- Page 1 MICROWAVE OVEN Model No. EM031M2ZC-X1 EM031M2ZC-X2 EM031M2ZC-X3 EM031M2ZC-X4 Hamilton Beach is a registered trademark of Hamilton Beach Brands, Inc. used under license by Wal-Mart Stores, Inc.
-
Page 2: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open as this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances basic safety precautions should always be followed, including the following: WARNING- To reduce the risk of burns, electric shock, fire and/or injury to persons, or exposure to excessive microwave energy: • Read all instructions before using the should not be heated in the oven. -
Page 4: Grounding Instructions
Liquids, such as water, coffee, or tea may overheat beyond the boiling point • without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED, OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. -
Page 5: Power Supply Cord
Power Supply Cord 1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. 2. Longer cord sets or extension cords are available and may be used if care is exercised in their use. -
Page 6: Materials You Can Use In Microwave Oven
Materials you can use in microwave oven Materials Comments Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls. -
Page 7: Setting Up Your Oven
SETTING UP YOUR OVEN Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray Turntable ring assembly Instruction manual A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray Turntable Installation... -
Page 8: Before Installation
Before Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. -
Page 9: Operation
OPERATION Control Panel and Features (11) (1) Time Cook (2) Time Defrost (3) Power (10) (4) Clock (5) Auto menu: Popcorn, Potato, Pizza, Frozen Vegetable, Beverage, Dinner Plate (6) Number Buttons: 0-9 (7) Weight Defrost (8) Kitchen Timer function (9) Stop/C lear : clears all previous settings pressed before cooking starts. -
Page 10: Clock Setting
Operation 1. Power Level The following power levels are available. Level Power 100% Display PL10 2. Clock Setting (1) Press " CLOCK ," "00:00" will display. 2) Press the number keys and enter the current time. For example, to set the clock to 10:12, press "1,0,1,2 . -
Page 11: Express Cook
Example: to cook the food with 50% microwave power for 15 minutes. a. Press "TIME COOK" once. "00:00" displays. b. Press "1","5","0","0" in order. c. Press "POWER" once, then press "5" to select 50% microwave power. d. Press "START/+30SEC." to start cooking. Note: button is pressed or no operation 1. - Page 12 POPCORN (1) Press " POPCORN " repeatedly until the package size of your popco appears in the display, "1.75", "3.0", "3.5" will display in order. For example, press "POPCORN" once, "1.75" appears. (2) Press "START/+30 SEC." to cook, buzzer sounds once. When cooking finished, buzzer will sound five times POTATO...
-
Page 13: Dinner Plate
DINNER PLATE (1) Press " DINNER PLATE " repeatedly until the number you wish appears in the display, "9.0","12.0","18.0" oz will display in order. For example, press "DINNER PLATE" once, "9.0" appears. (2) Press "START/+30 SEC." to cook, buzzer sounds once. When cooking is finish a buzzer sounds five times. -
Page 14: Multi-Stage Cooking
15. Multi-stage Cooking At most, 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then defrosting shall be placed at the first stage automatically. Note: Auto cooking cannot work in the multi-stage cooking. Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10 minutes. -
Page 15: Troubleshooting
Troubleshooting Check your problem by using the chart below and try the solutions for each problem. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY a. Electrical cord for oven is a. Plug into the outlet. not plugged in. b. Close the door and try Oven will not start b. -
Page 16: One-Year Limited Warranty
SAVE THIS FOR YOUR RECORDS Hamilton Beach® is a registered trademark of Hamilton Beach Brands, Inc. used under license by Wal-Mart Stores, Inc. Bentonville, AR 72716. Made in China ...
Need help?
Do you have a question about the EM031M2ZC-X1 and is the answer not in the manual?
Questions and answers
How to turn sound off?
What size is turntable plate
The turntable plate for the Hamilton Beach EM031M2ZC-X1 is 12-3/8 inches (315mm) in diameter.
This answer is automatically generated
I have an EM031M2ZC-X3. How do I turn off the beep?
Does the watt being used change if you decrease the power level? Is the microwave safe for use in a 14.9 liter semi truck?
The provided context does not specify the wattage changes when decreasing the power level on the Hamilton Beach EM031M2ZC-X1 microwave. However, microwaves typically reduce power by cycling the magnetron on and off rather than changing the wattage output.
Regarding its use in a 14.9-liter semi-truck, the microwave operates at 120V~ 60Hz. To determine if it is safe for use in the truck, you need to check if the truck’s power system can support this voltage and frequency. If the truck does not provide a stable 120V~ 60Hz power source, the microwave may require an inverter with sufficient wattage capacity.
This answer is automatically generated
