Hints for Energy Saving ................... 22 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ..23 TECHNICAL DATA ................. 24 INFORMATION FOR TEST INSTITUTES ..........24 Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support EN - 3 -...
PART - 1. BEFORE USING THE APPLIANCE General warnings Please read the instruction manual carefully before installing and using your appliance. We are not responsible for the damage occurred due to misuse. Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve the problems that may occur in the future.
Page 5
during transportation and installation to prevent the cooler elements from being damaged. R600a is an environmentally friendly and natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
Page 6
they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. •...
Page 7
• Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice cream and making ice cubes. • One-, two- and three-star compartments are not suitable for the freezing of fresh food. • If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance.
Old and out-of-order fridges or freezer • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges.
• Do not place glass bottles or cans in the ice-making compartment as they will burst when the contents freeze. • Do not place explosive or flammable material in your freezer. • When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or cuts.
• Use the adjustable front legs to make sure your appliance is level and stable. You can adjust the legs by turning them in either direction. This must be done before placing food in the appliance. • Install the two plastic distance guides (the parts on the black vanes -condenser- at the rear) by turning it 90°...
Dimensions Overall dimensions Overall space required in use 1860 1245 the height, width and depth of the the height, width and depth of the appliance without the handle appliance including the handle, plus the space necessary for free circulation of the cooling air, plus Space required in use the space necessary to allow door opening to the minimum...
PART - 2. THE VARIOUS FUNCTION AND POSSIBILITIES Information on No-Frost technology No-frost freezers differ from other static freezers in their operating principle. In normal freezers, the humidity entering the freezer due to opening the door and the humidity inherent in the food causes freezing in the freezer compartment.
Display and Control Panel Using the Control Panel 1. Freezer temperature set button 2. Super freeze symbol (Super freeze LED) 3. Alarm symbol (Alarm LED) 4. Freezer adjusted temperature indicator Operating your Freezer Lighting (If available) When the product is plugged in for the first time, the interior lights may turn on 1 minute late due to opening tests.
• Press freezer setting button once. • Every time you press the button, the setting temperature will decrease. (-16 °C, -18 °C, -20 °C,.. super freezing) • If you press freezer setting button until super freezer symbol is displayed on freezer. •...
Important installation instructions This appliance is designed to work in difficult climate conditions (up to 43 degrees C or 110 degrees F) and is powered with ‘Freezer Shield’ technology which ensures that the frozen food in the freezer will not defrost even if the ambient temperature falls as low as -15 °C. So you may then install your appliance in an unheated room without having to worry about frozen food in the freezer being spoilt.
Page 16
• Do not store fresh food next to frozen food as it can thaw the frozen food. • Before freezing fresh food, divide it into portions that can be consumed in one sitting. • Consume thawed frozen food within a short period of time after defrosting •...
Page 17
Important note: • Never refreeze thawed frozen food. • The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they are stored for a long period of time. Therefore, add small amounts of spices to food to be frozen, or the desired spice should be added after the food has thawed.
Page 18
Maximum storage time Vegetables and Fruits Preparation (months) String beans and beans Wash, cut into small pieces and boil in water 10 - 13 Beans Hull, wash and boil in water Cabbage Clean and boil in water 6 - 8 Carrot Clean, cut into slices and boil in water Cut the stem, cut into two pieces, remove the core...
PART - 4. CLEANING AND MAINTENANCE Disconnect the unit from the power supply before cleaning. Do not wash your appliance by pouring water on it. Do not use abrasive products, detergents or soaps for cleaning the appliance. After washing, rinse with clean water and dry carefully. When you have finished cleaning, reconnect the plug to the mains supply with dry hands.
• Remove the vaporisation container from its position by removing the screws as indicated. Clean it with soapy water at specific time intervals. This will prevent odours from forming. Replacing LED Lighting Depending on the model, one LED strip in the freezer is used to illuminate the interior of your appliance.
PART - 6. BEFORE CALLING YOUR AFTER SALES SERVICE Errors Your freezer will warn you if the temperatures for the freezer is at improper levels or if a problem occurs with the appliance. In case of a problem within the freezer, the alarm led will release red light.
Air blowing noise occurs: In No-Frost freezers during normal operation of the system due to the circulation of air. The edges of the freezer in contact with the door joint are warm Especially during summer (warm seasons), the surfaces in contact with the door joint may become warmer during the operation of the compressor, this is normal.
THE PARTS OF THE APPLIANCE AND THE PART - 7. COMPARTMENTS 1. Control panel 2. Freezer flaps 3. Freezer drawers 4. Freezer bottom drawer 5. Freezer big drawer 6. Ice tray (In some models) In some models there is a shelf with icematic in the top basket This presentation is only for information about the parts of the appliance.
PART - 8. TECHNICAL DATA The technical information is situated in the rating plate on the internal side of the appliance and on the energy label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
