ORDER NO.AD0704007AE CD Stereo System SC-EN28P SA-EN28P SB-EN28P Colour (S)....Silver Type System SC-EN28P Main Unit: SA-EN28P Speakers: SB-EN28P Please use this manual together with the service manual for Model No.SC-EN27PC, Order No.AD0603021CE. Specifications MAIN UNIT D/A converter: MASH(1 bit DAC)
3 Schematic Diagram 1 Note · This simplified service manual is provided to indicate the main differences between the original model No. SC-EN27PC(SA- EN27PC+SB-EN25P) and the subsequent model No. SC-EN28P(SA-EN28P+SB-EN28P). 2 Replacement Parts List Note: · All parts are supplied by ASPC.
Page 3
SC-EN28P / SA-EN28P / SB-EN28P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C719 F1H1H332A013 50V 3300P R731 ERJ3GEYJ823V 1/10W 82K C720 ECEA0JKA330B 6.3V 33U R732 ERJ3GEYJ821V 1/10W 820 C721 F1H1H472A013 50V 4700P...
Page 4
SC-EN28P / SA-EN28P / SB-EN28P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C104 F1H1C104A042 16V 0.1U C809 ECJ1VB1H102K 50V 1000P C105 F1H1C104A042 16V 0.1U C810 ECJ1VC1H390J 50V 39P C106 ECJ1VB1H102K 50V 1000P...
Page 5
SC-EN28P / SA-EN28P / SB-EN28P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description IC351 C0GAE0000007 MOTOR DRIVER IC ERJ3GEYJ103V 1/10W 10K IC601 C0AAAA000036 POWER IC ERJ3GEYJ103V 1/10W 10K IC801 MN101C74FAD MICON IC...
Page 6
SC-EN28P / SA-EN28P / SB-EN28P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R608 ERJ3GEYJ333V 1/10W 33K R849 ERJ3GEYJ392V 1/10W 3.9K R612 ERJ3GEYJ222V 1/10W 2.2K R850 ERJ3GEYJ562V 1/10W 5.6K R613 ERJ3GEYJ223V 1/10W 22K R851 ERJ3GEYJ822V 1/10W 8.2K...
Page 7
SC-EN28P / SA-EN28P / SB-EN28P Ref. Part No. Part Name & Remarks Description XTV3+14GFJ SCREW XTV3+14GFJ SCREW RQLA1030 SP CAUTION LABEL RGNW0101-K SP NAME PLATE...
SC-EN28P / SA-EN28P / SB-EN28P foil. 3 Schematic Diagram · Put a conductive mat on the work table. 3.1. Schematic Diagram Notes · Ground the soldering iron. · Do not touch the pins of IC, LSI or VLSI with fingers (All schematic diagrams may be modified at any time with the directly.
Page 9
SC-EN28P / SA-EN28P / SB-EN28P 3.2. Schematic Diagram SCHEMATIC DIAGRAM-1 NOTE: CD SERVO CIRCUIT :POSITIVE VOLTAGE LINE :CD PLAYBACK SIGNAL LINE The number which noted at the connectors on the schematic diagram as "SCHEMATIC DIAGRAM-1" or "SCHEMATIC DIAGRAM-2" indicates the schematic diagram serial number located on the left corner in the...
Page 15
SC-EN28P / SA-EN28P / SB-EN28P 4 Printed Circuit Board Diagram Note: This printed circuit board diagram may be modified at any time with the development of new technology. CD SERVO P.C.B. R751 R705 VREF CN701 R708 C721 Q700 R725 R723...
