Power Supply; Outputs - GE Multilin MIB Instruction Manual

2 PRODUCT DESCRIPTION
2.10.4.1 LOW RANGE
Rated DC Voltage:
Min./Max. DC Voltage:
2.10.4.2 HIGH RANGE
Rated DC Voltage:
Min./Max. DC Voltage:
Rated AC Voltage:
Min./Max. AV Voltage:
Power Consumption:
Proper backup time (date, time and log
memory) without power supply voltage
2.10.4.3 LOW RANGE (HID MODULE)
Rated DC Voltage:
Min./Max. DC Voltage:
2.10.4.4 HIGH RANGE (HID MODULE)
Rated DC Voltage:
Min./Max. DC Voltage:
Power consumption:
2.10.5.1 OUTPUT RELAYS
Configuration:
Contact Material:
Maximum Operating Voltage:
Continuous Mode Current:
Make and Carry:
Breaking:
GEK-106426B
24 to 48 Vdc
19 / 58 Vdc
110 to 250 Vdc
88 / 300 Vdc
110 to 230 Vac @ 50 – 60 Hz
88 / 264 Vac @ 50 – 60 Hz
Max. = 10 W
> 1 week
48 Vdc
38 / 57 Vdc
125 Vdc
100 / 150 Vdc
8W
6 Electro-Mechanical Form C
Silver alloy suited for inductive loads
400 Vac
16 A at 250 Vac. general purpose
¾ HP, 124 Vac
1-1/2 HP, 250 Vac
10A, 250 Vac, 0.4 PF,
B300 pilot duty
30 A
4000 VA
MIB High Impedance Bus Differntial Relay
2.10 TECHNICAL SPECIFICATIONS.

2.10.4 POWER SUPPLY

2.10.5 OUTPUTS

2
2-19
