AK-HRP1015 Firmware update procedure
1. Version display method
1-1
Each software version can be confirmed at item "SOFT VERSION" and "FPGA VERSION" in ROP SETTING menu.
1. Supply the power to AK-HRP1015 by connecting to AK-UC4000/UC3000/HC5000, AK-UCU600/UCU500, or PoE
HUB.
2. Press the SETUP button. The TOP menu screen of ROP menu appears.
3. Select "ROP SETTING" by pressing the Function △▽button.
4. Press the EXEC button to open the ROP SETTING menu.
5. When pressing the Function △▽button, SYSTEM version and each Software version can be confirmed.
AK-HRP1015 Firmware Update Procedure / Mar.2021
MENU
37 ROP SETTING
38 CONNECT SETTING
39 ROP IP SETTING
40 CAMERA IP SETTING
SETUP button
41 SD CARD STORE
42 SD CARD LOAD
EXEC button
ROP SETTING
UPGRADE
SYSTEM VERSION
ROP SETTING
SOFT VERSION
FPGA VERSION
Page1/4
Function button
IRIS CALIBRATION
TOP
BOTTOM
NO?
NO?
NO?
1.00-00-0.00
1.00-0000.00
1.00-00-0.00
Panasonic Corporation
7 / 8
5 / 6
6 / 6
