Summary of Contents for Eques VEIU Pro
- Page 1 VEIU Pro Smart Video Doorbell Smart and Safe User Manual...
-
Page 2: Package Contents
01 | Package Contents OPEN Bracket Outdoor Camera Indoor LCD Screen 1 piece 1 piece 1 piece Charger Bolts USB Cable 1 piece 1 piece 6 pieces Outdoor Camera 1 piece Charger 1 piece Bolts 6 pieces Indoor LCD Screen 1 piece Bracket 1 piece USB Cable 1 piece... -
Page 3: Component Diagram
02 | Component Diagram PIR motion detector Camera Speaker Outdoor Camera Doorbell Indoor LCD Screen Distance Sensor Screen Main key Camera SD slot Reset USB port 30 PIN I/O connector... -
Page 4: Installation Diagram
03 | Installation Diagram Bracket Self-adhesive strips Door Camera Peephole Ribbon cable Bolts Camera Preview Key Indoor LCD Screen Install Device with 1 screwdriver within minutes Tips: 1.When fastening the outdoor camera, attach bolts into its poles first. 2.When fastening the LCD screen, align it to the notch of the bracket. -
Page 5: Installation
04 | Installation 1. Attach two bolts to the 2. Peel off the protective film camera loosely. from the adhesive strips. 3. Pass the ribbon cable 4. Fasten the camera by through the door hole. pressing it firmly onto the door. Tip: It will be easier to wrap the ribbon cable in a paper tube first then pass through. - Page 6 5.Take out the screen, push 6. And then take off the out the small bracket on the guard board in the botton of back of it with your finger. the bracket. 7. Slightly press the cable to 8. And then attach the guard the pin on the bottom of the board.
- Page 7 ② ① 9. Pass the bolts through the 10. Put on the small bracket bracket as pictured, then with your finger. tighten the screws. 11. Suspend the LCD monitor 12. Press the Power key for 5 on the bracket from top to seconds to turn on/off your bottom, its magnet will be doorbell.
- Page 8 05 | Register and Add Your Device 5.1 | Download App Scan QR code to download the app, or seach on App store/Google play. “Eques” Android 5.2 | Start App After installing the app, click to start it.
- Page 9 5.3 | Register, Login and Add Devices In the “Device Manager” panel, Fill the information as pictured click “+” to add a new device. then click “register”. After Choose the device above as completed, use this account to pictured. login. Make sure you remember your login info.
- Page 10 5.4 | Input WiFi Information, Scan QR Code SAMPLE Input WiFi name and password Click “Prepare Scan” on the as per UI prompt then click previous step then generate a “Start Binding”. (Notes: the UI QR code, use the outdoor will prompt to enter the menu camera to scan this code.
- Page 11 5.5 | Bind Device and Preview You can hold your smartphone 1.Turn on power key and go in landscape orientation for a to setting full view. 2.Click “Setting” choose “Scan QR code”...
- Page 12 06 | Applicable Door Thickness Outdoor Indoor Side angle Applicable door thickness: 1.4in - 4.3in (35mm ~ 110 mm) Applicable peephole: 0.6in - 2.2in (15mm ~ 50mm) When choosing bolts to install the outdoor camera, you must know your door’s thickness. Notes: For the door thickness between 1.4in - 2.6in (35mm ~ 65mm), choose 30mm short bolts;...
-
Page 13: Safety Guideline
07 | Safety Guideline Try to avoid placing the device in high-temperature, high humidity, dusty or other harsh environments as this may reduce its lifespan. Don’t forcibly squeeze the camera lens and the black ball on the top of the outdoor subcomponent; otherwise it can cause hardware damage. - Page 14 CONTACT PAGE CUSTOMER SERVICE EMAIL: cs@equeshome.com ADDRESS: 3000 El Camino Real,Building 4, Suite 200,Palo Alto,CA 94306, USA WEBSITE: www.equeshome.com...
