Sauder Harbor View 158002 Manual

Lateral file
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Lateral File
Harbor View Collection | 158002
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Get all organized
and stuff .
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-20
Français pg 21-24
Español pg 25-28
Lot # 376082
08/27/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Harbor View 158002 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Harbor View 158002

Summary of Contents for Sauder Harbor View 158002

  • Page 1 Harbor View Collection | 158002 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 RIGHT MOLDING (1) TOP (1) D256 RIGHT DRAWER SIDE (1) LEFT MOLDING (1) SHELF (1) LEFT DRAWER SIDE (1) END MOLDING (2) BOTTOM (1) D729 DRAWER BOTTOM (1) M63 DRAWER BRACE (1) BACK (1) BASE (1) Page 2 158002 www.sauder.com/services...
  • Page 3 Now you know Part Identifi cation our ABCs. D256 D729 www.sauder.com/services 158002 Page 3...
  • Page 4 FASTENER - 17 MOLDING FRONT FILE REAR FILE METAL BRACKET - 7 CONNECTOR - 2 BRACKET - 1 BRACKET - 1 GG KNOB - 2 RR SLIDE CAM - 2 RUBBER SLEEVE - 8 METAL PIN - 8 Page 4 158002 www.sauder.com/services...
  • Page 5 BLACK 7/8" FLAT HEAD SCREW - 7 BLACK 9/16" LARGE HEAD SCREW - 14 BROWN 7/16" LARGE HEAD SCREW - 5 PP GOLD 5/16" FLAT HEAD SCREW - 8 NAIL - 26 30S BLACK 1-9/16" FLAT HEAD SCREW - 5 www.sauder.com/services 158002 Page 5...
  • Page 6 Assemble your unit on a carpeted fl oor or on the empty carton to å avoid scratching your unit or the fl oor. To begin assembly, push a SAUDER TWIST-LOCK® FASTENER (Y) å into the large holes in the ENDS (A and B). Repeat this step for the UPRIGHT (C), SHELF (E), and BOTTOM (F).
  • Page 7 Tap two MOLDING CONNECTORS (EE) into the notches å in the MOLDINGS (P, Q, and R). Use your hammer to tap the MOLDING CONNECTORS (EE) into the notches in the MOLDINGS. Flat end Unfi nished surface Flat end Unfi nished surface www.sauder.com/services 158002 Page 7...
  • Page 8 Fasten the MOLDINGS (P, Q, and R) to the TOP (D). Use å seven BLACK 7/8" FLAT HEAD SCREWS (31S). Remember: Righty tighty. Lefty loosey. BLACK 7/8" FLAT HEAD SCREW (7 used in this step) Finished surface Finished surface Long fi nished edge Page 8 158002 www.sauder.com/services...
  • Page 9 Push the black lever in and pull the SLIDE from the RAIL. Unfi nished edge GOLD 5/16" FLAT HEAD SCREW (4 used for the RAILS) Use this hole. (6 used) Unfi nished edge BLACK 9/16" LARGE HEAD SCREW (6 used for the METAL BRACKETS) www.sauder.com/services 158002 Page 9...
  • Page 10 Step 5 Fasten the LEFT END (B) to the LEFT MOLDING (R). å ® How to use the SAUDER TWIST-LOCK FASTENER Tighten two TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
  • Page 11 - L O F A S ® T E N f a c ® S u r - L O E R S I S T E R S T E N F A S www.sauder.com/services 158002 Page 11...
  • Page 12 (8 used in this step) of the BOTTOM. Fasten the BASE (N) to the ENDS (A and B) and BOTTOM (F). Use å three BLACK 9/16" LARGE HEAD SCREWS (NN) through the METAL BRACKETS and into the BASE. Page 12 158002 www.sauder.com/services...
  • Page 13 Then, insert the metal end of a CAM DOWEL (2F) into the HIDDEN CAM. Do not tighten the HIDDEN CAM in this step. Arrow Insert the metal end of the CAM Arrow DOWEL into the HIDDEN CAM. www.sauder.com/services 158002 Page 13...
  • Page 14 Fasten the DRAWER BACK (D61) to the DRAWER Fasten the DRAWER BRACE (M63) to the å å SIDES (D88 and D256) and DRAWER BRACE (M63). Use DRAWER FRONT (I). Tighten one HIDDEN CAM. five BLACK 1-9/16" FLAT HEAD SCREWS (30S). Page 14 158002 www.sauder.com/services...
  • Page 15 SLIDE. Open end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES D256 Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 158002 Page 15...
  • Page 16 Fasten the LOCK BRACKET (BB) to the RIGHT DRAWER SIDE (D256). å Use a BROWN 7/16" LARGE HEAD SCREWS (OO). BROWN 7/16" LARGE HEAD SCREW (5 used for the BRACKETS) D256 BLACK 1-1/8" PAN HEAD SCREW (2 used for the KNOBS) Use the oblong hole. Page 16 158002 www.sauder.com/services...
  • Page 17 FILE BAR (V2), and into the FILE GLIDE (W) on the RIGHT DRAWER SIDE (D256). Slide another FILE GLIDE (W) onto the other ends of the å FILE RODS (X2), then press this FILE GLIDE over the LEFT DRAWER SIDE (D88). D256 www.sauder.com/services 158002 Page 17...
  • Page 18 NOTE: Be sure the metal bar on the LOCK is facing the å direction shown. Push the LOCK COVER (AA) over the key extension on å the LOCK. SILVER 3/4" PAN HEAD SCREW (2 used in this step) Metal bar Page 18 158002 www.sauder.com/services...
  • Page 19 Peel two FELT DISC from the FELT DISC CARD (1M) and stick them on the å DRAWER FRONT where it comes into contact with the ENDS (A and B). 50 lbs. 20 lbs. (8 used) 20 lbs. 40 lbs. total 50 lbs. www.sauder.com/services 158002 Page 19...
  • Page 20 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 20 158002 www.sauder.com/services...
  • Page 21 EXTRÉMITÉ DROITE ..........1 TRINGLE POUR DOSSIERS ........2 pour future référence. EXTRÉMITÉ GAUCHE ..........1 ARMATURE POUR DOSSIERS ......2 Pour contacter Sauder MONTANT................1 TIGE DE DOSSIER ............2 en ce qui concerne cet élément, faire référence DESSUS ................1 FIXATION TWIST-LOCK® ........17 au numéro de lot et...
  • Page 22 Fixer l'EXTRÉMITÉ GAUCHE (B) à la MOULURE GAUCHE (R). Serrer deux FIXATIONS TWIST-LOCK®. Pour commencer l'assemblage, enfoncer une FIXATION TWIST-LOCK® SAUDER (Y) dans les gros trous des Fixer le MONTANT (C) sur le DESSUS (D). Serrer deux EXTRÉMITÉS (A et B). Répéter cette étape pour le FIXATIONS TWIST-LOCK®.
  • Page 23 REMARQUE : Des lignes perforées ont été prévues pour accéder facilement à l'ARRIÈRE. Découper avec précaution les trous nécessaires. Enfoncer une EXCENTRIQUE ESCAMOTABLE (1F) dans l’ENTRETOISE DE TIROIR (M63). Ensuite, insérer l'extrémité en métal de la CHEVILLE D'EXCENTRIQUE (2F) dans l'EXCENTRIQUE ESCAMOTABLE. www.sauder.com/services 158002 Page 23...
  • Page 24 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. Page 24 158002 www.sauder.com/services...
  • Page 25 VARILLA DE ARCHIVERO ........2 EXTREMO IZQUIERDO ..........1 pour future référence. SUJETADOR TWIST-LOCK® ......17 PARAL ...................1 Pour contacter Sauder en ce qui concerne cet CERRADURA ..............1 PANEL SUPERIOR ............1 élément, faire référence CUBIERTA DE CERRADURA ........1 ESTANTE ................1 au numéro de lot et...
  • Page 26 Apriete dos SUJETADORES TWIST-LOCK®. Para comenzar el ensamblaje, empuje un SUJETADOR TWIST-LOCK® SAUDER (Y) en los agujeros grandes de los Fije el PARAL (C) al PANEL SUPERIOR (D). Apriete dos EXTREMOS (A y B). Repita este paso para el PARAL (C), el SUJETADORES TWIST-LOCK®.
  • Page 27 GRANDE de 11 mm (OO). DORSO. Cuidadosamente corte los agujeros necesarios. Empuje un EXCÉNTRICO ESCONDIDO (1F) en la RIOSTRA DE CAJÓN (M63). A continuación, inserte el extremo de metal de un PASADOR DE EXCÉNTRICO (2F) dentro de EXCÉNTRICO ESCONDIDO. www.sauder.com/services 158002 Page 27...
  • Page 28 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 28 158002 www.sauder.com/services...
  • Page 29 Les téléviseurs peuvent être très un téléviseur. téléviseur. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 158002 Page 29...
  • Page 30 Además, soportar un televisor. diseñadas para soportar un televisor. el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 30 158002 www.sauder.com/services...
  • Page 31 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
