AXIS Q7436 Video Encoder Blade
Hardware Overview

Pin Assignments for RS485 Connector - AXIS Q7920 Chassis

Pin Function
1
Channel 1, RS485A
2 Channel 1, RS485B
3
Channel 2, RS485A
4
Channel 2, RS485B
5
Channel 3, RS485A
6
Channel 3, RS485B
7
Channel 4, RS485A
8
Channel 4, RS485B
9
Channel 5, RS485A
10 Channel 5, RS485B
11
Channel 6, RS485A
12
Channel 6, RS485B

LED Indicators

Note
• The Status LED can be configured to flash while an event is active.
• The Status LED can be configured to flash for identifying the unit. Go to Setup > System Options > Maintenance .
Status LED
Green
Amber
Red
Green/Red
Power LED
Green
Amber
Indication
Steady green for normal operation.
Steady during startup, during reset to factory default or when restoring settings.
Steady for hardware error on the corresponding channel.
Flashes for identification purposes. To configure, go to Setup > System Options > Maintenance.
See the online help for more information.
Indication
Normal operation.
Flashes green/amber during firmware upgrade.
Description
A half-duplex RS485 interface for controlling auxiliary
equipment such as PTZ devices.
8
