AUTO SCAN
Performs an auto scan to update the list of
services in browse mode. (Available only
during DAB reception.)
FIRMWARE
(Available only while the source is off and the
clock is displayed.)
Checks/updates the firmware version. For
details, consult your nearest Alpine dealer.
FW VERSION (firmware version)
Displays current firmware version.
FW UPDATE (firmware update)
Enters firmware update process: [YES], [NO].
Updating the firmware takes a few minutes to
complete. During the update, do not turn the
ignition to the OFF position, nor remove the
USB device.

Audio Setup (AUDIO)

This setup menu is not available when the source
is off and the clock is displayed.
EQ PRESET
Selects an equalizer curve from 10 equalizer
curves or off:
[USER], [FLAT](OFF), [POPS], [ROCK], [NEWS],
[JAZZ], [ELEC DANCE], [HIP HOP], [EASY LIS],
[COUNTRY], [CLASSICAL].
The equalizer curve setting can be memorized
for each source.
3BAND PEQ (3Band Parametric Equalizer)
Adjusts WIDTH, FREQUENCY and LEVEL for
each after BAND is selected.
BAND: [BASS], [MID], [TREBLE].
Setting contents: [WIDTH <Q>], [CENTER
FREQ], [LEVEL].
BALANCE
Adjusts the sound balance: [R 15] – [0] – [L 15].
FADER
Adjusts the relative level: [F 15] – [0] – [R 15].
SUBWOOFER
SUBW LEVEL (subwoofer level)
Adjusts the subwoofer volume level:
[OFF], [0] - [+15].
SUBW PHASE (subwoofer phase)
Selects the subwoofer phase: [NORMAL],
[REVERSE].
LPF FREQ (low pass filter frequency)
Selects the subwoofer cut-off frequency:
[80Hz], [100Hz], [120Hz].
HPF FREQ (high pass filter frequency)
Selects the front/rear speaker cut-off
frequency: [OFF], [80Hz], [100Hz], [120Hz].
AUX VOL (AUX volume level)
Adjusts the volume level for each connected
auxiliary device: [+18 dB] – [0 dB] – [-8 dB].
This setting negates the need to adjust the
volume level between sources.
(Available only when the AUX is selected.)
BTA VOL (BLUETOOTH audio volume level) (CDE-
205DAB/ UTE-204DAB only)
Adjusts the volume level for each connected
BLUETOOTH device: [+6 dB] – [0 dB] – [-6 dB].
This setting negates the need to adjust the
volume level between sources.
(Available only when the BT audio is selected.)

Display Setup (DISPLAY)

BLACK OUT
If no operation is performed for a while with
[ON] set, the display disappears automatically.
Activates the black out: [ON], [OFF].
DIMMER
Changes the display brightness:
[OFF], [ON], [AUTO], [CLOCK].
([AUTO] is available only when the
illumination control lead is connected, and
the head light is turned on.)
To set this function to be active only during a
fixed period, select [CLOCK], then set the start
and end times.
– To set the brightness when the dimmer
function is activated:
Set [DIMMER] to [ON], then adjust
[BRIGHTNESS].
– To set the brightness when the dimmer
function is deactivated:
Set [DIMMER] to [OFF], then adjust
[BRIGHTNESS].
