Introduction .......................................................2
Important Safety Information ....................3
Features ............................................................6
Installation .........................................................7
Door Removal ................................................10
Door Handle Installation ............................. 12
Water Supply Connection .......................... 13
Controls and Settings ................................. 15
Frigidaire.com USA 1-800-374-4432
REFRIGERATOR
use
care
&
Automatic Ice and Water Dispenser ...... 19
Storage Features ........................................... 21
Normal Operating Sounds ........................ 22
Filter Replacement ...................................... 23
Care and Cleaning ....................................... 25
Troubleshooting .......................................... 29
Limited Warranty ......................................... 33
A19894604 (November 2020)
Frigidaire.ca Canada 1-800-265-8352
Advertisement
Table of Contents
Related Manuals for Frigidaire Gallery GRSC2352AD
Summary of Contents for Frigidaire Gallery GRSC2352AD
-
Page 1: Table Of Contents
Filter Replacement ........23 Door Removal ..........10 Care and Cleaning ........25 Door Handle Installation ......12 Troubleshooting .......... 29 Water Supply Connection ......13 Limited Warranty ......... 33 Controls and Settings ......... 15 A19894604 (November 2020) Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352... -
Page 2: Introduction
Installation Checklist Welcome to our Doors Thank you for bringing Frigidaire into ˆ Handles are secure and tight your home! We see your purchase as the ˆ Door seals completely to cabinet on beginning of a long relationship together. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING DANGER Please read all instructions before using DANGER Risk of fire or explosion. this appliance. Flammable refrigerant used. Do not use mechanical devices to defrost refrigera- Safety Definitions tor. Do not puncture refrigerant tubing. DANGER Risk of fire or explosion. This is the safety alert symbol. - Page 4 IMPORTANT SAFETY INFORMATION Child Safety Proper Disposal of your Appliance Risk of child entrapment This appliance is not intended for use by persons (including children) with reduced Child entrapment and suffocation are physical, sensory or mental capabilities, not problems of the past. Junked or or lack of experience and knowledge, abandoned appliances are still dangerous unless they have been given supervision...
- Page 5 IMPORTANT SAFETY INFORMATION Electrical information IMPORTANT • The appliance must be plugged into Turn off power to your appliance you its own dedicated 115 Volt, 60 Hz., must unplug the power cord from the 15 Amp, AC only electrical outlet. electrical outlet.
-
Page 6: Features
Damper/Air Filter Housing Crisper Drawers LED Lights Toe Grille Water Filter Slide-Out Basket IMPORTANT Accessories are available for your appliance and may be purchased at Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in Canada) or from an authorized seller. -
Page 7: Installation
INSTALLATION Installation This Use & Care Manual provides general operating instructions for your model. Use Installation clearances the unit only as instructed in this Use & Care Manual. Before starting the appli- • Allow the following clearances for ease ance, follow these important first steps. of installation, proper air circulation, and plumbing and electrical connections: Location... - Page 8 INSTALLATION Door Opening Meet all of these conditions by raising or lowering the adjust- NOTE able front rollers. To level the cabinet using the front rollers: The doors are designed to shut by themselves within a 20 degree opening. Open both doors and remove the toe grille (see “Toe Grille Installation and Removal”...
- Page 9 INSTALLATION To level the doors using the adjustable 4. After leveling, verify the door stop lower hinge: contacts the lower hinge and the top of the door does not contact the upper hinge through full movement NOTE of the door (from fully closed to fully open).
-
Page 10: Door Removal
DOOR REMOVAL To remove the refrigerator door: Tools Necessary: 1. Remove the 3 screws from the cover over the door hinge. 2. Lift hinge cover straight up and off. 3. Trace lightly around the door’s top hinge with a pencil. This makes Phillips™... - Page 11 DOOR REMOVAL To remove the freezer door: To Disconnect 1. Press outer ring against face of Remove the 3 screws from the cover fitting over the top door hinge. 2. Lift hinge cover straight up and off. 2. Pull to remove tube To Connect Insert tube and push until mark...
-
Page 12: Door Handle Installation
DOOR HANDLE INSTALLATION Remove handles from carton and Handles may vary according to model any other protective packaging. CAUTION 2. Position the freezer handle end caps over the upper and lower pre-in- stalled shoulder bolts (A) that are Wear gloves and safety goggles and fastened into door, ensuring the use extreme CAUTION when installing holes for the set screws are facing... -
Page 13: Water Supply Connection
• Use Copper or Stainless Steel braid- ed tubing for the water supply line. Check with your local building authori- Frigidaire does not recommend wa- ty for recommendations on water lines ter supply tubing made of ¼" plastic. and associated materials prior to in- Plastic tubing greatly increases the stalling your new refrigerator. - Page 14 WATER SUPPLY CONNECTION Plastic Water Tubing to Ice Maker Fill Tube Steel Clamp Brass Compression Nut Ferrule (Sleeve) Copper Water Line Water Valve Bracket Valve Inlet Water Valve Copper Water Line from Household Water Supply* Braided Flexible Stainless Steel Water Line 6 ft.
-
Page 15: Controls And Settings
CONTROLS AND SETTINGS NOTE Your appliance may have some or all of the features listed below. Become familiar with these features and their use and care. Sleep Mode Display Sleep Mode Sleep mode is default on. When sleep mode is on, the LEDs are not illuminated on the display. - Page 16 CONTROLS AND SETTINGS Display Freeze Boost (on/off) Ice Maker Activates a faster rate for freezing Press and hold for 3 seconds to food in the freezer. Use this feature turn the ice maker on/off. When when loading several items into the the indicator is lit, the ice maker is freezer at one time.
- Page 17 CONTROLS AND SETTINGS Adjusting Temp °F/°C Illuminates when temperatures are To toggle between Fahrenheit (°F) changed on the display and will and Celsius (°C), simultaneously press and hold + and - for 5 seconds remain illuminated until the desired temperatures are reached inside on refrigerator side of display.
- Page 18 CONTROLS AND SETTINGS Alarms (continued) In the Sabbath mode, the High Temp alarm is active for health reasons. For example, if the door is left ajar the High Water The water filter needs to be Temp alarm is activated. The refrigerator Filter replaced when the indicator will function normally once the door...
-
Page 19: Automatic Ice And Water Dispenser
AUTOMATIC ICE AND WATER DISPENSER Priming the water supply system Turning the ice maker on Ice production is controlled by the ice CAUTION maker's On/Off feature on the control panel. Pressing and holding the On/Off button toggles the ice maker On/Off. For proper dispenser operation, the recommended water supply pressure should fall between 30 psi and 100 psi. - Page 20 AUTOMATIC ICE AND WATER DISPENSER Ice Maker/Dispenser Tips 4. Allow the ice storage bin to dry com- pletely before replacing it in the freezer. • Ice cubes stored too long may 5. Remove ice chips and clean the ice develop an odd flavor. Empty the ice storage bin, shelf and the freezer container as explained in Cleaning the door chute.
-
Page 21: Storage Features
STORAGE FEATURES Glass shelves Crispers Shelves are easily adjusted to suit individ- Crispers allow you the flexibility to store ual needs. Before adjusting the shelves, any manner of items including fruits, veg- remove all food. Shelves are supported etables, nuts, etc. Crispers do not feature by side rails. -
Page 22: Normal Operating Sounds
NORMAL OPERATING SOUNDS Understanding the Sounds you may Hear Your new, high-efficiency unit may intro- duce unfamiliar sounds. These sounds normally indicate your appliance is oper- ating correctly. Some surfaces on floors, walls, and kitchen cabinets may make these sounds more noticeable. Following is a list of major components in your unit and the sounds they can cause: Evaporator Refrigerant through the... -
Page 23: Filter Replacement
3. Slide the old water filter cartridge To order your replacement filters, please straight out of the housing and visit our online store at Frigidaire.com, by discard it. calling toll-free at 1 (800) 372-4432, or by 4. Unpackage the new filter cartridge. - Page 24 FILTER REPLACEMENT 5. Push firmly until the cartridge Damper/Air Filter Housing snaps into place (you should hear a click as the cartridge engages the In humid regions snap-in connector). certain products 6. Press a drinking glass against the stored too close water dispenser while checking for to the damper/air any leaks at the filter housing.
-
Page 25: Care And Cleaning
CARE AND CLEANING Protecting your investment NOTE Keeping your appliance clean maintains If you set your temperature controls appearance and prevents odor build-up. to turn off cooling, power to lights and Wipe up any spills immediately and clean other electrical components will contin- the freezer and refrigerator compart- ue until you unplug the power cord from ments at least twice a year. - Page 26 CARE AND CLEANING Glass Shelves CAUTION CAUTION To avoid personal injury or property damage, handle the freezer glass shelves To avoid personal injury or property carefully. These shelves are fixed and are damage, handle tempered glass shelves not to be used as sliding shelves. carefully.
- Page 27 CARE AND CLEANING Finally, rotate the front trim upward on the To reassemble the freezer shelf, slide the front edge of the glass shelf (Figure 4). glass and rear trim along the shelf rails while pressing the shelf downward until it is fully locked into place in the rear (Figure 3).
- Page 28 CARE AND CLEANING Care & Cleaning Tips Part What To Use Tips and Precautions Interior & • Soap and water Use 2 Tbsp of baking soda in 1 qt Door Liners of warm water. Be sure to wring • Baking soda and water excess water out of sponge or cloth before cleaning around controls, light bulb or any electrical part.
-
Page 29: Troubleshooting
If you need us, visit our website, chat with an agent, or call us. We may be able to help you avoid a service visit. If you do need service, we can get that started for you! 1-800-265-8352 (Canada) 1-800-374-4432 (United States) Frigidaire.com Frigidaire.ca CONCERN CAUSE... - Page 30 TROUBLESHOOTING CONCERN CAUSE SOLUTION DISPENSER (Ice & Water) (Continued) Dispenser will not • Water filter not • Remove and reinstall the water filter. dispense water. seated properly. Be sure to push the filter firmly so that you hear it lock solidly into position. •...
- Page 31 It actually saves energy running more frequently. DIGITAL TEMPERATURE DISPLAY Digital tempera- • Electronic control • Call your Frigidaire service represen- ture displays system has detected a tative, who can interpret any messag- are flashing. performance problem. es or number codes flashing on the...
- Page 32 TROUBLESHOOTING CONCERN CAUSE SOLUTION WATER/MOISTURE/FROST INSIDE REFRIGERATOR Moisture collects • Weather is hot • The rate of frost buildup and internal on inside of re- and humid. sweating increases. frigerator walls. • See PROBLEM column OPENING/ • Door is slightly open. CLOSING OF DOORS/DRAWERS.
-
Page 33: Limited Warranty
Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.265.8352 1-800-374-4432 Electrolux Canada Corp. Frigidaire 5855 Terry Fox Way 10200 David Taylor Drive Mississauga, Ontario, Canada Charlotte, NC 28262 L5V 3E4... - Page 34 Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your regristration card for more information.) Frigidaire.com 1-800-374-4432 Frigidaire.ca 1-800-265-8352...
