Digital IO Control Category

The camera's Digital IO Control category is used to configure the cameras GPIO pins.

Digital IO Control Feature Descriptions

Display Name
Trigger Mode
Internal
External
Trigger Source
CLHS In
Rotary Encoder
Line 1
Trigger Input Line
ActivationEdge
Rising Edge
Falling Edge
Any Edge
100 • Appendix A: GenICam Commands
Figure 52 Digital I/O Control Panel
Feature
TriggerMode
Internal
External
TriggerSource
CLHS
Encoder
GPIO1
TriggerActivation
RisingEdge
FallingEdge
AnyEdge
Description
Determines the source of trigger to the camera.
Line rate is controlled with AcquisitionLineRate
feature.
Trigger comes from CLHS (frame grabber) or GPIO.
Determines the source of external trigger.
Source of trigger is from the frame grabber over
CLHS.
Trigger source is from the two shaft encoder inputs.
Trigger source is from Line 1 of the GPIO connector.
Determines which edge of a input trigger will
activate on
The trigger is considered valid on the rising edge of
the line source signal (after any processing by the
line inverter module).
The trigger is considered valid on the falling edge.
The trigger is considered valid on any edge.
Linea HS Series Camera User's Manual
View
Beginner
Beginner
Beginner
