DFG-50
GAS CONVECTION OVEN

REPLACEMENT PARTS LIST

EFFECTIVE OCTOBER 16, 2007
THE BLODGETT CORPORATION
44 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: (802) 860-3700 (800) 331-5842 Fax: (802) 860-3732
www.blodgett.com
Superseding All Previous Parts Lists.
www.blodgett.com
The Company reserves the right to make substitution in the event that items specified are not available.
ERRORS: Descriptive and/or typographic errors are subject to correction.
