- Page 1 ITKB-14-01-12-20-EN Quick Start Indicator • PUE 5...
- Page 2 To view the full user manual, go to the website or scan the QR code: radwag.com/en/manuals/W4C...
- Page 3 1. CONTENT PUE 5.15 Indicator ×1 PUE 5.19 Indicator ×1 2. NOTES AND WARNINGS Operate the indicator in a room free from dust where the temperature ranges +104 0–40 °C (32–104 °F) and where the relative humidity is below 80%. Potential temperature change shall occur gradually and slowly.
- Page 4 3. PREPARING FOR WORK Place the indicator on the workstation and leave it until it reaches ambient temperature. 3.1. Indicator Temperature Stabilization 1- 8 h Prior to switching the device on let it Connect the indicator to reach room temperature (estimated the mains.
- Page 5 4. HOME SCREEN 4.1. Home Screen The PUE5 indicator operates in Windows environment. RADWAG applications are installed individually on customer’s order. One of the basic applications is MwManager. 192.192.0.00 MwManager MWMH - Mass Display manager TERMINAL Proxy Manager 10:10 01.01.2020 MwManager home screen.
- Page 6 5. CONNECTING PERIPHERALS ON OFF 100-240V AC RS 232 50/60Hz 0,2A RS 485 Inputs Ethernet Load Cell Load Cell Inputs Inputs RS 232 Load Cell Load Cell ON/OFF switch Power cord cable gland 4IN connector (option) RS232, RS485 or 2XPROFIBUS (IN, OUT) connector USB M12 4 pin connector RJ45 Ethernet connector USB panel connector...
- Page 7 6. CLEANING AND MAINTENANCE 6.1. Notes and Warnings Prior to cleaning it is necessary For cleaning use only soft cloths made Apply the cleanser onto the cloth first. to disconnect the indicator from of microfiber. Do not use any abrasive the mains.
- Page 8 www.radwag.com...
