- Page 1 DSP2-200 Installation Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction Amplifier Specifications DSP Presets Quick Setup Guide Trouble Shooting Technical Assistance Warranty Return Process... -
Page 3: Introduction
DSP2-200 AMPLIFIER INSTALLATION USER MANUAL Introduction Thank you for purchasing the DSP Series amplifier. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ products are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 4: Amplifier Specifications
DSP2-200 AMPLIFIER INSTALLATION USER MANUAL Specifications MODEL DSP2-200 PART AMPD02X2000 # of Channels 2 Powered Out (L/R) Analog Input 1 x RCA Unbalanced Analog output 1 x RCA Unbalanced Digital Input 1 x Optical Digital Output 1 x Optical 8 1/ 2 x 15 1/ 5 x 2 1/ 5 ” (216 x 386 x 55mm) (With Feet) Dimensions 8 1/ 2 x 15 1/ 5 x 1 3/ 4 ”... -
Page 5: Dsp Presets
DSP2-200 AMPLIFIER INSTALLATION USER MANUAL Amplifier Presets DSP Settings To adjust the DSP settings for this amplifier, there is a rotary dial on the rear. Rotating this dial with automatically set the DSP curve, as outlined within the amplifier preset insert located inside of the carton. -
Page 6: Quick Setup Guide
Quick Setup Guide About The DSP2-200 provides uncolored, clean amplification to loudspeakers rated from 4-ohms and up. It contains preset DSP curves for Origin Acoustics products and is ready for installation into a rack or inside a cabinet. Placement We recommend at least ten inches of clearance on both the left and right sides of the amplifier. - Page 7 DSP2-200 AMPLIFIER INSTALLATION USER MANUAL Stereo Phoenix Sub Out Connector 100-120V~60Hz/220-240V~50Hz 400W SPEAKER SUB OUT BRIDGED IN(L) EQ PRESET AUTO ON OPTICAL OPTICAL +12V UPDATE TRIGGER IN FUSE T6.3AL/250 V DSP Selection Optical I/O Line Level I/O Removable Feet Input Indicator...
-
Page 8: Troubleshooting
DSP2-200 AMPLIFIER INSTALLATION USER MANUAL Troubleshooting If you have a problem, try isolating it first. For example, if you’re playing a DVD and there is no sound, try replacing the DVD with an MP3 player to see if you get sound. -
Page 9: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 10: Warranty
If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 11: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 12 DSP2-200 AMPLIFIER INSTALLATION USER MANUAL IMPORTANT SAFETY INSTRUCTIONS • Read these instructions • Keep these instructions • Heed all warnings • Follow all instructions • Do not use apparatus near water • Clean only with dry cloth • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions...
- Page 13 DSP2-200 AMPLIFIER INSTALLATION USER MANUAL • Unplug this apparatus during lightning storms or when unused for period of times. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus had been damaged, liquid had been damaged in any way,...
- Page 14 6975 S Decatur Blvd, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2019 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
