Voxx Electronics PRESTIGE APS997Z Quick Installation Manual

APS997Z
Security and Remote Start
System Layout
1 3 5 7
2 4 6 8
1 Red/Black Ignition 3 Flex Relay (87) Input
2 Pink Ignition 3 Flex Relay (30) Output
3 Yellow Starter Output (+)
4 Green Ignition 2 Output (+)
P
5 Red Battery 12V Input (+)
6 Red/White Battery 12V Input (+)
7 Purple Accessory Output (+)
P
8 Blue Ignition 1 Input / Output (+)
Replacement Part #4120458
1 3
2 4
1 White Parking Light (30) Output
2 White/Red Parking Light (87) Input
3 White/Black Siren Output (+)
4 Black Ground Input (-)
Replacement Part #4120462
1
White Data RX
2
Black Ground (-)
3 Blue
Data TX
4 Red
Battery 12V (+)
Not Included
87
87A
85
86
30
85 Red Ignition Input (+)
86 Orange Starter Kill Input (-)
87A Black Starter Interrupt - Key Side
30 White/Black Starter Interrupt - Motor Side
Replacement Part #4360828
P
P
1
2
Replacement Part #4360830
3
4
1 2 3 4
1 Green Data RX
2 Blue Data TX
3 Black Ground (-)
4 Red Battery 12V (+)
Replacement Part #4120464
1 2 3
1 Blue
2 White
3 Black
4 Red
Not Included
4180075 18LCDSP 185SP
FLCART Dock
4
Data TX
Data RX
Ground (-)
Battery 12V (+)
4
4 Red Battery 12V (+)
3 3 Black Data TX
2 Green Warn Away Input (-)
2
1 Blue Full Trigger Input (-)
1
Green
22 Unlock Output (-) (NOC 11)
Dk. Blue
21 Trunk Output (-) (NOC 9)
20 Red Lock Output (-) (NOC 10)
19 Green/Lt. Blue Ch. 4 AUX Output (-) (NOC 8)
18 Black/White Horn Output (-)
17 Lt. Blue/Green Ch. 5 AUX Output (-) (NOC 7)
21 22
16 Red/Black 2nd Unlock Output (-) (NOC 12)
Black/Lt. Green
15 Factory Arm Output (-) NOC 6)
19 20
14 Brown/Black Brake Input (+)
17 18
13 Black/Blue Factory Disarm Output (-) (NOC 5)
15 16
12 Dk. Blue/Black External Activation Input (-)
13 14
11 Black/Red Pulse After Shutdown Output (-) (NOC 4)
11 12
10 Orange/Black Parking Brake Input (-)
9 10 9 Black/Yellow Pulse During Crank Output (-) (NOC 3)
8 Green/Yellow Diesel Glow Plug Input (+)
7 8
7 Green/White DomeLight Output (-) (NOC 2)
5 6
6 Purple/Brown Door Trigger Input (- / +)
3 4
5 Lt. Blue Remote Start Status Output (-) (NOC 1)
1 2
4 Green/Orange Tach Input (-)
3 Gray/Black Hood Input (-)
2 Lt. Green Trunk Trigger Input (-)
1 Orange Starter Kill Relay / Anti-Grind Output (-)
4
4 Red
Battery 12V (+)
3 3 Black
Ground (-)
2 White Data RX
2
1 Blue Data TX
1
19 20
17 18
15 16
13 14
This Harness is included with the FLCART.
11 12
For Wire Information and Diagram Please Refer to Vehicle
Specific FlashLogic Install Guide.
9 10
Visit www.FlashLogic.com for More Information.
7 8
Not Included
5 6
3 4
1 2
2018 Voxx Electronics. All Rights Reserved.
Shock Sensor
Part #4700033
Replacement Part #4120459
Replacement Part #4120457
Not Included
