Merlin@home™ Transmitter
Model EX1150
Quick Start Guide
Set up the transmitter
Note. The transmitter is designed for use with direct analog telephone lines. It
may be damaged by any other type of phone line. The transmitter might work with
VOIP and cable services. For Technical Support in North America, call 1-877-MY-
MERLIN (1-877-696-3754) Monday through Friday 8AM to 8PM Eastern Stand-
ard Time
1
Place the transmitter on your nightstand or a table close
to your bed. The transmitter should be no more than
10 feet from your bed.
2
If you have an empty wall jack, remove the
transmitter cord from the phone connector
and plug the transmitter cord into the wall
jack. Go to Step 5.
If you do not have an empty wall jack,
remove your phone cord from the wall jack.
3
Plug the phone connector into the wall jack.
Advertisement
Table of Contents
Related Manuals for St. Jude Medical merlin@home EX1150
Summary of Contents for St. Jude Medical merlin@home EX1150
- Page 1 Merlin@home™ Transmitter Model EX1150 Quick Start Guide Set up the transmitter Note. The transmitter is designed for use with direct analog telephone lines. It may be damaged by any other type of phone line. The transmitter might work with VOIP and cable services. For Technical Support in North America, call 1-877-MY- MERLIN (1-877-696-3754) Monday through Friday 8AM to 8PM Eastern Stand- ard Time Place the transmitter on your nightstand or a table close...
- Page 2 • If you have set up the transmitter before, go to Step 12. Make sure you are within 1 foot of the transmitter. Make sure no one else with a St. Jude Medical implant is nearby. Face the transmitter and press the Start button quickly. The transmitter beeps.
- Page 3 The Read icon lights up when the transmitter reads your implant. The Tower icon lights up when the transmitter contacts your clinic. This process can take up to 15 minutes. Do not use your phone during this process. The Stars icon lights up when your set up is fi...
- Page 4 How to Send Your Information Manually Your information is sent automatically while you sleep. Send your information man- ually only if your clinician instructs you to do so. 1. Press the Start button once. The Stars icon lights up. 2. Remain in front of the transmitter. 3.
- Page 5 Call your clinic 1. Press the Start button to stop the fl ashing lights and beeping sounds. 2. Call your clinic for more instructions. Call Technical Support 1. If all fi ve progress lights are lit, call Technical Support. For additional information, see the March 2014 accompanying manual.
Need help?
Do you have a question about the merlin@home EX1150 and is the answer not in the manual?
Questions and answers
My husband's transmitter was unplugged briefly. I have reconnected both phone line and electrical connection several times. Three yellow lights flash, but it goes no further and never turns green.
Why are the yellow lights blinking
@Dorothy Brown
All 5 yellow lights are blinking
