TECHNICAL MANUAL
ULTRASONIC TEST SET
MODEL TS500
OCTOBER 10, 2018
REV D
DUKANE SEACOM, INC. SARASOTA, FLORIDA 34243 PHONE: 941-739-3200 FAX: 941-739-3201
DOCUMENT NO. 03-TM-0082 © DUKANE SEACOM, INC.
INTERNET: www.dukaneseacom.com
Page 1 of 6
DOCUMENT NO. 03-TM-0082 REV D
Advertisement
Table of Contents
Related Manuals for Dukane Seacom TS500
Summary of Contents for Dukane Seacom TS500
- Page 1 TECHNICAL MANUAL ULTRASONIC TEST SET MODEL TS500 OCTOBER 10, 2018 REV D DUKANE SEACOM, INC. SARASOTA, FLORIDA 34243 PHONE: 941-739-3200 FAX: 941-739-3201 DOCUMENT NO. 03-TM-0082 © DUKANE SEACOM, INC. INTERNET: www.dukaneseacom.com Page 1 of 6 DOCUMENT NO. 03-TM-0082 REV D...
- Page 2 This manual should be read in its entirety prior to operation of the TS500 Test Set Page 2 of 6 DOCUMENT NO. 03-TM-0082 REV D...
- Page 3 ANSI Y14.15 and MIL-STD-12, respectively. 1.2. GENERAL DESCRIPTION 1.2.1. FUNCTION. The TS500 is a battery operated heterodyne type receiver that operates at an ultrasonic frequency of 8.8 kHz and 37.5 kHz. The test set was designed primarily as a self-...
- Page 4 A. Turn the test set ON using the small slide switch located on the left side of the housing. B. If the display reads LB, LO BAT or ∆ on the left side, the TS500 battery voltage has fallen be- low the level required for operation of the test set and the 9 Volt battery should be replaced.
- Page 5 3.3. TEST SET CALIBRATION 3.3.1. The TS500 Test Set is calibrated at the factory during manufacture. Under normal operat- ing conditions the test set will not require calibration for a period of 15 months. The calibration due date is shown on the back of the test set.
- Page 6 SECTION IV WARRANTY TEST SETS Dukane Seacom, Inc. warrants that the Test Set (referred to as the unit) will be free from defects in materials and workmanship, when used under normal operating conditions as determined solely by Dukane Seacom, Inc., for a period of one (1) year from the date of shipment from Dukane Sea- com, Inc.
