1. LIST OF ERROR DISPLAY

Errors and warnings are displayed by the following ways:
- Operator call errors are indicated by the Alarm lamp lit in orange, and the error and its solution
are displayed on the LCD.
- Messages during printing from a computer are displayed on the printer driver Status Monitor.
- Error codes are printed in the "operator call/service call error record" area in EEPROM
information print.
1-1. Operator Call Errors (Alarm Lamp Lit In Orange)
Buttons valid when an operator call error occurs:
- ON button:
- OK button:
- Stop button: To cancel the job at error occurrence, and to clear the error.
Error
Error
code
No paper in the [1000] --- There is no paper.
rear tray.
The paper output [1251] --- Paper output tray is
tray closed.
Paper jam. [1300] --- The paper is jammed.
Ink cartridge not [1401] U051 Print head is not
installed, or not
properly installed.
Ink cartridge [1403] U052 The type of print head
temperature
sensor error.
Non-supported [1485] U059 The ink cartridge
ink cartridge
installed.
Ink cartridge in a [1486] U076 Some ink cartridges
wrong position.
To turn the printer off and on again.
To clear and recover from an error. In some operator call errors, the error will
automatically be cleared when the cause of the error is eliminated, and pressing
the OK button may not be necessary.
U No. Message on the LCD
Load paper and press
[OK].
closed. Open the paper
output tray.
Clear the paper and
press [OK].
installed. Install the
print head.
is incorrect. Install the
print head.
cannot be recognized.
are not installed in
place.
Solution
Set the paper in the rear
tray, and press the OK
button.
Open the paper output tray,
and press the OK button.
Remove the jammed paper,
and press the OK button.
Install the ink cartridge
properly. If the error is not
cleared, the ink cartridge
may be defective. Replace
the ink cartridge.
Re-set the ink cartridge. If
the error is not cleared, the
ink cartridge may be
defective. Replace the ink
cartridge.
A non-supported ink
cartridge is installed. Install
the supported ink cartridge.
If the error is not cleared,
the ink cartridge may be
defective. Replace the ink
cartridge.
Install the ink cartridge(s) in
the correct position. If the
error is not cleared, the ink
cartridge may be defective.
Replace the ink cartridge.
(2/37)
Parts that are likely to be
faulty
- PE PWB unit
- Pick-up roller
- Drive unit
- Logic board
- PE PWB unit
- Logic board
- Ink cartridge
- Carriage unit
- Logic board
- Ink cartridge
- Carriage unit
- Logic board
- Ink cartridge
- Carriage unit
- Logic board
- Ink cartridge
- Carriage unit
- Logic board
