Modes
There are 24 modes to choose from. The "M"
button cycles through the 6 main modes, all of
these 6 main modes contain different built-in 4
modes.
1. Lateral palm kneading
2. Flat palm kneading
3. Crosscut fist kneading
4. Vertical fist kneading
5. Acupuncture
6. Moxibustion
7. Acupuncture kneading
8. Moxibustion kneading
9. Rubbing
10. Rubbing reduction
11. Tapping
12. Fibrillation massage
13. Lifting-pinching manipulation
14. Vibrating manipulation
15. High frequency manipulation
16. Fibrillation manipulation
17. Shiatsu-Deep
18. Thai Massage
19. Shiatsu
20. Strength Alternate Massage
21. Twinkling Cupping
22. Cupping
23. Fibrillation Cupping
24. Cup retaining
support@belifu.co
3
Operating instructions
1. Connect the pads to the wire by snapping them
on, then remove the protective film.
Note: adding a few drops of water on the pads will increase
their longevity.
2. Place pads where the massage sensations are
desired. And plug into one of the ports on the
device. For additional relief, use the second port
and repeat steps 1&2 for two additional pads.
Make sure both pads on the skin and not overlap-
ping.
Make sure your skin is free from any dirt, oil or
lotion.
3. Turn the device on by pressing the on/ off switch
on the top of the unit. The unit will be now activated
and start in Model1.
4.Press the mode button to try different mode. Then
press the center button to choose the waves within
that selection. There are six icons on the screen,
press "<" and ">"button to change the six icons.
Each icon contains different built-in 4 modes, press
the "M" to choose the built-in 24 modes.
Please increase the intensity because it will return
to lowest automatically when you change to a new
mode.
5.Once you select a mode, gradually increase the
A/B intensity by pressing the + button on the right/
left side; decrease it by pressing ‐ button on the
right/ left side of the tens.
www.belifu.co
4
support@belifu.co
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the SM9126 and is the answer not in the manual?
Questions and answers
Can I speak to someone in person about my unit sm9126. Can I get a manual ?
@Carolyn S Bourne
How do I get it to work
To operate the Belifu SM9126:
1. Connect the electrodes by snapping them onto the wires.
2. Remove the protective film from the electrodes.
3. Apply a few drops of water to the electrodes to extend their life.
4. Place the electrodes on the desired body area.
5. Plug the electrode wires into the device.
6. Press the power button to turn on the device.
7. Use the mode button to switch between available modes.
8. Adjust intensity by pressing the + or - buttons on the right or left side for channels A/B.
9. Set the timer using the T button; it increases in 10-minute intervals.
10. The device turns off automatically when the timer ends.
Increase intensity slowly to avoid discomfort.
This answer is automatically generated
I can't get this thing to work
Troubleshooting steps for the Belifu SM9126 device:
1. Pads not working or no sensation:
- Ensure both pads are firmly pressed to the skin.
- Check for loose connections between the unit, wires, and pads.
- Increase the intensity level.
2. Adhesive pads not sticking:
- Clean and moisten the skin before applying pads.
- Replace old adhesive gel pads with new ones.
3. Device does not turn on or screen is dim:
- Recharge the battery if it is low.
4. Not providing adequate pain relief:
- Use the device for 20–30 minutes per session, 3–6 times per day.
- Lie on your back for better neck and headache relief.
5. Mode or intensity issues:
- After changing modes, increase the intensity again, as it resets to the lowest level.
- Use the "+" and "–" buttons on each side to adjust intensity.
- Use the “M” button to select among 24 built-in modes.
- Use the timer (T button) to adjust use time in 10-minute intervals.
This answer is automatically generated
Received this as a gift. What wires are you supposed to use? There are 3 sets included. One 4 lead blue and white and two white. Is there a differance?
With the Belifu SM9126, when using a four-lead cable, at least one white wire (positive) and one blue wire (negative) must be used together. The difference is that the four-lead set includes both white and blue wires for dual polarity, while the two white sets likely represent standard two-lead cables with only positive leads.
This answer is automatically generated
How to use the main mode 3 to strengthen muscles
