  • Page 1 Operating Instructions XG 310/330 Rev. 2...

  • Page 2: Security Symbols

    Operating Instructions Foreword We are pleased to welcome you as a new customer of our Sophos XG appliances. To install and configure the hardware appliance you can use the following documents: Ì Hardware Quick Start Guide: Connection to the system peripherals in a few steps Operating Instructions: Notes on the security and Ì...

  • Page 3: Operating Elements And Connections

    Connector for optional 2nd external power supply Power supply Connector for optional Power switch PoE Power Module HDMI USB 3.0 * The displayed front image is of XG 330 device. The XG 310 device may vary slightly. XG 310/330 Rev. 2...

  • Page 4: Led Status

    Power No power LCD and Control Keys The Sophos XG 310/330 units have an LCD and an operating unit with four membrane keys. In the LCD, 16 characters per line can be displayed. SOPHOS While the security appliance is booting this message is displayed...
  • Page 5 1. v to Cont. Factory Reset 2. Confirm Firmware Menu Shutdown 3. Shutdown 1. v to Cont. Shutdown 1. Confirm Firmware Menu Reboot 4. Reboot 1. v to Cont. Reboot 1. Confirm Main Menu Not Configured 4. HA Info XG 310/330 Rev. 2...

  • Page 6: Factory Reset

    Shows Firmware Menu second item 2. Factory Reset Factory Reset Press down key to continue 1. v to Cont. Factory Reset Asks for Confirmation 2. Confirm? Factory Reset under progress Firmware Version Factory Reset complete SFOS 16.05.1 MR-1 XG 310/330 Rev. 2...
  • Page 7 Firmware Menu Shows Firmware Menu fourth item 4. Reboot Factory Reset Press down key to continue 1. v to Cont. Factory Reset Asks for Confirmation 1. Confirm? Reboot under progress Firmware Version Reboot complete SFOS 16.05.1 MR-1 XG 310/330 Rev. 2...

  • Page 8: Putting Into Operation

    The supplied parts are indicated in the Hardware Quick Start Guide. Mounting Instructions The XG 310/330 appliances are designed for use in racks. Please consider the following security tips: Important Note: Functional reliability outside of a rack cannot be guaranteed.

  • Page 9: Rack Mounting Considerations

    This product is for installation only in a restricted access location (no capitalization) (dedicated equipment rooms, service closets and the like). 3. Slide the appliance into the rack. 4. Attach the front and rear brackets to the rack with the appropriate screws (not included). XG 310/330 Rev. 2...

  • Page 10: Connection And Configuration

    How to connect the appliance is described in the Hardware Quick Start Guide. For configuration you can follow the initial setup wizard described in the WebAdmin Quick Start Guide or cancel it and perform a manual setup (see the Sophos XG Firewall Administrator Guide).

  • Page 11: Serial Console

    Please read the operation manual to the SFP GBIC module. Serial Console You can connect a serial console to the COM port of the Sophos XG Firewall hardware appliances. You can use, for instance, the Hyperterminal terminal program which is included with most versions of Microsoft Windows to log on to the appliance console.
  • Page 12 Registered in England and Wales No. 2096520, The Pentagon, Abingdon Science Park, Abingdon, OX14 3YP, UK Sophos is the registered trademark of Sophos Ltd. All other product and company names mentioned are trademarks or registered trademarks of their respective owners.
