Read this manual carefully before use, and retain it for future reference.
10000mAh Mi Power Bank 3 Ultra Compact
User Manual
Thank you for choosing 10000mAh Mi Power Bank 3 Ultra Compact. This product
is small and portable, supporting a maximum of 22.5 W in two-way fast charging.
Equipped with high-quality lithium polymer battery cells and a charging and
discharging chip, the power bank performs excellently in terms of safety,
efficiency, and compatibility.
USB-C Port (Input/Output)
Micro-USB Port (Input)
USB-A Port (Output)
Battery Level Check Button
USB-A Port (Output)
Battery Level Indicator
Notes:
The battery level check button is not a power button.
The power bank detects charging and discharging automatically.
Safety: This power bank is equipped with multiple safeguarding technologies to
prevent overcharging, over-discharging, overheating, and short circuits in any
working condition.
Fast Charging: USB-A single port supports 5 V/2.4 A, 9 V/2.5 A Max., 12 V/1.85 A
Max. fast charging mode. USB-C single port supports 5 V/3 A, 9 V/2.5 A Max.,
12 V/1.85 A Max. fast charging mode.
Compatibility: The built-in USB charge controller is compatible with most smart
devices including smartphones, and tablets.
Quality: High-quality lithium polymer battery cells and a durable charging and
discharging chip.
Advertisement
Table of Contents
Related Manuals for Mi 3 Ultra Compact
Summary of Contents for Mi 3 Ultra Compact
- Page 1 10000mAh Mi Power Bank 3 Ultra Compact User Manual Thank you for choosing 10000mAh Mi Power Bank 3 Ultra Compact. This product is small and portable, supporting a maximum of 22.5 W in two-way fast charging. Equipped with high-quality lithium polymer battery cells and a charging and discharging chip, the power bank performs excellently in terms of safety, efficiency, and compatibility.
- Page 2 Charging To charge the power bank, connect a Mi power charger and charging cable to its USB-C or Micro-USB port. The indicator shows the following charging status: Battery Level LED1 LED2 LED3 LED4 0-25% Blinking LED1 25-50% Blinking LED2 LED3...
- Page 3 Warnings Improper use may result in battery failure, overheating, and even fire or explosion. To ensure your safety and minimize the risk of personal injury and property damage, please observe the following precautions: This power bank is not a toy. Please keep it away from children. Do not let children use or play with this power bank in order to avoid accidents.
- Page 4 Precautions Please fully charge this power bank before using it for the first time. Use a qualified charger and a USB cable (Mi brand products are recommended) when charging the power bank or using it to charge other devices. When charging this power bank, do not leave it unattended for a long time. Unplug it from the power supply before going out.
- Page 5 Directives and European Norms, and amendments. The full text of the EU declaration of conformity is available at the following internet address: http://www.mi.com/global/service/support/declaration.html WEEE Information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste.
- Page 6 Anti-counterfeit Label Instructions Each 10000mAh Mi Power Bank 3 Ultra Compact comes with an anti-counterfeit label on the outer package. To check the authenticity of the product, scratch the anti-counterfeit coating, and then enter the security code on chaxun.mi.com. Anti-counterfeit Label Scratched-off Coating For further information, please go to www.mi.com...
