• Count — select 8. This creates the series
of 1-8 for Aux Bank 1.
6. Click Apply.
7. For each of the new sources you need to add
a custom VID. The VIDs must follow the
format
<router-name> .slot0.virt-out[ aux ].sdi.ch1.
For example, aux 7 on bank 4 for the router
being used for this example would be
Ultrix-5ru.slot0.virt-out[31].sdi.ch1.
8. Repeat this procedure to add all 8 aux bus
banks.
9. Click Apply.

Ultriscape Multi-Viewer

Some of the outputs from each ME are available
as PiPs for the software defined Ultriscape
MultiViewer in the router.
Note: Refer to the documentation that came with your router
for information on licensing and setting up Ultriscape.
The switcher makes the following sources
available as PiPs from ME 1. All other MEs in
the switcher have similar outputs. You must
assign tally IDs to the router sources to have the
switcher tally sources on the Multi-Viewer.
• ME1 PGM A
• ME1 PVW A
• ME1 PGM B
• ME1 PGM C
• ME1 User Out 1
• ME1 User Out 2
• ME1 User Out 3
• ME1 User Out 4
Tip: Refer to ME Outputs to the Router
information on assigning sources switcher sources to the USER
outputs.
22 • Ultrix Acuity Setup — Ultrix Acuity Setup Manual (v10.0)
on page 33 for
