Quick Start Guide
Quick Start Guide
Please read this guide before operating this scanner. After you finish reading this guide,
store it in a safe place for future reference.
Safety Precautions.............................. 1
Package Contents............................... 3
Installing the Software......................... 4
Preparing the Scanner ........................ 7
Try Scanning....................................... 8
Table of Contents
Using the Scanner Buttons ................. 9
Scanning with MP Navigator EX......... 10
Scanning Film ..................................... 11
Positioning the Scanner...................... 15
Specifications...................................... 16
Advertisement
Table of Contents
Related Manuals for Canon CanoScan LiDE 700F
Summary of Contents for Canon CanoScan LiDE 700F
-
Page 1: Table Of Contents
Quick Start Guide Quick Start Guide Please read this guide before operating this scanner. After you finish reading this guide, store it in a safe place for future reference. Safety Precautions... 1 Package Contents... 3 Installing the Software... 4 Preparing the Scanner ... 7 Try Scanning... -
Page 2: Fcc Notice (U.s.a. Only)
United States and or other countries. • ©ArcSoft, Inc. All rights reserved for PhotoStudio. • Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies. ® Partner, Canon Inc. has determined that this product meets... -
Page 3: Safety Precautions
Setting the stand incorrectly may result the scanner to fall sideways and cause injury. • Do not push the scanner into a narrow cabinet or put a tablecloth on it or place on a thick rug. If the scanner has heat, it may cause fire or damage. -
Page 4: Setup And Operating Conditions
• When transporting the scanner, always unplug the cables. Damaged cables could cause fire or electrical shock. If anything enters the scanner, immediately unplug the USB cable and contact your retailer or Canon Customer Support Help Desk. CAUTION • Do not release the document cover until it completely opens/closes. If the document cover falls, it may lead to pinch your hands or damage the scanner and result in injury. -
Page 5: Package Contents
Documentation • Quick Start Guide (this document) • Additional Documents Setup CD-ROM • Software Programs - ScanGear (scanner driver) - MP Navigator EX (utility software) - Solution Menu (menu panel software) - ArcSoft PhotoStudio (image editing software) • On-screen Manuals... -
Page 6: Installing The Software
Installing the Software Installing the Software • Do NOT connect the scanner to a computer before installing the software. If you connect the scanner and the Found New Hardware screen appears, unplug the USB cable from the computer and click Cancel. The screen may close automatically when the USB cable is unplugged. - Page 7 Click Easy Install on the main menu. Click Install to start installation. Carefully read the License Agreement, and then click Yes to proceed. For Macintosh, skip step 6 and go to step 7. For Windows, carefully read the Please Allow All Install Wizard Processes screen, and then click Next.
- Page 8 Installing the Software For Windows, when the Extended Survey Program screen appears, confirm it. If you can agree, click Agree. When the installation is complete, click Restart to restart your computer. For Windows: After restarting the computer, Solution Menu will appear.
-
Page 9: Preparing The Scanner
• Do not touch the metallic parts of the USB connector. • The scanner does not have a power switch. The power is activated as soon as the computer is turned on. • When the scanner is connected to the USB 1.1 port and HI-SPEED USB Device Plugged into non-HI-SPEED USB Hub message appears, ignore the message. -
Page 10: Try Scanning
1 cm (0.4 in.) away from the edges of the document glass, and then close the document cover. Start MP Navigator EX. For Windows: Double-click the Canon Solution Menu icon, then click Scan/import photos or documents. For Macintosh: Click the Solution Menu icon in the Dock, then click Scan/import photos or documents. -
Page 11: Using The Scanner Buttons
If the scanner buttons do not work properly, see "Troubleshooting" in the on-screen manual: Scanning Guide. • For Mac OS X v.10.3.9: Before using the scanner buttons, you need to set Image Capture (in Applications folder) to open MP Navigator EX automatically when a scanner button is pressed. -
Page 12: Scanning With Mp Navigator Ex
Click Scan/import photos or documents in the Solution Menu. You can also start it by following procedure. For Windows: Select Start – (All) Programs – Canon Utilities – MP Navigator EX 2.1, and click MP Navigator EX 2.1. For Macintosh: Open Applications – Canon Utilities folders, then double-click the MP Navigator EX 2.1 icon. -
Page 13: Scanning Film
Scanning Film This scanner can scan 35 mm film strip one frame at a time. Follow the procedure below when scanning film. • Do not connect other than the accompanying Film Adapter Unit to the FAU connector. Use of other units may lead to malfunctions of the connected unit and the scanner. - Page 14 Follow the step 2 in "Try Scanning" on page 8. Click Film. Click Scan. Click OK on the calibration message window. Do not move the scanner while it is operating. When the scanning message window appears, open the document cover, remove the Film...
- Page 15 The document cover does not touch the document glass. Be careful not to force the document cover down. Click OK on the scanning message window. The scanned image is displayed in the preview area. Do not move the scanner while it is operating. Confirm the scanning image, and then click Scan to start scanning.
- Page 16 Scanning Film Click Save to save the image and close MP Navigator EX. • After the scanning is finished, remove the Film Adapter Unit, and then attach the cap to the unit. Remove the film and the Film Guide from the document glass. •...
-
Page 17: Positioning The Scanner
Thick documents or films cannot be scanned in this position. Pull out the stand on the bottom of the scanner until it clicks, and set the scanner upright on a flat stable surface. Gently open the document cover as far as it goes (stops at approximately 40°) and slide down the document along the... -
Page 18: Specifications
35 mm slides are not supported. USB connection to PC. Film adapter unit weight is included. • Specifications are subject to change without notice. Model Name: K10337 (CanoScan LiDE 700F) CanoScan LiDE 700F Flatbed CIS (Color Contact Image Sensor) 3-color (RGB) LED... - Page 19 CANON U.S.A. INC. One Canon Plaza, Lake Success, NY 11042 U.S.A. CANON AUSTRALIA PTY LTD 1 Thomas Holt Drive, North Ryde, Sydney N.S.W. 2113, Australia CANON NEW ZEALAND LIMITED Akoranga Business Park, Akoranga Drive, Northcote, Auckland, New Zealand QT5-2200-V01 XXXXXXXX ©CANON INC.
