Android TV Box
ENJOY TV Dual CORE
ATV1200
User Manual
Thank you for purchasing this MyGica product.
.Before using it, be sure to read the precautions contained in this User's Guide.
.Keep the User's Guide in a safe place for future reference.
.For the most up-to-date information about this product, visit official website at
http://www.mygica.com
Advertisement
Table of Contents
Related Manuals for MyGica ATV1200
Summary of Contents for MyGica ATV1200
- Page 1 ENJOY TV Dual CORE ATV1200 User Manual Thank you for purchasing this MyGica product. .Before using it, be sure to read the precautions contained in this User’s Guide. .Keep the User’s Guide in a safe place for future reference. .For the most up-to-date information about this product, visit official website at...
-
Page 3: Safety Information
1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product, this could lead to the risk of injury, damage to the product. -
Page 4: Handling Cautions
Do not use the product. Using the product as it is may cause a fire or an electric shock. 2. Introduction 2.1 Package Contents Enjoy TV Dual Core - ATV1200 HDMI Cable A/V Cable User Manual Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 12V/1.5A... -
Page 5: Panel Introduction
2.3 Panel Introduction 2.4 Remote Controller Learning Key function setup instruction: 1. Press and hold the Power button inside the learning area (Button 13) for 6 seconds, the red... -
Page 6: Setup Connection
5. Once learning is finished, press any button outside of learning area to exit learning states and the red indicator will turn off. 2.5 Setup Connection Place ATV1200 on a flat platform near the TV, and make sure nothing blocks the remote control signal. 2.6 Display when Power Up 2.6.1 After power up, the TV will first show a green robot then change to “android”... - Page 7 Or if connection fails you will need to reset password. 3.1.3 Once the connection to a certain Wi-Fi network is done successfully, ATV1200 will connect this Wi-Fi network automatically when restart. Note: If factory reset, the password of Wi-Fi network have to be reset.
-
Page 8: Data Usage
3.2 Ethernet Connect Box and Router by RJ45 network cable. Press “ON” in Ethernet setting, it will connect to network automatically. 3.3 Data usage Show data usage information. 3.4 More... 3.4.1 VPN Build and set VPN... - Page 9 3.4.2 Portable hotspot 3.4.2.1 Enable Portable hotspot 3.4.2.2 Set up Wi-Fi hotspot 3.4.2.3 Choose different security way to share your network. 3.4.2.4 Help for any confusion Note: Wi-Fi and hotspot connection cannot be applied at same time. Disconnect Wi-Fi and connect Ethernet while using hotspot function. 3.4.3 Proxy settings Setup proxy server 3.5 Sound...
- Page 10 3.5.2 Touch Sounds If Touch sound is enabled, sound will be heard while you move on the remote controller. 3.6 Display 3.6.1 Font size Change the font size of OSD 3.7 Storage Shows the storage used of the OS and SD card.
- Page 11 3.8 Apps List all apps installed. You can choose an application and force to shut down the app, uninstall the app, clear user data, move to SD card and clear cache data. 3.9 Security...
-
Page 12: Language And Input
3.10 Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method. 3.11 Backup & reset Back up my data: You can backup your application data, Wi-Fi password and other settings. -
Page 13: Developer Options
3.12 Date & Time Set date, time, time zone and time format 3.13 Developer options If user want to do some debugging on box by ADB, enable USB debugging, you will get ADB function by Ethernet or Wi-Fi network. -
Page 14: About Mediabox
Firmware version under build number. 4. Apps Install & Uninstall On ATV1200, you can install apps from Android Market over the Internet or other sources, such as other online sources, the internal storage and the USB storage device and SD card that you have mounted onto ATV1200. - Page 15 XBMC Media Center allows you to play and view most videos, music such as podcasts from the internet, and all common digital media files from local and network storage media. 5.1.1 Playback local media files Under Videos (same as Music and Pictures) there are 2 options, Files & Add-ons. To playback local media files, select ‘Files’...
- Page 16 If your media files are store in SD Card, select ‘sdcard’ folder, if the files are store in USB drive, select ‘sda’ folder. Once you select the desire folder, select ‘OK’ and you will find out that folder will be added to the Files list. You can enter that folder and playback media files you want.
-
Page 17: Local Media
Once you enter Add-ons, you will see a list of different channels. These channels are in alphabetical order, browse through the list and select the desire channels and start playback the internet media. 5.2 Local Media To access media files in your SD card/USB device, simple click on ‘Local Media’ in the Home screen. - Page 18 5.3 Media Center Media Center lets you enable DLNA or Airplayer function. DLNA_DMP: DLNA_DMP lets you visit DLNA share folders on other devices in the same network and playback shared file. DLNA_DMR: Lets you stream media file from your android mobile device to the player ...
- Page 19 1. Make sure MyGica Enjoy TV Box and your Android phone/Tablet are connected to the same network. 2. On MyGica Enjoy TV Box, goto settings > Wi-Fi and click on the router which is currently connected. (Usually it is the first router on the list with ‘Connected’ under the router name.) 3.
- Page 20 If your device cannot find the MyGica Enjoy TV Box, you can click on the button and manually input the IP address of MyGica Enjoy TV Box. 5.5.3. Using RemoteIME Once properly connected, your Android phone/tablet will become a remote control for...
-
Page 21: Firmware Update
We recommend you read this manual thoroughly, search for a solution on line at www.mygica.com, or contact MyGica Customer Care before seeking to repair your player. 9. Specification Dual core ARM CORTEX A9 1.5GHz, 3D engine... -
Page 22: Trademark Notice
IR receiver RJ45 10/100M Ethernet interface Wi-Fi IEEE 802.1 B/G/N 2.4G,wireless Internet access Audio Decoder MPEG MP1, MP2, MP3 WMA Ver: 4, 4.1, 7, 8, 9 WMA Pro Other Audio WAV, OGG, OGA, FLAC, ALAC, Ape, AAC, M4A, AC3,DTS,RM Video Decoder Performance Max.
