Olimpia splendid SECCO SUPER Service Manual

Hide thumbs Also See for SECCO SUPER:

Table of Contents

Download this manual

SECCO PIÙ - SECCO SUPER

Display:

Usually the display shows set point, press "Hr" button to see room humidity. Set point can be regulated

between 30 and 90, 5 by 5, pressing UP or DOWN. (only for Secco Super)To select minimum or

maximum fan speed, press the fan button.

To start and stop the unit pres Stand By button. In stand by mode every component is off, there is no

measuring and no programming is possible.

Compressor and fan start if the difference between room humidity and set point is higher than 3 and if a

time higher than "Cf" has passed after last stop. Compressor and fan keep going until the difference

between room humidity and set point is higher than -3. When compressor stops the fan keep going for

another 30 seconds. When the tank is full all components turn off, tank led turns on and the unit buzzes for

15 sec. Pressing one button during the 15 sec the buzz stops.

All inputs are saved in an eeprom, after a power failure the unit will restart considering last inputs.

When there is ice on the evaporator (evaporator temperature < "Ft" and compressor on) the compressor

keep working for another 30 min, than it stops while the fan keep going until evaporator temperature >

Table of Contents

Do you have a question about the SECCO SUPER and is the answer not in the manual?

Page 1 Usually the display shows set point, press “Hr” button to see room humidity. Set point can be regulated between 30 and 90, 5 by 5, pressing UP or DOWN. (only for Secco Super)To select minimum or maximum fan speed, press the fan button.
Page 2 “St”. If there is ice on the evaporator, but the compressor stops because set point has been reached, fan keep going until evaporator temperature is OK. Full tank deactivation The switch for full tank alarm can be deactivated. When the switch is open (tank missing or full) press for 3 sec UP + DOWN.
