Motorhome
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Greyhawk and is the answer not in the manual?

Questions and answers

Novak
March 1, 2025

In my 2002 Jayco granite Ridge motor home were is my breaker panel

User image 67c2931ecbf83
Jim Priest
March 22, 2025

where is the electrical panel located in my 2006 Greyhawk 29gs

1 comments:
Mr. Anderson
March 22, 2025

The electrical panel in a 2006 Jayco Greyhawk 29GS is located inside the motorhome door at the end of the upper cabinet behind a smoke glass door.

This answer is automatically generated

Summary of Contents for Jayco Greyhawk

  • Page 1 Where Tradition Model Year 2003 and Innovation Meet... Motorhome Owner’s Manual...
  • Page 2 Nothing in this manual creates any warranty, either expressed or implied. The only warranty offered by Jayco, Inc. is as set forth in the limited warranty applicable to this vehicle.
  • Page 3 YOUR NEW JAYCO IS YOUR PASSPORT TO A WHOLE WORLD OF NEW FRIENDS, CAMPING FUN AND TRAVEL ADVENTURE WHEN YOU JOIN THE THOUSANDS OF JAYCO FAMILIES WHO MAKE UP THE . . . JAYCO JAFARI INTERNATIONAL TRAVEL CLUB You will find us enjoying the friendship and fellowship of JAFARI CAMPING as we join our local area FLIGHTS at hundreds of weekend camp-outs all over North America each month .
  • Page 4 TO: Membership Coordinator for the Jayco Jafari International Travel Club Please enroll us as members in the Jayco Travel Club. We are ready to roll to where the “friends we just haven’t met yet” have the coffee on the fire and are waiting for us to arrive: We are ...
  • Page 5: Table Of Contents

    TABLE OF CONTENTS Chapter 1 Introduction To RV Ownership ......1 Welcome ..........1 Safety Considerations .
  • Page 6 Chapter 4 The Systems........27 Plumbing System .
  • Page 7 Power Center ........54 AC Distribution Center .
  • Page 8 Interior Care ......... . 88 Refrigerator .
  • Page 9: Chapter 1 Introduction To Rv Ownership

    Thank you for purchasing your Jayco Recreation Vehicle and welcome to the world of recreation vehicle travel. Your purchase of a Jayco RV allows you to enter this unique world of camping and leisure in a grand style. Your Jayco RV has been designed and engineered to offer you many comforts of home that will make your camping experience as enjoyable as possible.
  • Page 10: Safety Considerations

    If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer or Jayco, Inc. NHTSA Customer Relations Dept.
  • Page 11: Electrical System Safety

    WARNING: For traveling safety, it is extremely important to read and understand the towing, hitching and loading cargo information provided in Chapter 3. If you do not understand the information provided, please consult your dealer or Jayco owner representative. • Sanitize the fresh water supply system periodically (see sanitizing instructions).
  • Page 12: Insurance

    • Ensure that tires are in good condition and properly inflated. Proper inflation should be monitored closely. Neglecting to do so could result in overheating of a tire, which could result in a blowout. • Check and tighten wheel lugs regularly, according to your chassis owner’s manual recommendations.
  • Page 13: Condensation

    CONDENSATION Condensation is a natural phenomenon. The amount of condensation will vary with the climate conditions, particularly the relative humidity. Condensation occurs because there is water vapor present in the air, which each of us adds by breathing, bathing and cooking. The water vapor collects where there is available air space, and when the temperature reaches the 'dew point' the water vapor in the air condenses and changes to liquid form.
  • Page 14: Chapter 2 Obtaining Service

    Chapter 2 OBTAINING SERVICE WARRANTY REGISTRATION Type C Owner’s Manual...
  • Page 15 Obtaining Service...
  • Page 16: Service Procedures

    Jayco. In most cases, the dealer can provide the service you require. If you are traveling and are unable to locate an Independent Jayco dealer, or an authorized dealer for the component needing service, please call our customer service office at 1-877-825-4782 or 1-574-825-0608 or contact your selling dealer for assistance.
  • Page 17: Dealer

    Please be prepared accordingly. Parts Parts are available at most Jayco dealerships or your dealer can order parts for you as needed. All retail parts inquiries should be routed through your dealer. If you are unable to find a dealer in your local area, contact our Customer Service Department at 1-877-825-4782 or 1-574-825-0608 and we will assist you in providing parts through an authorized dealer.
  • Page 18: Chapter 3 Operating And Using Your Type C Motorhome

    Located on the post of the driver's door is a "Federal Certification" label supplying a portion of this information. Fig. 3-1 MANUFACTURED BY: JAYCO, INC. DATE FABRIQUÉ PAR: INC. VEHICLE MFG. BY: VÉHICULE FABRIQUÉ PAR: V.I.N./N.I.V.
  • Page 19 MOTORHOME WEIGHT INFORMATION SERIAL # MODEL (GROSS VEHICLE WEIGHT RATING) MEANS THE MAXIMUM GVWR PERMISSIBLE WEIGH OF THIS FULLY LOADED MOTORHOME. (UNLOADED VEHICLE WEIGHT) MEANS THE WEIGHT OF THIS MOTORHOME AS MANUFACTURED AT THE FACTORY WITH FUEL ENGINE OIL, AND COOLANTS. (SLEEPING CAPACITY WEIGHT RATING) MEANS THE DESIGNATED SCWR NUMBER OF SLEEPING POSITIONS MULTIPLIED BY 154 LBS (70 KG).
  • Page 20: Hitch - See Chapter 7 "Options

    Weight labels are posted inside a cabinet door inside all Jayco RV's so you can make a decision before you buy about how much cargo capacity is important for you personally.
  • Page 21: Loading Cargo

    LOADING CARGO WARNING: For traveling safety, it is important to make sure that tie down straps are secured on all appliances such as the television, coffee maker, etc. Vibration caused during travel will move the appliances creating the potential for them to fall out of their cabinets possibly causing injury.
  • Page 22: Weighing Instructions

    WARNING: PROPER ATTENTION MUST BE TAKEN FOR CARGO LOADING AND DISTRIBUTION TO ASSURE TRAVELING SAFETY. 1. LOAD ALL CARGO EVENLY FROM SIDE TO SIDE. 2. SECURE ITEMS PREVENT LOAD SHIFTS DURING TRANSIT. 3. AFTER LOADING, WEIGH THE MOTORHOME AT EACH AXLE AND EACH WHEEL.
  • Page 23: Tires

    2. SEGMENTED PLATFORM - Platform scales with segmented sections can provide individual axle weights and total vehicle weights simultaneously, when the vehicle is positioned properly. Position the vehicle on the scales so that each axle is centered as much as possible on separate segments, and record the weight.
  • Page 24: Wheel Lugs

    WHEEL LUGS Ensure that wheel lugs are tight as specified in the chassis manual. When your vehicle is new or a tire has been removed for any reason, re-torque the lug nuts at 10, 25 and 50 miles (15, 40 and 100 kilometers) and every 3,000 miles (5000 kilometers) thereafter.
  • Page 25: Tv Antenna

    TV ANTENNA Raising Antenna to Operating Position Turn the elevating crank clockwise in the UP direction about thirteen turns or until some resistance to turning is noted. (Fig. 3-5) On Amplified models, 12-Volt DC power is required. Turn the power supply ON to use either the front or rear TV outlet.
  • Page 26: Seat Belts

    SEAT BELTS Three-point shoulder harnesses and lap belts are provided at the front driver and passenger seats by the chassis manufacturer. See the chassis manual for operating instructions. For the recreation vehicle section, the dinette, sofa, and barrel chairs have a two-point lap seat belts installed.
  • Page 27: Procedures To Take During An Alarm

    Procedures to Take During an Alarm WARNING: The activation of the CO detector is a warning that indicates the presence of carbon monoxide! WARNING: Do not disconnect the CO detector to silence the alarm. The detector is designed to sense when the level of CO in the air falls below the danger level. All individuals should remain outside the unit until the alarm is silent.
  • Page 28: Slideout Room Option

    SLIDEOUT ROOM OPTION The slideout is designed for additional floor space and comfort. Mechanical components are gear driven and produced by the Power Gear Company. Read ALL instructions in the next few pages before operation to become familiar with your slideout system. CAUTION: Do not place excessive weight in the slideout room.
  • Page 29: Operations

    set up correctly. The corners of this seal are cut at a 45° angle. The top of the seal must overlap the side of the seal to avoid the possibility of water penetration. (Fig. 3-8) Fig. 3-8 Operations IMPORTANT SLIDEOUT INSTRUCTIONS •...
  • Page 30: Overriding The Motorhome Slideout System

    WARNING: For models with a slideout front facing dinette seat, confirm that the tie down strap is installed correctly prior to travel. CAUTION: IMPORTANT! Never store the slideout without the transit bars installed. This helps seal the slideout in the closed position. MOUNTING BRACKETS OUTER RAIL ASSEMBLY MANUAL...
  • Page 31 Install the transit bars and tie down strap (if applicable) and take the unit to a Jayco dealer for service. BEDROOM / MOTORHOME MOTOR MAIN ROOM MOTOR WITH BRAKE LEVER ROTATE TO ROTATE TO RELEASE BRAKE RELEASE BRAKE BEDROOM MOTOR WITHOUT BRAKE LEVER Fig.
  • Page 32 TROUBLESHOOTING ELECTRIC SLIDEOUT If the slideout does not move when the slideout switch is depressed follow these steps: 1. Check the battery for a full charge and good wire connections. 2. Check for loose connections on the slideout motor. 3. Make sure the motorhome master battery switch is on. If the slideout still does not move when the slideout switch is depressed follow these steps: 1.
  • Page 33: Setup For Camping

    If the slideout extends crooked or only one side moves follow these steps: 1. Follow steps 1-4 of the section on overriding the slideout system to disconnect the motor. 2. Retract the slideout using the manual override. You may need to push on the side that is not sliding to get it to retract all the way.
  • Page 34: Storing Your Motorhome

    TL Enterprises (Trailer Life, Motorhome, etc.) can offer you additional, practical advice on the proper storage of your vehicle. Damage from rodents or insects are NOT covered under your Jayco Limited Warranty. Type C Owner’s Manual...
  • Page 35: The Systems

    Chapter 4 THE SYSTEMS PLUMBING SYSTEM Your motorhome contains a complete fresh water system. The components of the system include water tanks, water fill connections, demand pump, faucets, etc. Depending on your model, the water system may be one of the following: •...
  • Page 36 CAUTION: Do not leave the tank unattended while filling. You must be careful not to over fill the tank. This can pressurize the tank, causing leakage and water damage. Fig. 4-2 - Utility Center Components To outside shower head SANITIZE NORMAL TANK NOTE: THIS SETTING CAN ALSO BE...
  • Page 37: Full Basement Models

    FULL BASEMENT MODELS: • Connect a garden hose to "Fresh Water Connection" (Fig. 4-3D) inside the utility center. • Move the "Fill Water Tank Handle" (Fig. 4-3B) to the "Fill Water Tank Position" (Fig. 4-3A). • Open the valve on the water supply line. •...
  • Page 38: Non-Basement Models

    NON-BASEMENT MODELS The water pump and valve connections for non-basement vehicles, are typically located under the bathroom vanity and/or the dinette seat. The pictures for the following instructions show the layout of the valves, not their locations in the vehicle. Depending on which non-basement model you have, one of the following Fig.
  • Page 39: 12-Volt Demand Pump

    12-Volt Demand Pump When water is desired and you are not hooked up to city water, you need to use the 12-volt pump to get water from the fresh water tank. You will find the switch for the pump on the monitor panel or a wall near the pump.
  • Page 40: Outside Shower (Option On Some Models)

    Outside Shower (Option on some models) A convenient faucet assembly with hot and cold water is available for exterior use washing or rinsing on the outside of the motorhome. (Fig. 4-7 - non-basement models) For full basement models, the outside shower is located with the other controls. OPERATION 1.
  • Page 41: Utility Center (Manifold)

    Fig. 4-9 - Utility Center Components To outside shower head SANITIZE NORMAL TANK NOTE: THIS SETTING CAN ALSO BE USED TO FILL THE FRESH WATER CITY TANK FROM AN EXTERNAL CONTAINER. WATER ANTIFREEZE/ CITY TANK SANITIZE FILL LINES PLEASE REFER TO YOUR OWNER'S MANUAL FOR DETAILS OF MANIFOLD OPERATION. 1.
  • Page 42: Full Basement Models

    14. Open kitchen and bathroom faucets to allow air to escape the water lines and the water heater. 15. Turn the “Water Pump Switch” (Fig. 4-9 - #3) to the “ON” position and allow several seconds for the pump to prime. 16.
  • Page 43: Non-Basement Models

    14. Connect garden hose to the “Fresh Water Inlet” and add water until the tank is 1/2 - 3/4 full. (Fig. 4-10E) 15. If possible, drive the vehicle to allow the solution to agitate in the tank. 16. Fill the remainder of the tank with water. Open kitchen and bathroom faucets to allow air to escape the water lines and the water heater.
  • Page 44 7. Fill the remainder of the tank. Open the kitchen and bathroom faucets to allow air to escape the water lines and the water heater. Model 23RK: Make sure valves 1, 2, 3, and 5 are closed and valve 4 is open.(Fig. 4-12 & 4-13) Model 24SS: Make sure valves 1, 2, 5 and 6 are closed and valves 3 and 4 are open.
  • Page 45: Bath And Shower

    Bath and Shower Your bathroom facilities function similar to those in your home. Prepare your bath or shower curtains to prevent water from spilling onto the floor. Be sure the water heater is in operation before bathing. Adjust the faucets for desired temperature before entering the tub or shower. The shower heads are equipped with a vacuum breaker to prevent pressure buildup.
  • Page 46: Water Purification System (Option)

    WATER PURIFICATION SYSTEM (OPTION) A water purification system may be installed as an option on your trailer. This system is equipped with a long-life cartridge to effectively reduce chlorine taste, odor, sediment, organic chemicals and inhibit bacteria growth. If the water system has not been used for some time, allow water to flow for several minutes to flush the system.
  • Page 47: Sanitation System

    SANITATION SYSTEM Toilets Two types or models of toilets are used in Jayco motorhomes. One is the Starlight/Galaxy model featuring two foot pedals for flushing. The second type, the Aqua Magic 4, features two levers on the back side to flush the toilet.
  • Page 48: Vents

    Vents Another important part of the sanitation system are the vents which release air from tanks. Each tank has a vent pipe built into the cabinet, wall and roof. A vent cap is attached to the roof and must be clear of obstructions to perform as intended.
  • Page 49: Gray Water Holding Tank

    GRAY WATER HOLDING TANK No special preparation is required. However, placing a small quantity of chemicals into this tank, such as baking soda or a Thetford chemical, will reduce odors from food particles in the system. WARNING: We recommend that you DO NOT travel with full holding tanks. Full holding tanks are not calculated into the cargo carrying capacity of your motorhome.
  • Page 50: Using The Water System During Freezing Weather

    Preparing your recreation vehicle for winter is very important for most states and Canada. Failure to prepare the motorhome will cause supply lines and water heater to freeze causing breakage. Repairs due to freezing are not to be covered under the terms of your Jayco Limited Warranty. WARNING: Do not use Ethylene Glycol (automotive antifreeze) or Methanol (windshield washer antifreeze) in your fresh water system.
  • Page 51: Full Basement Models

    Full Basement Models NON-UTILITY CENTER 1. Drain the water tank and water heater completely by turning all faucets on until tank and heater are empty. 2. Open the low point drain valves located in the utility center. When water stops flowing out of them, close the valves.
  • Page 52: Utility Center

    UTILITY CENTER Fig. 4-30 - Utility Center Components To outside shower head SANITIZE NORMAL TANK NOTE: THIS SETTING CAN ALSO BE USED TO FILL THE FRESH WATER CITY TANK FROM AN EXTERNAL CONTAINER. WATER CITY ANTIFREEZE/ SANITIZE TANK LINES FILL PLEASE REFER TO YOUR OWNER'S MANUAL FOR DETAILS OF MANIFOLD OPERATION.
  • Page 53: Non-Basement Models

    Non-Basement Models Two methods of winterizing your motorhome after draining and flushing the system are listed below. USING THE WATER HEATER BYPASS The water heater bypass is available on most 1 & 2 - Low Point Drains 5 - Tank Outlet vehicles.
  • Page 54: The Lp Fuel System

    THE LP FUEL SYSTEM It is because of the LP gas system that your RV has the convenience of a refrigerator, stove, water-heater, and furnace. This system has a tank that contains the fuel and also regulators to control the pressure of the fuel and supplies the gas vapor to the various appliances. When correctly used, the LP system is very effective and will ensure the comfort and added convenience for your vehicle.
  • Page 55 DANGER: ALL PILOT LIGHTS, APPLIANCES AND THEIR IGNITORS (SEE OPERATING INSTRUCTIONS) SHALL TURNED BEFORE REFUELING OF MOTOR FUEL TANKS AND/OR LP GAS CONTAINERS. FAILURE TO COMPLY COULD RESULT IN DEATH OR SERIOS INJURY. A warning label has been located near the LP gas tank. This label reads: WARNING: THIS GAS PIPING SYSTEM IS DESIGNED FOR USE OF LIQUEFIED PETROLEUM GAS ONLY.
  • Page 56: Fuel Distribution Components

    WARNING: Never smoke while filling the LP tanks. When an LP tank is low, occasionally there is a concentration of garlic-like odor which may be mistaken for a gas leak. After a change over to a full tank, the odor usually will disappear. If not, turn off the valve of the LP gas tank and have the system checked by a qualified technician.
  • Page 57: Checking For Leaks

    OPERATION After the camper is completely set up and you are prepared for camping enjoyment, follow these steps for LP gas operation. 1. Close all burner valves, controls and pilot light valves. 2. Open the main valve on the LP gas tank slowly to avoid a fast rush of propane vapor through the excess flow valve causing a "gas freeze."...
  • Page 58: Lp Gas Consumption

    WARNING: IT IS NOT SAFE TO USE THE COOKING APPLIANCE FOR COMFORT HEATING. 1. Cooking appliances need fresh air for safe operation. Before operation: a. Open overhead vent or turn on exhaust fan. b. Open window. 2. Unlike homes, the amount of oxygen supply is limited due to size of the recreation vehicle, and proper ventilation when using the cooking appliances (s) will avoid dangers of asphyxiation.
  • Page 59: Lp Detector

    LP DETECTOR Any recreation vehicle which contains an LP fuel system with propane consuming appliances requires a propane leak detection device for safety protection. A converter or auxiliary battery is required to supply 12-volt DC energy to operate leak detector. Operation Power ON Warm Up: When power is first applied the yellow LED will flash for three minutes while the detector is warming up.
  • Page 60: Alarm Mute

    ALARM MUTE This feature is activated by pressing the TEST/MUTE button when the detector is in alarm. 1. The red LED will continue to flash and the alarm will beep every thirty seconds until the gas level has dropped to a safe level. 2.
  • Page 61: Electrical System

    Damage from power surges are not covered by your Jayco Warranty. Consult the component manufacturer’s owner’s manual or your Independent Jayco Dealer for recommendations on power surge protection. Changes, Modifications and Additions Any changes or additions made to a finished and delivered motorhome may cause a hazardous condition.
  • Page 62: Power Center

    Power Center Your motorhome is equipped with a power center that includes 120-volt breakers, 12-volt fuses, and battery charging capability. Your motorhome is also equipped with a transfer switch that automatically switches between generator power and external power. AC Distribution Center When 120-volt AC is connected to power center through commercial power or AC generator, the 120-volt AC circuits are protected by the breakers contained in the AC panel board.
  • Page 63 120-VOLT AC The diagram below for the 120-volt AC layout. Fig. 4-30 120-volt AC Layout A - Main D - Kitchen, Bath, Outside B - Converter/Utility E - Microwave C - Air Conditioner F - Electric Water Heater 12-volt DC Layout 1 - Bath 7 - Optional 2 - Pump...
  • Page 64: 12-Volt Dc (Direct Current) System

    Replaceable fuses are used to protect the 12-volt DC components. If fuses continue to blow, it is an indictation that a circuit is overloaded or there is a “shorted circuit.” Contact your Independent Jayco dealer for assistance. A separate 12-volt fuse panel supplies power to your chassis. Consult the chassis manual for assistance.
  • Page 65: Isolators

    Energy in the tow vehicle battery is now preserved and can be used to start your engine if needed. The Jayco motorhome has a solenoid located on the cowl of chassis under the hood. Master Battery Switch Located near the motorhome entrance door there is a master battery switch.
  • Page 66: Inverter

    Refer to the manufacturer’s owner’s manual for complete operating instructions or consult with your Independent Jayco dealer. Dome Lights for Cab These lights are wired directly to the chassis wiring. Operation for these lights is the headlight switch or the button switches located in the driver and passenger doors.
  • Page 67: Light Bulb Chart

    Light Bulb Chart BULB # Tail Light 1157 Turn Signal 1157 Backup 1156 Porch Light, Power Hood Light Interior Light Clearance Light Refrigerator (900 series only) Generator (Option) This generator will produce 120-volt power when camping in an area where shore power is not available.
  • Page 68: Chapter 5 Appliances

    All appliances in your Jayco recreation vehicle are name brand quality built equipment, guided by current code and standards. For gas operation, the appliances in your motorhome will operate on LP gas only, not on natural gas.
  • Page 69: Furnace

    FURNACE WARNING: This appliance does not have a pilot. It is equipped with an ignition device which automatically lights the burner. DO NOT try to light the burner by hand. The furnace requires both 12-volt and LP gas energy for full operation. The combustion system is fully sealed.
  • Page 70: How To Turn Off Electrical Power

    How to Turn off Electrical Power 1. Set the thermostat to lowest setting. 2. Open the furnace exterior door and turn OFF electric switch or circuit breaker. 3. Close the furnace exterior door. WARNING: CARBON MONOXIDE POISONING / FIRE / EXPLOSION •...
  • Page 71 CAUTION - PRODUCT DAMAGE DO NOT allow flue gas exhaust to have extended contact with the exterior sidewall of the recreation vehicle. It will cause the material to degrade over time. Exhaust tube and furnace chamber tube must overlap no less than 1-1/4” and be positioned against the door screen for proper function.
  • Page 72: Ducting And Return Air

    CAUTION: BURN INJURY • DO NOT touch exterior exhaust grille, when furnace is operating. • Supervise young children in the same room as the furnace. Ducting and Return Air All heat discharges, registers and return air grills must be free and clear of obstructions. Obstructions will prevent the furnace from performing correctly.
  • Page 73: Top Burner Operation

    Top Burner Operation WARNING: • Use range or cooktop only for use as described in the manufacturer’s manual. • Do not leave children alone or unattended in area where range or cooktop is in use. Never allow anyone to sit, stand, or climb on any part of the range cooktop.
  • Page 74 WARNING: • Use care when lighting a top burner by hand. If the burner lights unexpectedly, or your hand is close to the burner, you may be burned. • Burner flame should not extend beyond the edge of the cooking utensil. The flame could burn you and cause poor cooking results.
  • Page 75: Oven Operation

    SETTING RECOMMENDED USE LITE • To light the burner • To start foods cooking • To bring liquids to a boil • To hold liquids at a boil • To fry chicken or pancakes • To cook large amounts of vegetables •...
  • Page 76 NOTE: Check that gas is on at shutoff valve. LIGHTING THE OVEN PILOT: a. Push in oven control knob (Figure 5-3A) and rotate counter-clockwise to PILOT ON. b. Light oven pilot (Figure 5-3C) located near the back of the oven, under the broiler shelf (Figure 5-3B) and to the left of the oven burner (Figure 5-3D).
  • Page 77: Water Heater

    WATER HEATER Several options are available in the water heater appliances. (1.) 6 or 10 gallon capacities, depending on floor plan. (2.) Three types of energy, LP gas only, LP gas and 120-volt combination, and 12-volt/LP gas combination with 110-volt. Water temperature is adjustable on pilot and 120-volt models, but not on combination unit.
  • Page 78 PILOT OPERATION 1. Turn gas control valve knob (Fig. 5-4B or 5-5B) to "OFF" position. 2. Wait at least five minutes to allow accumulated gas in burner compartment to escape. 3. Water heater may be equipped with either a "White Rodgers" or Robertshaw "Unitrol" Control.
  • Page 79: Electric Ignition Operation

    TO ADJUST MAIN BURNER (FIG. 5-6): 1. Loosen air shutter screw (Fig. 5-6A). 2. Slide air shutter (Fig. 5-6B) to the right until some yellow appears in the main burner flame. 3. Move air shutter (Fig. 5-6B) to left until yellow disappears. 4.
  • Page 80: Combo Gas/Electric Electric Operation

    Combo Gas/Electric Electric Operation 1. For gas operation refer to Pilot, Pilot Relight or Electronic Ignition operation. 2. For electrical operation, use the switch inside the motorhome in the utility panel. 3. Completely fill tank with water. 4. Turn switch (Fig. 5-8) located in the motorhome to the "ON" position. NOTE: Turning the power on in the heater with little or no water covering the heating element may burn out the element and void the warranty.
  • Page 81: Refrigerator

    REFRIGERATOR WARNING: • The storage of flammable materials behind or around the refrigerator creates a fire hazard. Do not use the area behind the refrigerator to store flammable materials (gasoline, cleaning supplies, etc.) • Do not remove the round ground prong from any AC power cords. Do not use a two prong adapter or an extension cord with any of the AC power cords.
  • Page 82: About Your Refrigerator

    About Your Refrigerator: LEVELING CAUTION: The refrigerator is made to operate within 3” off level side-to-side and 6” off level front-to-back (as looking at the front of the refrigerator). Operating it at more than these limits can cause damage to the cooling system and create a risk of personal injury or property damage.
  • Page 83 ADJUSTABLE SHELVES The shelves in the freezer and the fresh food compartment are made so you can remove them or move them. • To remove or move the shelf of the freezer: • Pull the shelf forward out of the slot. •...
  • Page 84 MOISTURE REDUCTION HEATER The refrigerator has a heater that prevents moisture from forming on the center divider between the doors of the freezer and the fresh food compartment. The heater operates only when the refrigerator is ON and the DC power is sufficient. BACKUP OPERATING SYSTEM This refrigerator has a backup operating system.
  • Page 85: Model N821

    Model N821 NORCOLD LP GAS TEMP MODE AUTO COLDEST-9 1-COLD Fig. 5-11 CONTROL PANEL The refrigerator control panel is between the freezer compartment and the fresh food compartment. To maintain the operating control functions of the refrigerator, a 12-volt DC power supply is necessary.
  • Page 86 The controls select the energy source in this sequence: • When 120-volt AC is available to the refrigerator: • The light bars beside AUTO and AC show in the center display. • After ten seconds, the light bar beside AC goes off and only the light bar beside auto remains.
  • Page 87: 900 Series Information

    900 Series Information REFRIGERATOR CONTROLS AND OPERATING INSTRUCTIONS A 12-volt DC supply is required to maintain the refrigerator’s operating control functions. The refrigerator receives its DC power from the vehicle’s 12-volt system; either an auxiliary battery, a converter or the engine battery. The 12-volt DC system not only supplies power to the refrigerator, but to other DC components in the vehicle.
  • Page 88 be used only to maintain temperatures when the other modes are unavailable (for example; while in transit). During operation in the “AUTO” mode, when a higher priority energy source becomes available, the operating controls will cease using the current energy source and will switch to the higher priority energy source.
  • Page 89: Monitor Panel

    MONITOR PANEL This electronic control panel and information center is located inside the motorhome door at the end of the upper cabinet behind a smoke glass door. Information data and controls are at eye level for easy operation. Energy to operate the panel is 12-volt DC, supplied by the auxiliary battery and/or power center.
  • Page 90 NOTE: Should icing-up occur, it is necessary to let the cooling (evaporator) coil defrost before normal cooling operation is resumed. During this time, operate the unit in the “HIGH FAN” position with the system at maximum air flow. When increased or full air flow is observed, the cooling coil should be clear of ice. SHORT CYCLING When an air conditioner is in operation , its compressor circulates refrigerant under high pressure.
  • Page 91: Chapter 6 Care And Maintenance

    Chapter 6 CARE AND MAINTENANCE EXTERIOR CAUTION: We do not recommend you take your recreation vehicle through automatic car washes and extreme caution should be used if utilizing any type of pressure sprayer around all attachments, doors, windows, appliance vents, etc. to avoid forcing water inside the vehicle, possibly damaging components.
  • Page 92: Doors, Extrusions, Windows & Vents

    Doors, Extrusions, Windows & Vents These components have putty tape between the component and the wall surface. Portions of these items may have a cap seal added as a secondary seal. Inspect these seals at least once a year. Both putty tape and cap seals can become damaged by U.V.
  • Page 93: Chassis

    NOTE: Use non-corrosive cleaning compounds. Avoid the use of compounds containing ammonia or chlorine since they may cause the panels to yellow. DO NOT use rubbing compounds, as they will etch and damage the panel surface. Chassis Instructions for drive train and automotive chassis are included in the manual supplied by the chassis manufacturer.
  • Page 94: Wheel Liners

    Wheel Liners Your recreation vehicle may be equipped with Versa-Liner Wheel Liners. The following instructions will give you direction for removing and reinstalling the wheel liners when necessary. VERSA-LINER® WHEEL LINERS NOTE: DO NOT loosen or remove lug nuts. Set the vehicle parking brake prior to wheel product installation.
  • Page 95: Inspection Points For Sealing

    INSPECTION POINTS FOR SEALING The following diagram indicates the locations that need to be inspected semi-annually and resealed at least one time each year. Moldings Windows TV Antenna Exterior Attachments Vents Marker & Tail Lights Care and Maintenance...
  • Page 96: Interior Care

    INTERIOR CARE Refrigerator REFRIGERATOR CARE CHECKLIST Your refrigerator will give you years of trouble free service if you do these simple checks every three to six months: • Keep the food compartment and the freezer clean. See “Defrosting” and “Cleaning”. •...
  • Page 97 It is normal for frost to collect inside the freezer. Excess frost decreases the cooling performance of the refrigerator. Defrost the refrigerator as necessary: • Remove all food from the refrigerator. • Push the selector switch to the OFF position to shut down the refrigerator. NOTE: Defrosting the refrigerator makes excess water inside the refrigerator.
  • Page 98 REFRIGERATOR MAINTENANCE CHECKLIST Read and understand the following maintenance sections. NOTE: Norcold is not responsible for installation, adjustment, alteration, service, or maintenance performed by anyone other than a qualified RV dealer or a Norcold authorized service center. Have a qualified RV dealer or a authorized service center do these annual safety and maintenance checks: •...
  • Page 99 REFRIGERATOR MAINTENANCE GAS FLAME APPEARANCE: While in GAS operation, examine the appearance of the gas flame: • Turn the temperature switch to the COLDEST position. • Open the lower intake vent. CAUTION: The burner box cover can be hot. Wear gloves to avoid burns. •...
  • Page 100: Range And Oven

    Range and Oven WARNING: • Make sure all controls are OFF and the range or cooktop is cool before cleaning. • Make sure that all cooktop surfaces, burner grates and bruners are cool before cleaning or disassembling cooktop. • Do not use oven cleaners, bleach, or rust removers on the cooktop or burner grates.
  • Page 101 Range & Slide-in Cooktop 1. To remove the range top: a. Remove the hold down clip by sliding it forward from the front burner. (Fig.6-1A) b. Lift the top upward by the front edge. The top will “snap” loose from the clips mounted in the burner box. 2.
  • Page 102: Toilet

    Toilet GALAXY No routine maintenance is required. To clean toilet, use Thetford Aqua-Bowl or any other high grade, nonabrasive cleaner. Do not use highly concentrated or high acid content household cleaners or scouring powder, as these products can damage seals and finish. Do not use products with chlorine or bleach.
  • Page 103 AFTERMARKET WATER HEATING ELEMENT DEVICES WARNING: EXPLOSION / BURN INJURY • DO NOT alter water heater, it will void warranty. • DO NOT USE Aftermarket heating elements, they can lack critical safety controls. • Use of Aftermarket heating elements can lead to an out of control heating of water tank and a catastrophic wet side explosion.
  • Page 104 PREVENTIVE MAINTENANCE Spiders, mud wasps, and other insects can build nests in burner tube. This causes poor combustion, delayed ignition or ignition outside combustion tube. Listen for a change in burner sounds or in flame appearance from a hard blue flame to a soft lazy flame or one that is very yellow. These are indications of an obstruction in the burner tube (Fig.
  • Page 105 4. Close off drain valve as well as pressure temperature relief valve. 5. After this procedure, there will be approximately two quarts of water left at the bottom of inner tank. Should this water freeze, it will not cause any damage to the tank. NOTE: Two or three times a year flush out tank.
  • Page 106: Air Conditioner

    When pressure-temperature relief valve discharges again, repeat above procedure. For a permanent solution, we recommend one of the following: • Install a pressure relief valve in cold water inlet line to water heater and attach a drain line from valve to outside of coach. Set to relieve at 100-125 PSI. •...
  • Page 107: Carbon Monoxide Detector

    Carbon Monoxide Detector TESTING WARNING: DO NOT attempt to test the detector by any other means than using the "test" button. DO NOT attempt to produce carbon monoxide to test the detector. The CO detector should be tested weekly for proper operation: 1.
  • Page 108: Slideout Preventative Maintenance

    • If the system squeaks or makes any noises apply a coat of light weight oil to the drive shaft and roller areas. Remove any excess oil to prevent buildup of dirt and debris. • If you have any problems or questions consult your local Jayco dealer or call Power Gear 1-800-334-4712...
  • Page 109: Cushions

    Paneling The wall paneling in your new Jayco is a vinyl covered panel. If deep scratches occur, putty sticks can be used to cover scratches on wood surfaces. These can be obtained from hardware stores and lumber yards.
  • Page 110: Counter Top

    Below is a list of suggested maintenance items to follow at specific intervals for optimum performance and operation of your Jayco RV. This list is meant to be a supplement to the maintenance items of the chassis manufacturer's owner's manual. Please add these items to your maintenance routine.
  • Page 111 EVERY THREE MONTHS OR 3,000 MILES Vacuum around LP Burner and pilot light areas. Compare water heater pilot flame with ideal flame. Refer to the water heater owner's manual for ideal flame. Clean and adjust as necessary. Compare refrigerator pilot flame with ideal flame. Refer to the refrigerator owner's manual for ideal flame.
  • Page 112: Chapter 7 Options

    Chapter 7 OPTIONS NOTE: Information in this chapter may not necessarily apply to your unit. For some models, optional equipment may have been added as your vehicle was being built. There may be some information here that is standard equipment for the model of motorhome that you own.
  • Page 113: General Safety Precautions

    • DO NOT CONNECT GENERATOR SET DIRECTLY TO ANY BUILDING ELECTRICAL SYSTEM. Hazardous voltages can flow from the generator set into the utility line. This creates a potential for electrocution or property damage. Connect only through an approved device and after building main switch is open. Consult an electrician in regard to emergency power use.
  • Page 114: Fuel Recommendations

    Fuel Recommendations WARNING: Gasoline and LP Gas are highly flammable fuels and can cause severe personal injury or death. Do not smoke if you smell gas or gasoline or are near fuel tanks or fuel-burning equipment or are in an area sharing ventilation with such equipment.
  • Page 115: Remote Control

    Remote Control The vehicle has a remote control panel (Fig. 7-2) inside the door for controlling the genset operation. The START-STOP switch has a lamp that lights to indicate when the genset is running (which may not otherwise be obvious, especially when the vehicle is moving).
  • Page 116: Starting And Stopping

    Starting and Stopping WARNING: EXHAUST GAS IS DEADLY! Exhaust gases contain carbon monoxide, an odorless and colorless gas. Carbon monoxide is poisonous and can cause unconsciousness and death. Symptoms of carbon monoxide poisoning include: Dizziness Throbbing in Temples Nausea Muscular Twitching Headache Vomiting Weakness and Sleepiness...
  • Page 117: Genset" Loading

    CAUTION: Proper engine cooling requires that the access cover be secured during operation. Also, hot engine parts can cause severe burns. Always secure the access cover as soon as the engine starts up. 1. For top performance and engine life, especially in colder weather, let the engine warm up for at least two minutes before connecting the genset to the vehicle electrical loads (appliances).
  • Page 118: Restarting A Stalled "Genset

    TYPICAL APPLIANCE POWER CONSUMPTION Power Consumption Appliance (watts) Air Conditioner 1400-2000 Battery Charger Up to 800 DC Converter 300-500 Refrigerator 600-1000 Microwave Oven 1000-1500 Electric Frying Pan or Wok 1000-1500 Electric Stove Element 350-1000 Electric Water Heater 1000-1500 Electric Iron 500-1200 Electric Hair Dryer 800-1500...
  • Page 119: Resetting Circuit Breakers

    Resetting Circuit Breakers If a circuit breaker in the main power distribution panel of the vehicle or on the genset (Fig. 7-3) trips, there is either a short circuit or too many appliances being operated at the same time. Note that the genset will continue to run after a circuit breaker trips.
  • Page 120: Periodic Maintenance

    DUSTY CONDITIONS Pay particular attention to the following items when operating the genset in dusty conditions: 1. Do not let dirt and debris accumulate inside the genset compartment. Keep the genset clean. 2. Perform air cleaner maintenance more often than usual. See Periodic Maintenance. 3.
  • Page 121: Electric Door Step (Standard On Some Models)

    ELECTRIC DOOR STEP (STANDARD ON SOME MODELS) The electric door step opens automatically when the screen door is opened. The power is supplied by 12-volt DC arriving through a 30-amp breaker located in the engine bay. A yellow wire supplies power to the electric step.
  • Page 122: Maintenance And Lubrication

    Maintenance and Lubrication Clean all mud, salt and road grime from the step before lubricating. Lubricate all moving parts (bearings, pivot points, slides, clevis pin and drive linkage ball) every 30 days with a good quality moisture and heat resistant penetrating grease. KwikLube™ Spray Grease is specially formulated to lubricate Kwikee Electric Steps and is recommended for lubricating all moving parts.
  • Page 123: Bbq Grill

    BBQ GRILL An option for your motorhome is a BBQ Grill. This grill is for use outside of the motorhome and comes with a bracket to attach to the side of the vehicle. The following list will supply basic operations for the grill.
  • Page 124: Hitch

    HITCH Your motorhome is designed to be a recreation vehicle, however it does have towing capabilities as well as limitations. A class 3 hitch receiver is available with a 3,500# (1588 kilograms) gross weight capacity. A variety of extender bars of different ratings are available. Remember the limit of weight on the hitch and chassis.
  • Page 125: Spare Tire Carrier

    SPARE TIRE CARRIER The following procedures should be used for securing the spare tire in the travel position: 1. Put the steel hoist lift support located on the end of the cable through the rim of the tire. Clips need to seat inside of the hole. •...
  • Page 126: Chapter 8 Warranties

    Chapter 8 WARRANTIES TRANSFERABLE LIMITED WARRANTY Type C Owner’s Manual...
  • Page 127 Warranties...
  • Page 128: Limited Warranty Transfer Application

    The warranty on your unit is transferable one time only, from the original owner to a subsequent owner. This form as shoen here and on the next page must be completed by the dealership. The form should be sent with the $100.00 to Jayco, Attention: After Market Services. Type C Owner’s Manual...
  • Page 129 Warranties...
  • Page 130 SUBSEQUENT OWNER This card is to be used for the notification of transfer of ownership only. If you have submitted the paperwork to transfer warranty, please do not use this card. ATTENTION! Subsequent Owner WE NEED YOUR HELP! FEDERAL RECORD KEEPING LAWS REQUIRE THAT WE MAINTAIN A FILE OF OWNERS OF OUR PRODUCT, YOUR COOPERATION IN FILLING OUT THE CARD WILL BE APPRECIATED.
  • Page 131 NO POSTAGE NECESSARY IF MAILED IN THE UNITED STATES BUSINESS REPLY MAIL FIRST-CLASS MAIL PERMIT NO. 21 MIDDLEBURY IN POSTAGE WILL BE PAID BY THE ADDRESSEE Jayco, Inc. P.O. Box 460 Middlebury, IN 46540-9904...
  • Page 132 NOTES...
  • Page 133 NOTES...
  • Page 134 Jayco. We are pleased you chose Jayco and want to do everything possible to make sure you stay as happy with your Jayco RV home as you were on the day you bought it.

This manual is also suitable for:

Granite ridge

Table of Contents

Save PDF
