DMC-FX70EB
Model No.
DMC-FX70EE
DMC-FX70EF
DMC-FX70EG
DMC-FX70EP
DMC-FX70SG
DMC-FX75P
DMC-FX75PU
DMC-FX75GC
DMC-FX75GD
DMC-FX75GH
DMC-FX75GK
DMC-FX75GN
DMC-FX75GT
Vol. 1
Colour
[ DMC-FX70 ]
(S)...........Silver Type (only EG/SG)
(K)...........Black Type
(A)...........Blue Type (only SG)
(N)...........Gold Type (only SG)
(P)...........Pink Type (only SG)
[ DMC-FX75 ]
(S)...........Silver Type (only P/GC/GH/GK)
(K)...........Black Type
(N)...........Gold Type (only GC/GD/GH/GT)
(P)...........Pink Type (except P/PU/GN)
(V)...........Violet Type (only PU/GK/GT)
© Panasonic Corporation 2010 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1007039CE
B26
Digital Camera
Advertisement
Chapters
Table of Contents
Related Manuals for Panasonic DMC-FX70EB
Summary of Contents for Panasonic DMC-FX70EB
- Page 1 (N)...Gold Type (only SG) (P)...Pink Type (only SG) [ DMC-FX75 ] (S)...Silver Type (only P/GC/GH/GK) (K)...Black Type (N)...Gold Type (only GC/GD/GH/GT) (P)...Pink Type (except P/PU/GN) (V)...Violet Type (only PU/GK/GT) © Panasonic Corporation 2010 Unauthorized copy- ing and distribution is a violation of law.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1.)--------3 1.4. How to Discharge the Capacitor on Flash Top P.C.B.----------------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1. -
Page 3: Safety Precautions
1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check. -
Page 4: How To Discharge The Capacitor On Flash Top P.c
1.4. How to Discharge the Capacitor on Flash Top P.C.B. CAUTION: 1. Be sure to discharge the capacitor on FLASH TOP P.C.B.. 2. Be careful of the high voltage circuit on FLASH TOP P.C.B. when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and remove the necessary parts/unit. 2. -
Page 5: Warning
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD). -
Page 6: Caution For Ac Cord(For Eb/Gc
A replacement fuse cover can be purchased from your local 2.3.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety. -
Page 7: How To Replace The Lithium Battery
NOTE: This Lithium battery is a critical component. (Type No.: ML421 Manufactured by Energy Company, Panasonic Corporation.) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use. -
Page 8: Service Navigation
3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2. -
Page 9: How To Define The Model Suffix (Ntsc Or Pal Model)
How to Define the Model Suffix (NTSC or PAL model) There are nine kinds of DMC-FX70/FX75, regardless of the colours. • a) DMC-FX70 (Japan domestic model), DMC-FX70SG • b) DMC-FX75P • c) DMC-FX70EB/EF/EG/EP • d) DMC-FX70EE • e) DMC-FX75GT • f) DMC-FX75GK •... - Page 10 3.5.2. INITIAL SETTINGS: After replacing the MAIN P.C.B., be sure to perform the initial settings after achieving the adjustment by ordering the following pro- cedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
- Page 11 [CASE 1. After replacing MAIN P.C.B.] [Except “EG, EF, EB and EP” models: (VEP56110A is used as a Main P.C.B.] When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Four pages in total) [Only “EG, EF, EB and EP”...
- Page 12 Chinese (traditional) Year/Month/Date g) DMC-FX75GK Chinese (simplified) Year/Month/Date h) DMC-FX70EE Russian Date/Month/Year i) DMC-FX75GN English Date/Month/Year j) DMC-FX70SG English Date/Month/Year k) DMC-FX75GH English Date/Month/Year l) DMC-FX70EG English Date/Month/Year m) DMC-FX70EF French Date/Month/Year n) DMC-FX70EB English Date/Month/Year o) DMC-FX70EP English Date/Month/Year...
-
Page 13: Specifications
4 Specifications... -
Page 14: Location Of Controls And Components
19 Card/Battery door 20 Release lever 21 DC coupler cover When using an AC adaptor, ensure that the Panasonic DC coupler and AC adaptor are used. Always use a genuine Panasonic AC adaptor (DMW-AC5PP; optional). We recommend you use a battery with sufficient battery power or the AC adaptor when recording motion pictures. - Page 15 The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.
-
Page 16: Service Mode
6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (i.e.,when the unit is powered on by the battery, the battery is pulled out) The error code is memorized to FLASH-ROM when the unit has just before powered off. - Page 17 • 3. Error Code List The error code consists of 8 bits data and it shows the following information.
-
Page 18: Ics (Indication Of Additional Camera Settings When Picture Was Taken) Function
Important notice about "Error Code List" 1) About "*" indication: The third digit from the left is different as follows. - In case of 0 (example: 18001000) When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been completed. - Page 19 3. How to read 4. How to exit: Simply, turn the power off. (Since ICS function is executed under the condition of temporary cancellation of "INITIAL SETTINGS", it wake up with normal condition when turn off the power.)
-
Page 20: Service Fixture & Tools
7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit. -
Page 21: When Replacing The Main P.c.b
7.2. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-AVC” web-site in “TSN system”, together with Maintenance software. 7.3. Service Position This Service Position is used for checking and replacing parts. -
Page 22: Disassembly And Assembly Instructions
8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 8.2. P.C.B. Location... -
Page 23: Disassembly Procedure
8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit and Front Case Unit Item Removal Rear Case Unit (Fig. D1) Card Front Case Unit Battery 2 Screws (A) 4 Screws (B) Bottom Ornament (Fig. D2) 6 Locking tabs Rear Case Unit Front Case Unit Sub Operation FPC (Fig. - Page 24 8.3.2. Removal of the Sub Operation FPC Unit/PCB Frame (Fig. D2) (Fig. D3)
- Page 25 8.3.3. Removal of the LCD Unit 8.3.4. Removal of the Top Operation Unit (Fig. D4) (Fig. D5)
- Page 26 8.3.5. Removal of the Flash Top P.C.B. and Speaker (Fig. D7) (Fig. D6)
- Page 27 8.3.6. Removal of the Lens Unit 8.3.8. Removal of the Sub Operation FPC Unit (Fig. D8) 8.3.7. Removal of the Main P.C.B. (Fig. D9) (Fig. D10)
- Page 28 8.3.9. Removal of the Battery Case (Fig. D12) 8.3.10. Removal of the Jack Door (Fig. D13) (Fig. D11)
- Page 29 8.3.11. Removal of the Battery Door Unit (Fig. D14) NOTE: (When Installing) Make sure to confirm the following points when installing: • The Screw is tightened enough. • Installing conditions are fine. (No distortion, no abnormal- space.) • No dust and/or dirt on Lens surfaces. •...
-
Page 30: Lens Disassembly Procedure
8.4. Lens Disassembly Procedure 8.4.1. Removal of the Zoom Motor and Lens FPC P.C.B. Unit Precaution: 1. Do not remove the CCD unit when disassembling or re- 1. Remove the Connector. assembling the lens in order to maintain it clean. 2. - Page 31 8.4.2. Removal of the Master Flange Unit 8.4.3. Removal of the Cam Frame Unit/ 1. Unscrew the 3 screws (C). Direct Frame/1st Lens Frame Unit/ 2. Remove the master flange unit. 2nd Lens Frame Move Unit 1. Push the cam frame unit from the lens front side in the direction of arrow, and then remove the unit of cam frame unit/direct frame/1st lens frame unit/2nd lens frame move unit from the fixed frame unit/drive frame unit/penetration...
- Page 32 8.4.4. Removal of the Direct Frame/1st 8.4.5. Removal of the 1st Lens Frame Lens Frame Unit/2nd Lens Frame Unit/2nd Lens Frame Move Unit Move Unit 1. Detach the shutter flex from 2 convexes of direct frame and pull it up. 1.
-
Page 33: Assembly Procedure For The Lens
8.4.6. Removal of the 2nd Lens Frame 8.5. Assembly Procedure for the Move Unit Lens 1. Remove the 2nd Lens frame move unit in the direction of 8.5.1. Phase alignment of the Drive Frame the arrow. Unit and Penetration Cam Frame Unit... - Page 34 8.5.2. Phase alignment of the Drive Frame 8.5.3. Install of the 2nd Lens Frame Move Unit/Penetration Cam Frame Unit Unit and Fixed Frame Unit...
- Page 35 8.5.4. Install of the 1st Lens Frame Unit/ 8.5.5. Phase alignment of the Direct 2nd Lens Frame Move Unit Frame/1st Lens Frame Unit/2nd Lens Frame Move Unit and Cam Frame Unit...
- Page 36 8.5.6. Phase alignment of the Cam Frame 8.5.7. Install of the Master Flange Unit Unit/Direct Frame/1st Lens Frame Unit/2nd Lens Frame Move Unit and Fixed Frame Unit/Drive Frame Unit/ Penetration Cam Frame Unit...
-
Page 37: Removal Of The Ccd Unit
8.5.8. Install of the Lens FPC P.C.B. Unit 8.6. Removal of the CCD Unit and Zoom Motor When remove the CCD unit once (the screw(E) is loosened even a little), the optical tilt adjustment is required. When loosen the screw(E), necessary the optical tilt adjustment at the end of assembling. -
Page 38: Removal Of The Focus Motor
8.7. Removal of the Focus Motor... -
Page 39: The Application Of Grease Method
8.8. Application Grease Method The grease application parts of lens unit are as follows. Apply grease additionally in the specified position if necessary. When the grease is applied, use a toothpick and apply thinly. • Focus motor (lead screw)/Fasten groove of nut/Guide pole - Grease: RFKZ0472 - Amount of application: 2 - 4 mg •... -
Page 40: Measurements And Adjustments
9 Measurements and Adjustments 9.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. Before disassembling the unit, it is recommended to back up the camera data stored in flash-rom as a data file. IMPORTANT NOTICE (After replacing the MAIN P.C.B.) After replacing the MAIN P.C.B., it is necessary to use the “DIAS”... - Page 41 9.2.2. Flash-Rom Data Backup When trouble occurs, it is recommended to backup the Flash-rom data before disassembling the unit. There are two kinds of Flash-rom data backup methods: [ ROM_BACKUP (Method of Non-PC backup) ] 1. Insert the SD-card into the camera. 2.
-
Page 42: Details Of Electrical Adjustment
9.3. Details of Electrical Adjustment 9.3.1. How to execute the Electrical Adjustment It is not necessary to connect the camera to a PC to perform adjustments. “Flag reset operation” and “Initial setting operation” are required when carrying out the alignment, follow the procedure below. 9.3.1.1. - Page 43 9.3.1.3. Execute Adjustment (In case of “OIS Adjustment”) 1. Perform step “9.3.1.1.” to “9.3.1.2.”, to reset the OIS flag status “F” (Set) to “0” (Reset) 2. Press [ MODE ] button after Flag reset. OIS Adjustment screen is displayed on the LCD panel. (Refer to Fig.3-3) 3.
- Page 44 9.3.2. Adjustment Specifications The following matrix table shows the relation between the replaced part and the Necessary Adjustment. When a part is replaced, make sure to perform the necessary adjustment(s) in the order indicated. The table below shows all the information necessary to perform each adjustment.
-
Page 46: After Adjustment
9.4. After Adjustment 9.4.1. Initial Setting Since the initial setting has been released to execute the built-in adjustment software, it should be set up again before shipping the camera to the customer. Refer to the procedure described in “3.5.2. INITIAL SETTINGS” for details. [ IMPORTANT ] 1. -
Page 47: Maintenance
10 Maintenance 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning KIT ;... - Page 48 Digital Camera 3.The voltage being indicated on the schematic diagram is measured in "Standard-Playback" mode when there is no specify mode is mentioned. Model No. DMC-FX70EB DMC-FX75P DMC-FX75GN 4.Although the voltage and waveform available on here is measured with standard frame, it may be differ from actual measurement due to modification of circuit and so on.
-
Page 49: S2. Voltage Chart
S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1. -
Page 50: S3. Block Diagram
S3. Block Diagram S3.1. Overall Block Diagram (24mm ~ 120mm) IC3001 CCD SIGNAL PROCESSOR X6001 (24MHz) 1/2.33" 14 MEGA PIX CDS, AGC, A/D, TG, CCD DRIVER ZOOM OIS UNIT IRIS SHUTTER FOCUS CARD IC3002,3003 REGULATOR MICROPHONE IC9101 SYSTEM IC IC9101 SYSTEM IC SPEAKER MOTOR DRIVE,... -
Page 51: S4. Schematic Diagram
S4. Schematic Diagram S4.1. Interconnection Diagram PS8001 FP8001 ET8001 FLASH TOP P.C.B. (COMPONENT SIDE) P8002 : (FOIL SIDE) ET8002 TOUCH PANEL LCD UNIT SPEAKER MICROPHONE BATTERY FP9001 CCD POWER CCD THERMO SUBSW1 V11A V13R V13L V12L V12R V11B FP9502 CCD GND CCDOUT CCD GND CCD GND... -
Page 52: S4.2. Sub Operation Schematic Diagram
S4.2. Sub Operation Schematic Diagram S9501 K0D112B00145 REC_PLAY_SW PLAY R9501 FRAME_GND K1MN04BA0162 FP9502 To Touch Panel TO MAIN BOARD FT9501 PW_BL_MINUS BL_MINUS PW_BL_MINUS PW_BL_VDD BL_PLUS PW_BL_VDD K1MN04BA0162 FRAME_GND FP9501 FRAME_GND To BackLight MENU MENU MODE MODE REC_PLAY_SW REC_PLAY_SW TP_XN TP_XN TP_YP TP_YP TP_XP... -
Page 53: S4.3. Flash Top Schematic Diagram
S4.3. Flash Top Schematic Diagram CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 2.0A 32V FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 2.0A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MÉME TYPE 2.0A 32V. GYRO_X(YAW) CL7304 CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,... -
Page 54: S4.4. Ccd Flex Schematic Diagram
S4.4. CCD Flex Schematic Diagram FT3101 CON_CHK CCD_GND CCD_GND 31 30 CCD_GND SUBSW2 SUBSW2 V11B MSUBSW MSUB MSUB MSUBSW MSUBSW V11B [29] MSUBSW CCD_GND [29] CCD_GND IC3101 R3107 CCD_OUT MN34571PBH-V 1300 CCD_GND [10] [20] SUBSW2 SUBSW1 SUBSW1 SUBSW2 R3101 12 13 14 15 V4 V4 R3108... -
Page 55: S4.5. Lens Flex Schematic Diagram
S4.5. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE IRB+ IRB+ IRB- IRB- DC SOLENOID (IRIS) IRA+ IRA+ SHUTTER UNIT IRA- IRA- DC SOLENOID (SHUTTER) YDR- DRIVE COIL (Y) XDR+ YDR+ DRIVE COIL (X) XDR- YHI- OIS UNIT YHO+ YHI+ HALL SENSOR (Y) YHO- TO MAIN XHI-... -
Page 56: S5. Print Circuit Board
S5. Print Circuit Board S5.1. Sub Operation Flex P.C.B. C9701 C9702 IC9701 (Foil Side) DMC-FX70/FX75 Sub Operation Flex P.C.B. -
Page 57: S5.2. Flash Top P.c.b
S5.2. Flash Top P.C.B. VA8001 CL8008 CL8005 R8003 F8001 34 30 LB8001 C8001 R8013 F8021 PS8001 CL8202 C8007 FP8001 CL8011 CL8002 RL8003 CL8201 L8001 IC8100 CL8006 TL8007 D8001 CL8004 R8037 R8038 P8002 CL8003 (Component Side) ET8003 ET8001 C8014 VA8003 VA8006 S8002 ET8004 RL8002... -
Page 58: S5.3. Ccd Flex P.c.b
S5.3. CCD Flex P.C.B. (Component Side) C3101 Q3101 6 5 4 R3107 R3101 IC3101 (Foil Side) DMC-FX70/FX75 CCD Flex P.C.B. S-11... -
Page 59: S5.4. Lens Flex P.c.b
S5.4. Lens Flex P.C.B. ZOOM MOTOR UNIT SHUTTER UNIT ZOOM ENCODER 1 C3/D1 ZOOM ENCODER 2 CO. BARREL ENCODER (FULL RETRACT) Pin 1 OIS UNIT Pin 45 FOCUS MOTOR UNIT DMC-FX70/FX75 LENS FLEX P.C.B. S-12... -
Page 60: S6. Replacement Parts List
ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES section. Definition of Parts supplier: 1. Parts marked with [ENERGY] in the remarks column are supplied from Panasonic Corporation Energy Company. 2. Parts marked with [PAVCSG] in the remarks column are supplied from PAVCSG. - Page 61 DMC-FX70EG-S Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP56110A MAIN P.C.B. 1 EXCEPT EG,EP,EF,EB T8001 G5D1A0000080 TRANSFORMER 1 [PAVCSG] (RTL) E.S.D. VEP56110B MAIN P.C.B. 1 EG,EP,EF,EB (RTL) E.S.D. VEP50066A SUB OPERATION FPC UNIT 1 (RTL) E.S.D.
- Page 62 DMC-FX70EG-S Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ML-421S/ZTK BUTTON BATTERY 1 [ENERGY] (B9101) VHD1876 SCREW VEP56110B MAIN P.C.B. 1 EG,EP,EF,EB (RTL) E.S.D. VHD1876 SCREW VEP56110A MAIN P.C.B. 1 EXCEPT EG,EP,EF,EB VHD2239 SCREW (RTL) E.S.D.
- Page 63 DMC-FX70EG-S Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPF1317 CAMERA BAG 1 P,PU DE-A59BB BATTERY CHARGER 1 P,PU ----- BATTERY 1 P,PU K1HA08AD0002 USB CABLE W/PLUG 1 P,PU K1HA08CD0028 AV CABLE W/PLUG 1 P,PU VFC4297 HAND STRAP...
- Page 64 DMC-FX70EG-S Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VQC7833 O/I SOFTWARE 1 GD VPF1317 CAMERA BAG 1 EXCEPT P,PU (KOREAN) DE-A60AA BATTERY CHARGER 1 EG,EP,EF,EB,GN VPK4513 PACKING CASE 1 EG-S,SG-S DE-A60BB BATTERY CHARGER 1 EE,GC,GH,GK,GD VPK4518...
-
Page 65: S7. Exploded View
S7. Exploded View S7.1. Frame and Casing Section 51-3 51-2 51-1 B101 B102 B103 B107 B109 B108 104-1 108-3 B112 70-1 B110 108-1 B105 B111 70-2 B106 108-2 S-18... -
Page 66: S7.2. Packing Parts And Accessories Section (1
S7.2. Packing Parts and Accessories Section (1) In the case of DMC-FX75PU, stick the Ref.No.225 (NTSC LABEL) to printed “PAL” of the packing case. S-19... -
Page 67: S7.3. Packing Parts And Accessories Section (2
S7.3. Packing Parts and Accessories Section (2) (DMC-FX70EE/EF/EG/EP DMC-FX75GC/GD) (DMC-FX70EB DMC-FX75GC/GH) (DMC-FX70SG DMC-FX75GK/GT) (DMC-FX75GN) In the case of DMC-FX75GT/GD, stick the Ref.No.325 (NTSC LABEL) to printed “PAL” of the packing case. S-20...
