVD is inserted into the optical drive. Switching the display while a DVD is playing may cause the computer to malfunction, and you may need to restart the DVD software. Set the power management profile to DVD, if you are using battery power. Follow these steps: Close all open programs.
Page 66: Copying Files To A Dvd-R Or Dvd-Rw
You can copy files to a DVD-R or DVD-RW if your computer is equipped with a DVD-RW drive. Use the DVD-RW drive and the preinstalled Click to DVD™ or Drag’n Drop CD/DVD program to create your own DVDs. The Sony Click to DVD program is ideal for creating full-featured video DVDs, and the Drag’n Drop CD/DVD program is ideal for creating data DVDs.
Page 67 with water, wring it out well, and use it to wipe the surface of the disc from the center out. Wipe off any remaining moisture with a dry, soft cloth. ❑ Do not clean the disc with solvents (such as benzine, thinner, commercially available cleaners, or anti-static spray), which may damage the disc.
Page 68 VAIO Computer Quick Start Restart the computer by pressing Ctrl+Alt+Delete, and selecting Restart from the Shut Down menu of the Windows Task Manger dialog box. Remove the CD or DVD from the optical drive. Check the disc for dirt or damage. If you need to clean the disc, see “How do I maintain CDs and DVDs?”...
Page 69 ❑ If a region code warning appears, the disc may be incompatible with the optical drive. Check the DVD package to make sure the region code is compatible with the optical drive. ❑ If you notice condensation on the computer, do not use the computer for at least one hour.
Page 70 VAIO Computer Quick Start Right-click the desktop, and select Properties from the shortcut menu. The Display Properties dialog box appears. Select the Settings tab. Move the screen resolution slider to the left to reduce the size and to the right to increase the size of the video resolution.
Page 71: Printer Connections
Printer Connections ❑ Printing With Your Computer...
Page 72: Printing With Your Computer
VAIO Computer Quick Start Printing With Your Computer You can connect a universal serial bus (USB) printer or a parallel port printer to your computer. To print properly, the printer you connect must be compatible with the Microsoft® Windows® operating system installed on your computer. ❑...
Page 73 Connecting a USB Printer P o w e r c o r d ✍ See the guide that came with the USB printer for more information on its installation and use. To connect a parallel port printer Locate the Printer port Plug the printer cable into the Printer port Plug the other end of the printer cable into the port on the printer.
Page 74: Disconnecting A Printer
VAIO Computer Quick Start Connecting a Parallel Port Printer P r i n t e r p a r a l l e l p o r t ✍ See the guide that came with the parallel port printer for more information on its installation and use.
Page 75 Select the Port Settings tab, and select a different LPT Port Number. ❑ You may need to enable the computer’s printer settings. Click Start, and point to All Programs, Sony Notebook Setup, and click Sony Notebook Setup again. Click the Device tab.
Page 76 VAIO Computer Quick Start...
Page 77: Computer Features
Computer Features ❑ Using the Keyboard ❑ Using the Touch Pad ❑ Using the Jog Dial Control ❑ Using Memory Stick Media ❑ Using the Multilingual User Interface Language Option ❑ Changing the Window Design of Sony Programs...
Page 78: Using The Keyboard
VAIO Computer Quick Start Using the Keyboard Your keyboard is very similar to a typewriter’s, but your computer keyboard has additional keys that perform specific computer-related tasks. ❑ Key locations and descriptions ❑ Combinations and functions with the Windows key ❑...
Page 79 Description Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to perform mathematical calculations such as addition and subtraction. Numbers appear on the front beveled edge of the numeric keys. Press the Num Lock key to activate the numeric keypad.
Page 80: Combinations And Functions With The Windows Key
VAIO Computer Quick Start Description Windows key The key with the Microsoft® Windows® operating system logo displays the Start menu; it is the equivalent of clicking Start on the taskbar. See “Combinations and functions with the Windows key” for more information. Fn key The Fn key is used in combination with other keys to issue commands.
Page 81: Indicators
Combination Function Shift + Returns all minimized windows to their previous size. Displays the Run window. This is the equivalent of selecting Run from the Start menu. Fn + + Insert Displays the System Properties window. This is the equivalent of selecting Control Panel, and then System from the Start menu.
Page 82: Combinations And Functions With The Fn Key
VAIO Computer Quick Start Indicator Function Caps Lock Turns on when the letters appear in uppercase as you type. The Shift key lowers the case of typed letters when Caps Lock is on. When the indicator is off, the letters appear in lower case as you type (unless you hold down the Shift key).
Page 83 Combinations/ Feature Function Fn + Toggles between the computer screen (LCD), a connected L C D (F7) external display, and both the LCD and external display. Switch to the external monitor/LCD Select one display at a time to playback DVDs. Connect the cable before you turn on the computer, otherwise Fn+F7 will not work.
Page 84 VAIO Computer Quick Start ✍ You can also carry out these functions using the Jog Dial™ Control. Some functions are not available until the Microsoft® Windows® operating system launches.
Page 85: Using The Touch Pad
Using the Touch Pad The keyboard contains a pointing device called a touch pad. You can point to, select, drag, and scroll objects on the screen using the built-in touch pad. ❑ Describing the touch pad ❑ Customizing the touch pad ❑...
Page 86: Customizing The Touch Pad
Customizing the touch pad Sony Notebook Setup lets you customize your touch pad, such as enable or disable the touch pad. You can also open the Mouse Properties dialog box, which enables you to set your touch pad and mouse preferences, such as changing pointers, enabling or disabling the tapping feature, clicking both buttons simultaneously, and adjusting the touch pad speed.
Page 87: Frequently Asked Questions
Press the Right Arrow key Press the Tab key to select the Default button, and press Enter. A pop-up window appears. Press the Left Arrow key Touchpad option is automatically selected. Press the Tab key to select the Apply button, and press Enter. Click OK.
Page 88 VAIO Computer Quick Start ❑ You may need to use your Application Recovery CD(s) to reinstall the mouse drivers. See “Using the Application Recovery CD(s)” for more information. Why doesn’t the pointer move when I use the touch pad? ❑ Try restarting your computer.
Page 89: Using The Jog Dial Control
Using the Jog Dial Control Your computer is equipped with a Jog Dial™ Control and Jog Dial Navigator software, which enables you to scroll through programs, folders, and documents from a predefined list. The Jog Dial control and Jog Dial Navigator are compatible with preinstalled software programs that support Jog Dial Navigator functions.
Page 90: Using The Jog Dial Navigator Icon
VAIO Computer Quick Start To use the Jog Dial control ❑ Rotate the Jog Dial™ Control to scroll up and down a menu. ❑ Press the Jog Dial control to select a menu item. ❑ Press the Back button (on selected models) to return to the previous menu. ✍...
Page 91: Using Jog Dial Launcher
Features Close button Launcher button Mode button Help button To move, hide, or close the Jog Dial bar ❑ Click and drag the Jog Dial Bar to another location on the desktop. ❑ Click the Close button ❑ Right-click the Jog Dial Bar, and select Hide Jog Dial Bar from the shortcut menu.
Page 92: Using Application And Scroll Modes
Jog Dial Navigator operates in one of two modes: Scroll or Application. Once a program is open, you can easily switch modes. Mode Description Application Enables you to carry out commands for specific Sony programs. Scroll Enables you to scroll through an active window and the Start menu of specific Sony programs.
Page 93 To select Application mode when a program is open ❑ Click APPS on the Jog Dial Bar. When you select Application mode, the Jog Dial Navigator window appears at the lower right side of the program window. The Jog Dial Navigator window appears in either the List Display or Guide Display format, depending on the program.
Page 94: Changing Jog Dial Navigator Settings
VAIO Computer Quick Start No windows appear when you select the Scroll mode. Simply rotate the Jog Dial control and the active window scrolls up and down or side to side if it has a scroll option. To select Scroll mode when a program is open ❑...
Page 95 To change settings Click the Jog Dial Setting button dialog box appears. Jog Dial Setting Dialog Box Click the tabs near the top of the dialog box to view options, and then make your changes. Click Apply, and then click OK. For information about Jog Dial settings, right-click the Jog Dial Navigator icon on the taskbar, and click Help.
Page 96: Using Memory Stick Media
VAIO Computer Quick Start Using Memory Stick Media This compact, portable, and versatile recording medium has a data capacity exceeding that of a floppy disk. The medium is specially designed for exchanging and sharing digital data with compatible products. Because it is removable, the media can be used for external data storage.
Page 97: Inserting Memory Stick Media
✍ MG Memory Stick media has the MG mark. Inserting Memory Stick media Before using Memory Stick® media, back up important data. The media slot accommodates only one Memory Stick media at a time. To insert Memory Stick media Insert the Memory Stick media with the arrow facing up and toward the Memory Stick media slot.
Page 98: Viewing The Contents
Memory Stick media. From this window, you can choose to view, print, copy or organize your Memory Stick images or data. If the Sony Memory Stick window does not appear when you insert your Memory Stick media, then follow these steps: To view the contents From the Start menu, click My Computer.
Page 99: Formatting Memory Stick Media
From the Start menu, click My Computer. The My Computer window appears. Right-click Sony MemoryStick, and click Format from the menu. The Format Sony MemoryStick dialog box appears. Select Quick Format in the Format options box, and then click Start.
Page 100: Frequently Asked Questions
Using recorded music requires permission of the copyright holders. ❑ Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders.
Page 101 ❑ Do not touch the media connector with your finger or metallic objects. ❑ Do not attach labels other than the supplied label to the Memory Stick media. ❑ Do not bend, drop, or apply strong shock to the media. ❑...
Page 102: Using The Multilingual User Interface Language Option
VAIO Computer Quick Start Using the Multilingual User Interface Language Option (Microsoft® Windows® XP Professional only) After you have initially setup your new VAIO® computer, you can change the language displayed in Microsoft® Windows® XP Professional operating system. The multilingual user interface (MUI) language option changes the text controlled by Windows XP Professional operating system.
Page 103: Changing Numbers, Currency, Time, And Date Formats
✍ Additional users can also change to their desired language(s) without affecting your existing language settings. Changing Numbers, Currency, Time, and Date Formats You can change your operating system’s number, currency, time, and date formats to coordinate with your chosen country or language settings. To change these formats Click Start on the Windows taskbar, and then click Control Panel.
Page 104: Changing The Window Design Of Sony Programs
Click << or >> to view the designs. Click Apply to select a design that appears in the center window. The UI Design Selector window design changes. The window design for your Sony software will match the UI Design Selector window.
Page 105: Connecting Mice And Keyboards
Connecting Mice and Keyboards ❑ Using External Mice and Keyboards...
Page 106: Using External Mice And Keyboards
VAIO Computer Quick Start Using External Mice and Keyboards You can connect a universal serial bus (USB) mouse or keyboard to your computer. If you purchased a port replicator, you can also connect a PS/2® mouse or keyboard to the port replicator. To function properly, the device you connect must be compatible with the Microsoft®...
Page 107: Connecting A Ps/2 Mouse Or Keyboard
Connecting a USB Mouse or Keyboard ✍ See the guide that came with your mouse or keyboard for more information on its installation and use. Connecting a PS/2 mouse or keyboard You can connect either an external PS/2® mouse or PS/2 keyboard to the port replicator using a PS/2 plug or adapter.
Page 108: Disconnecting A Mouse Or Keyboard
VAIO Computer Quick Start Plug the mouse or keyboard into this port. The arrow on the connector should face upward. Connecting PS/2 Mouse or Keyboard M o u s e / K e y b o a r d ( P S / 2 ) p o r t Disconnecting a mouse or keyboard You can disconnect a USB or PS/2®...
Page 109: Frequently Asked Questions
Frequently asked questions Why doesn’t the computer recognize the mouse? ❑ Make sure the mouse is securely plugged into the USB or Mouse/Keyboard (PS/2) port. See “Connecting a USB mouse or keyboard” or “Connecting a PS/2 mouse or keyboard” for more information. ❑...
Page 110 VAIO Computer Quick Start...
Page 111: Floppy Disk Drives And Pc Cards
Floppy Disk Drives and PC Cards ❑ Using Floppy Disk Drives ❑ Using PC Cards...
Page 112: Using Floppy Disk Drives
VAIO Computer Quick Start Using Floppy Disk Drives You can connect a floppy disk drive to your computer or port replicator (not supplied). The floppy disk drive enables you to read data stored on a floppy disk. ❑ Connecting a floppy disk drive ❑...
Page 113: Inserting And Removing Floppy Disks
Connecting a Floppy Disk Drive F l o p p y d i s k d r i v e Inserting and removing floppy disks Floppy disks are portable devices that store data. To protect your floppy disks, keep them away from magnets and direct sunlight or other heat sources. To insert a floppy disk Hold the floppy disk with the label facing up.
Page 114: Notes On Handling Floppy Disks
VAIO Computer Quick Start Inserting a Floppy Disk F l o p p y d i s k d r i v e ✍ Do not open the shutter manually and touch the surface of the floppy disk. To remove a floppy disk Close all programs that were opened from the disk and wait for the LED indicator to turn off.
Page 115: Disconnecting A Floppy Disk Drive
Disconnecting a floppy disk drive You can disconnect a floppy disk drive when the computer is on or off. Disconnecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a floppy disk drive Close any active programs to prevent data loss.
Page 116: Frequently Asked Questions
VAIO Computer Quick Start Frequently asked questions Why doesn’t the Safety Remove Hardware icon the drive is connected? The computer does not recognize the floppy disk drive. First, make sure the USB cable is properly connected to the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive.
Page 117: Using Pc Cards
You can use Sony Notebook Setup to disable devices. To open Sony Notebook Setup Click Start on the Windows taskbar, and then click All Programs. Point to Sony Notebook Setup, and click Sony Notebook Setup. The Sony Notebook Setup dialog box appears. To insert a PC Card Make sure the front label of the PC Card is facing up.
Page 118: Removing Pc Cards
VAIO Computer Quick Start Do not force a PC Card into the slot. It may damage the connector pins. When a PC Card is inserted, do not place your computer in a bag or case. Pressure or shock to a PC Card may damage your computer. Touching the head of the PC Card will not damage the connector pins, but damage may occur if the head of the PC Card is sticking out of the PC Card slot while the computer is being transported.
Page 119: Connecting And Disconnecting Pc Card Drives
The PC Card drive enables you to read data stored on a DVD or CD. Your computer may come with an external PC Card drive, depending on the model you purchased. If you wish to purchase an optional PC Card drive, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 120 VAIO Computer Quick Start Remove the PC Card from the bottom of the optical drive. Removing a PC Card Insert the PC Card into the PC Card slot with the arrow facing the slot. See “To insert a PC Card” for more information. Connecting a PC Card drive ✍...
Page 121: Frequently Asked Questions
Make sure the PC Card is compatible with the Microsoft® Windows® operating system installed on your computer. ❑ Use the Sony Notebook Setup utility to disable devices you are not currently using. See “To open Sony Notebook Setup” for more information. ❑...
Page 122 VAIO Computer Quick Start ❑ You may not be able to use some PC Cards or some functions of the PC Card with this computer. Check the guide that came with your PC Card for more information on its use. Why does an exclamation mark (!) appear on the Device Manager tab in the System Properties dialog box? You may not be using the most recent driver software provided by the PC Card...
Page 123: Connecting A Port Replicator
Connecting a Port Replicator ❑ Locating Ports and Connectors ❑ Using the Port Replicator...
Page 124: Locating Ports And Connectors
VAIO Computer Quick Start Locating Ports and Connectors You can purchase a port replicator to use with the computer you purchased. The port replicator contains several ports and connectors, which enable you to connect additional peripherals to your computer. Back USB ports LINE IN jacks S Video Out jack...
Page 125: Using The Port Replicator
Using the Port Replicator Connecting the port replicator You must use the AC adapter to power the computer when it is connected to the port replicator. However, you can insert the battery to charge it while you are using the AC adapter to power the port replicator. Make sure you insert the battery before you connect the port replicator.
Page 126: Removing The Port Replicator
VAIO Computer Quick Start Align the connector on the bottom of the computer with the port replicator connector, and push the computer down until it clicks into place. Attaching the Port Replicator C o m p u t e r Removing the port replicator To remove the port replicator Close any active programs to prevent data loss.
Page 127 Using the Port Replicator Releasing the Port Replicator R e l e a s e l e v e r s Lift the computer away from the port replicator. Removing the Port Replicator...
Page 128 VAIO Computer Quick Start...
Page 129: Audio And Video Connections
Audio and Video Connections ❑ Using i.LINK Digital-Video Recorders ❑ Using Computer Monitors and Projectors ❑ Using Speakers, CD Players, or Amplifiers ❑ Using Microphones...
Page 130: Using I.link Digital-Video Recorders
The Found New Hardware window appears on the lower right corner of your screen. * i.LINK is a trademark of Sony used to designate that a product contains an IEEE 1394 connector. The i.LINK connection may vary, depending on the software application, operating system, and compatible i.LINK devices.
Page 131: Disconnecting The I.link Digital Video Recorder
Connecting an i.LINK Digital Video Camera Recorder D i g i t a l v i d e o c a m e r a r e c o r d e r ✍ See the guide that came with your digital video camera recorder for more information on its installation and use.
Page 132: Using A Digital Video Camera Recorder
Using a digital video camera recorder Your computer comes with preinstalled driver software that is compatible with most Sony digital video camera recorders. If you purchased a camera that comes with its own driver software, install these drivers before you use the camera.
Page 133: Frequently Asked Questions
See “Connecting an i.LINK digital video recorder” for more information. * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Page 134: Using Computer Monitors And Projectors
VAIO Computer Quick Start Using Computer Monitors and Projectors You can connect an external display (such as a computer monitor or a projector) to your computer or port replicator (not supplied). ❑ Connecting a computer monitor ❑ Connecting a TV ❑...
Page 135: Connecting A Tv
Connecting a Multimedia Display M o n i t o r ( V G A ) p o r t Connecting a TV You can connect a multimedia display, such as a TV or a VCR, to the computer or the port replicator (not supplied). To connect a TV to the computer Plug the display into an AC outlet.
Page 136 VAIO Computer Quick Start Connecting a TV A / V O U T j a c k Switch the TV input channel to external input. ✍ See the guide that came with your peripheral device for more information on its installation and use.
Page 137 The Fn+F8 key combination will not work once a DVD is inserted into the optical drive. Switching the display while a DVD is playing may cause the computer to malfunction, and you may need to restart the DVD software. To connect a TV to the port replicator Connect the port replicator to the computer.
Page 138 VAIO Computer Quick Start Connecting a TV to the Port Replicator L I N E O U T j a c k s a n d C o m p o s i t e V i d e o O u t j a c k Switch the TV input channel to external input.
Page 139: Connecting A Projector
Select a display. ❑ Press the Fn+F8 key combination to select either the computer screen (LCD) or an external display. See “Selecting a display mode” for more information. The Fn+F8 key combination will not work once a DVD is inserted into the optical drive.
Page 140: Selecting A Display Mode
VAIO Computer Quick Start Connecting a Projector P r o j e c t o r P o w e r c o r d ✍ See the guide that came with your projector for more information on its installation and use.
Page 141 Shortcut keys Result Toggles between the computer screen (LCD), a connected L C D (F7) external display (projector or computer monitor), and both the LCD and external display. Select one display at a time.Connect the cable before you turn on the computer, otherwise Fn+F7 will not work. only/ Toggles between the computer screen (LCD-only), TV-only, L C D...
Page 142 VAIO Computer Quick Start Mobility Radeon Properties window Click the selection tab located just above the display graphic to activate the display panel. Click the Primary icon display choice to change the display settings. Click Apply. For more information, click Help. ✍...
Page 143: Disconnecting A Computer Monitor Or Projector
Using Computer Monitors and Projectors Disconnecting a computer monitor or projector You can disconnect the external computer monitor or projector by unplugging the display or Monitor (VGA) cable from your computer’s port. Disconnecting the external display when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Page 144: Using Speakers, Cd Players, Or Amplifiers
VAIO Computer Quick Start Using Speakers, CD Players, or Amplifiers Your computer comes with built-in stereo speakers. If you wish to enhance the sound quality of your computer, you can purchase and connect external speakers. You can also purchase and connect other audio devices, such as a CD player or an amplifier.
Page 145: Disconnecting Standard Speakers
Connecting Standard Speakers ✍ See the guide that came with your speakers for more information on its installation and use. Disconnecting standard speakers You can disconnect external speakers when the computer is on or off. Simply unplug the speaker cable from the Headphone jack Connecting active speakers or amplifiers You can connect amplifiers or active speakers, which are equipped with amplifiers, to the port replicator or the computer.
Page 146 VAIO Computer Quick Start Connecting Active Speakers or Amplifiers to the Port Replicator A u d i o c a b l e ( n o t s u p p l i e d ) To connect active speakers or amplifiers to the computer Plug the audio cable into the A/V OUT jack on the computer.
Page 147: Disconnecting Active Speakers Or Amplifiers
Connecting Active Speakers or Amplifiers to the Computer A / V O U T j a c k Disconnecting active speakers or amplifiers You can disconnect active speakers or amplifiers when the computer is on or off. Simply unplug the audio cable from the LINE OUT on the port replicator or the A/V OUT jack on the computer.
Page 148: Disconnecting Cd, Minidisc, Or Audio Cassette Players
VAIO Computer Quick Start Connecting CD, MiniDisc, Audio Cassette Player Disconnecting CD, MiniDisc, or audio cassette players You can disconnect CD, MiniDisc, or audio cassette player when the computer is on or off. Simply unplug the audio cable from the LINE IN jack on the port replicator.
Page 149: Enabling The Audio Feature
To adjust the volume of your speakers Right-click the Volume icon Volume Control. The Volume Control window appears. Click and drag the Volume Control slider up to increase volume and down to decrease volume. Click to cancel any Mute check boxes that are selected. Sound device Volume Control Wave...
Page 150: Frequently Asked Questions
VAIO Computer Quick Start To enable the audio feature Click Start on the Windows® taskbar, and click Control Panel. Click Performance and Maintenance, and click System. The System Properties window appears. Select the Hardware tab, and click Device Manager. The Device Manager window, which lists the hardware devices, appears.
Page 151 ❑ Your speakers may be set to mute, the volume setting may be too low, or the audio option may be disabled. See “Adjusting the volume” and “Enabling the audio feature” for more information. Why don’t the Fn+F3 or the Fn+F4 key combinations work? The computer may not recognize the Fn+F3 and Fn+F4 key combinations if the correct speakers are not selected.
Page 152 VAIO Computer Quick Start Close the Profile Editor window.
Page 153: Using Microphones
You can connect an external microphone to your computer to enhance the sound input to your computer. Make sure your microphone is designed for computer use. If you wish to purchase a microphone, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 154: Using A Microphone Or Other Device To Record
VAIO Computer Quick Start Using a microphone or other device to record You can record messages, memos, or other recordings in analog by connecting a microphone or other audio device to the Microphone jack or port replicator and switching the jack functionality. The Microphone jack for MIC IN (monaural).
Page 155: Frequently Asked Questions
Using Microphones Frequently asked questions Why doesn’t my microphone work? If you are using an external microphone, make sure the microphone is properly plugged into the Microphone jack on the computer. See “Connecting a microphone” for more information.
Page 156 VAIO Computer Quick Start...
Page 157: Preinstalled Programs
Preinstalled Programs ❑ Software Programs On Your Computer ❑ DVgate Program Notes ❑ Program Support Information...
Page 158: Software Programs On Your Computer
VAIO Computer Quick Start Software Programs On Your Computer Your computer may not be supplied with all of the programs listed in “Program overview”, depending on the configuration you purchased. Preinstalled software may not be identical to retail versions or include supporting documentation. ❑...
Page 159 Click to DVD™ (On selected models) Sony Electronics Inc. At the touch of a button, Click to DVD software enables you to automatically burn DVDs from videos or still pictures. Create DVDs by capturing video content straight from a digital video (DV) device or stored video files —...
Page 160 Personal Start Page, free storage space for your personal Web site, a member magazine, and 24-hour technical support. Jog Dial Navigator Sony Electronics Inc. Jog Dial Navigator software enables you to easily scroll, launch applications, access settings, and perform other useful functions by manipulating the Jog Dial™...
Page 161 Sony Electronics Inc. PictureGear Studio image management software displays images from your hard drive or a Sony digital still camera. The images appear in a convenient light-table format, so that you can easily view the contents of an entire folder and create...
Page 162 Play CDs, MP3s and internet radio stations from anywhere in the world. View video clips and movies with the same player. Download music directly to your Sony MiniDisc™ Walkman or your Sony Memory Stick™ Walkman.
Page 163 Internet content. Sony on Yahoo! Yahoo! Inc. Personalize your own Web portal with Sony on Yahoo! Get a free Web mail account, customized news and local weather reports, comics, instant messaging, and more.
Page 164: Frequently Asked Questions
Make sure you place the CD in the tray with the label facing up. Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage program and Windows® software to create CDs on your VAIO® computer, if the specific model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
Page 165: Dvgate Program Notes
DVgate Program Notes ❑ Recording images to a digital video device ❑ Adjusting image resolution ❑ Saving to your hard disk drive Recording images to a digital video device If your system displays the message, “Failed to record to DV deck, please check deck’s power status, cable connection…,”...
Page 166 VAIO Computer Quick Start To defragment a partition Back up all files you want to save. From the Start menu on the Windows® taskbar, point to All Programs, Accessories, System Tools, and then click Disk Defragmenter. The Disk Defragmenter dialog box appears. Select the drive you want to defragment from the list, and click Defragment.
Page 167: Program Support Information
Program Support Information ❑ Sony Service Center Adobe® Acrobat® Reader®, Photoshop® Elements, Premiere® LE (Adobe Systems Inc.) Web site http://www.adobe.com/ e-mail techdocs@adobe.com telephone 206-675-6126 (fee-based support) 206-628-5737 hours M-F, 6 A.M.-5 P.M. (Pacific time) America Online® (America Online, Inc.) Web site http://www.aol.com/...
Page 168 888-4-SONY-PC (888-476-6972) hours 7 days a week, 24 hours a day * Support from 1-888-4-SONY-PC is free of charge for 90 days after the original date of purchase. Windows® Operating System, Word, XP Professional, XP Small Business (Microsoft Corp.) Web site http://www.sony.com/pcsupport...
Page 169: Sony Service Center
WinDVD® (InterVideo, Inc.) Web site http://www.intervideo.com telephone 510-651-0888 Yahoo! (Yahoo! Inc.) Web site http://help.yahoo.com/ Sony Service Center For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972) or find Sony Customer Service on the Web at http://www.ita.sel.sony.com/support. Program Support Information...
Page 170 VAIO Computer Quick Start...
Page 171: Memory Upgrades
Memory Upgrades ❑ Upgrading Your Computer’s Memory...
Page 172: Upgrading Your Computer's Memory
Sony recommends that memory upgrades be performed by an authorized Sony Service Center. To find the nearest center or agent, go to: http://www.sony.com/pcsupport.
Page 173: Typical Expansion Memory Configuration
❑ Do not open the memory module package until you are ready to install the module. The package protects the module from ESD. ❑ Use the special protective package to store a memory module and prevent ESD or use anti-static wrap. Typical expansion memory configuration Total System Memory (MB) 1024...
Page 174 VAIO Computer Quick Start To avoid damaging the computer, do not remove or loosen any other screws. Removing the Bottom Screws Touch a metal object (such as the connector panel on the back of your computer) to discharge static electricity. Remove the memory module by pulling out the tabs (see arrows No.
Page 175 To install a memory module Remove the existing memory module from the computer. See “To remove a memory module” for more information. Remove the new memory module from its packaging, and install the memory module by sliding it into the open slot at a 45-degree angle. Do not touch any part of the motherboard or the other components inside the computer.
Page 176: Confirming Added Memory Capacity
Click Start on the Windows® taskbar, point to All Programs, and then point to Sony Notebook Setup. Select Sony Notebook Setup from the submenu. The Sony Notebook Setup dialog box appears. On the About This Computer tab, make sure the System Memory displayed in the System Information box matches the amount of memory installed.
Page 177 Upgrading Your Computer’s Memory...
Page 178 VAIO Computer Quick Start...
Page 179: Using The Recovery Cds
Using the Recovery CDs ❑ Application and System Recovery CDs ❑ Using Your Recovery CDs...
Page 180: Application And System Recovery Cds
Recovery CDs. You will need an optical drive to use these recovery CDs. If your computer does not come with an optical drive, use an external optical drive. Application Recovery CD(s) Sony Electronics Inc. This CD enables you to reinstall individual software programs and device drivers if they become corrupted or are erased.
Page 181 Turn on your computer. If your computer is already on, close all open programs. Logon to the Microsoft® Windows® desktop. Insert Sony Application Recovery CD No. 1 into your computer’s optical drive. The Application Recovery utility loads automatically. Click OK in the VAIO welcome window. The Sony Application Recovery Program window appears.
Page 182: Using The System Recovery Cd(S)
CD(s), depending on the application or driver you want to restore. If you have any questions about using the Application Recovery CD(s), visit http://www.sony.com/pcsupport, or contact Sony Customer Support at 1-888-4- SONY-PC. Using the System Recovery CD(s) The System Recovery CD(s) enables you to format your hard disk and restore all original software programs.
Page 183 Your system may take a few minutes to load necessary files. A blue screen may appear during the downloading process. Insert the Sony System Recovery CD into the optical drive. The first CD must be in the drive before you restart your computer.
Page 184 Press the power button and hold it for more than four seconds to turn off the computer. Turn on the computer. When the Sony logo is displayed, press the F2 key. The BIOS Setup Utility appears. Press the right arrow key Press the down arrow key The Setup Confirmation window appears.
Page 185: Troubleshooting And Support
Troubleshooting and Support This section describes how to solve common problems you may encounter when using your computer. Many problems have simple solutions, so try these suggestions before you contact Sony Computing Support (http://www.sony.com/pcsupport). ❑ Troubleshooting Your Computer ❑ Troubleshooting Batteries ❑...
Page 186: Troubleshooting Your Computer
VAIO Computer Quick Start Troubleshooting Your Computer Why doesn’t my computer start? ❑ Make sure the computer is securely plugged into a power source and is on. Make sure the power indicator shows the power is on. See “Connecting the AC adapter”...
Page 187 Select Yes, and press Enter. The computer restarts. ✍ If this occurs on a regular basis, contact Sony Computing Support (http://www.sony.com/pcsupport). Why does the message, “Operating system not found” appear when my computer starts, and why won’t Windows start? ❑...
Page 188 VAIO Computer Quick Start Press Enter. The Setup Confirmation window appears. Select Yes, and press Enter. 10 Select Exit (Save Changes), and press Enter. The Setup Confirmation window appears again. 11 Select Yes, and press Enter. The computer restarts. If your computer continues to display the message “Operating system not found,” and Windows does not start, use your supplied System Recovery CD(s) to restore the software titles shipped with your computer.
Page 189 Why won’t the power management respond? Your computer’s operating system may become unstable if a lower power state, such as Hibernate, is initiated and changed before the computer completely enters the lower power state. To restore the computer to its normal operating stability Close all open programs.
Page 190: Troubleshooting Batteries
VAIO Computer Quick Start Troubleshooting Batteries How do I know when the battery is charged? To determine the remaining battery charge, see “Displaying battery information”. When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed.
Page 191: Troubleshooting The Printer
Select the Port Settings tab, and select a different LPT Port Number. ❑ You may need to set or reset your computer’s printer settings. Click Start, and point to All Programs, Sony Notebook Setup, and click Sony Notebook Setup again. Click the Device tab.
Page 192 VAIO Computer Quick Start In the left panel, make sure the Printer Port check box is selected, and click Setting. In the Printer port mode box, click the ECP option. Click OK.
Page 193: Troubleshooting The Mouse And Touch Pad
Troubleshooting the Mouse and Touch Pad Why doesn’t the computer recognize the mouse? ❑ Make sure the mouse is securely plugged into the USB or Mouse/Keyboard (PS/2) port. See “Connecting a USB mouse or keyboard” or “Connecting a PS/2 mouse or keyboard” for more information. ❑...
Page 194 VAIO Computer Quick Start Press the Windows appears. Click the Tools menu, and select Folder Options. The Folder Options dialog box appears with the General tab open. In the Click items as follows box, click to select Single-click to open an item (point to select).
Page 195: Troubleshooting The Modem
Make sure the telephone number the program is dialing is correct. ❑ Make sure the program you are using is compatible with the computer’s modem. (All preinstalled Sony programs are compatible.) ❑ If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
Page 196: Troubleshooting Networks
VAIO Computer Quick Start Troubleshooting Networks Why can’t my computer connect to a wireless LAN access point? ❑ Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using.
Page 197 the data transfer speed, move your computer away from obstructions or closer to any access point you may be using. ❑ If you are using a wireless LAN access point, the device may be temporarily overloaded depending on the number of other devices communicating via the access point.
Page 198 (Standby or Hibernate), restart both computers. For more information, see “Connecting Another VAIO Computer.” * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Page 199: Troubleshooting Dvds And Cds
Troubleshooting DVDs and CDs How do I maintain DVDs? ❑ Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors. ❑ To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out.
Page 200 VAIO Computer Quick Start Why isn’t the optical drive playing my CD or DVD properly? ❑ Make sure the disc label is facing up. ❑ If the disc requires software, make sure the software is installed according to the manufacturer’s instructions. ❑...
Page 201 Click to select the Enable digital CD audio for this CD-ROM device check box. Why did the computer screen (LCD) go blank? ❑ Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate). ❑...
Page 202 VAIO Computer Quick Start Move the screen resolution slider to the left to reduce the size and to the right to increase the size of the video resolution. How do I switch the computer screen (LCD) from LCD to TV? Press Fn+F8 to select either the computer or TV display.
Page 203: Troubleshooting Floppy Disk Drives
Troubleshooting Floppy Disk Drives Why doesn’t the Safety Remove Hardware icon the drive is connected? The computer does not recognize that the floppy disk drive is connected to the computer. First, make sure the USB connector is properly inserted into the USB port.
Page 204: Troubleshooting Pc Cards
Make sure the PC Card is compatible with the Microsoft® Windows® operating system installed on your computer. ❑ Use the Sony Notebook Setup utility to disable devices you are not currently using. See “To open Sony Notebook Setup” for more information. ❑...
Page 205: Troubleshooting Audio-Video Connections
See that program’s help file for more information. * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Page 206 VAIO Computer Quick Start ❑ Your speakers may be set to mute, the volume setting may be too low, or the audio option may be disabled. See “Adjusting the volume” and “Enabling the audio feature” for more information. Why don’t the Fn+F3 or the Fn+F4 key combinations work? The computer may not recognize the Fn+F3 and Fn+F4 key combinations if the correct speakers are not selected.
Page 207 Troubleshooting Audio-Video Connections Close the Profile Editor window. Why doesn’t my microphone work? If you are using an external microphone, make sure the microphone is properly plugged into the Microphone jack on the computer. See “Connecting a microphone” for more information.
Page 208: Troubleshooting The Computer Screen (Lcd)
VAIO Computer Quick Start Troubleshooting the Computer Screen (LCD) Why did the computer screen (LCD) go blank? ❑ Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate). ❑...
Page 209 Troubleshooting the Computer Screen (LCD) How do I switch the computer screen (LCD) from LCD to TV? See “Selecting a display mode” for instructions on how to switch the display mode to LCD and TV.
Page 210: Troubleshooting Memory Stick Media
❑ Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders.
Page 211 ❑ Do not bend, drop, or apply strong shock to the media. ❑ Do not disassemble or modify the media. ❑ Do not allow the media to get wet. How do I extend the life of the Memory Stick media? ❑...
Page 212: Troubleshooting Programs
Make sure you place the CD in the tray with the label side facing up. Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage software and Windows® software to create CDs on your VAIO® computer, if the specific model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
Page 213: Computer Support Information
VAIO Support Agent You can find VAIO Support Agent by clicking Start and selecting Help and Support. Using advanced diagnostic technology, Sony’s VAIO Support Agent runs scheduled protections of your programs, network settings, and other important program settings. When your program is protected, you can use VAIO Support Agent to repair program problems by restoring the program to any of the previously protected states.
Page 214 VAIO Computer Quick Start...
Page 215 AC adapter connecting AC Profile power setting adding memory Application Recovery CD Applications key arrow keys audio connecting microphone connecting speakers audio-video (AV) connecting i.LINK bass boost battery power saving modes battery pack inserting second pack notes battery packs charge status icons charging indicator lights 16, 18...
Page 216 VAIO Computer Quick Start Computer online support computer connecting computers online support troubleshooting connecting coin-operated telephones computers dial-up digital video recorder Ethernet floppy disk drive hard drives i.LINK device Internet microphone multiple phone lines network party phone lines port replicator printer projector PS/2 keyboard...
Page 217 floppy disk installing additional hard disk optical DVD-ROM drive tray 67, 199 troubleshooting DVgate application 56, 57 Eject button Escape key Ethernet connecting external devices projectors speakers external display connecting floppy disk drive carrying connecting 115, 126 disconnecting floppy disks handling 116, 203 troubleshooting...
Page 218 VAIO Computer Quick Start IEEE 1394 image resolution DVgate indicator lights 17, 81 battery Caps Lock hard disk Memory Stick Num Lock Scroll Lock Wireless LAN installing hard drives Internet connecting jacks modem Jog Dial Control Jog Dial Navigator Indicate window Launcher window settings key locations...
Page 219 adding confirming added capacity removing Memory Stick displaying contents formatting indicator light inserting Magic Gate MagicGate removing troubleshooting types using write-protecting microphone connecting 155, 207 troubleshooting modem 37, 195 troubleshooting modem jack monitor switching modes mouse PS/2 109, 193 troubleshooting multiple phone lines navigation keys network...
Page 220 VAIO Computer Quick Start 56, 57 opening tray party phone lines PC Card inserting using peripheral device TV/VCR port replicator connecting ports printer Serial port power power button Power Management Off power setting power saving modes 24, 83 Hibernate Standby power setting AC Profile Maximum Battery Life...
Page 221 Scroll Lock indicator light search second battery pack inserting removing Serial port software changing window design DVgate support information Software list Sony Service Center speakers built-in connecting off and on volume Standby mode support software System Recovery CD telephone connecting line...
Page 222 VAIO Computer Quick Start mouse and touchpad printer TV or a video deck printer using PC Card video camera volume speakers window design of Sony software Windows Find window help Windows key combinations and functions Wireless LAN indicator light...
