USB VideoBus II
™
User Guide
F5U208
P73476

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F5U208 and is the answer not in the manual?

Questions and answers

Related Manuals for Belkin F5U208

Summary of Contents for Belkin F5U208

  • Page 1 USB VideoBus II ™ User Guide F5U208 P73476...
  • Page 2 PC-compatible digital video image and audio format. The Belkin Components VideoBus II is the ideal device to bring video and still images into your computer from various standard video sources via the USB port. The VideoBus II enables unparalleled throughput of up to 30 frames per second for CIF size color images by using Belkin’s advanced...
  • Page 3 Introduction (continued) camcorder or any other video source to the VideoBus II yellow RCA input jack and left and right audio jacks. Now you are ready to begin capturing live video or creating amazing images! Features • Make your own movies using Windows or most any video imaging application.

  • Page 4: Specifications

    Specifications • Full-motion video–30 fps at CIF resolution video capture via USB. • Motion video up to 15 fps at VGA resolution (progressive video source) video capture via USB. • VGA (640 X 80) resolution still-image capture. • Audio input up to Stereo 16KHz/ 16-bit audio capture via USB.

  • Page 5: Getting Started

    Getting Started Please read this manual thoroughly before starting the installation of the VideoBus II. The recommended sequence for setting up the VideoBus II and the software is as follows: Install the MGI software packages. Install the VideoBus II hardware. Connect the VideoBus II to your camcorder, VCR, etc.

  • Page 6: Hardware Installation

    F5U208 VideoBus II Hardware Installation Instructions for Windows ® Plug the USB VideoBus II into a free USB port on the computer or a hub.
  • Page 7 After Windows has found the video driver, you will get a prompt that Windows has finished installing the new hardware device: "Belkin USB Video Cable". Click “Finish”. Steps 3 and 4 will be repeated to install the video driver. Hardware Installation...
  • Page 8 (continued) F5U208 VideoBus II Hardware Installation Instructions for Windows ® Connect the Belkin USB VideoBus II into an available USB port on the computer. Windows will detect a "USB Composite Device". Click “Next”. On the next screen that appears, select "Search for the best driver for your device (Recommended)"...
  • Page 9 Capture as "Unknown Device". Click “Next”. Hardware Installation (continued) Select "Search for the best driver for your device (Recommended)" and click “Next”. Insert the Belkin VideoBus II Driver CD into the CD-ROM drive. Check the "CD-ROM drive" and click “Next”. Windows...
  • Page 10 Hardware Installation (continued) 10. Windows will find the drivers for the "Belkin USB VideoBus II, Audio". Click “Next”. 11. Windows will copy the necessary files. At this time, Windows may ask for the Windows 98 SE CD. If asked, insert the Windows 98 SE CD into the CD-ROM drive and follow the directions on the screen.
  • Page 11 Hardware Installation (continued) 15. Make sure the Belkin VideoBus II Driver CD is inserted in the CD-ROM drive. Check the "CD-ROM drive" and click “Next”. 16. Windows will find the drivers for the "Belkin USB VideoBus II, Video". Click “Next”.
  • Page 12 F5U208 VideoBus II Hardware Installation Instructions for Windows 98 Second Edition ® Connect the Belkin USB VideoBus II into an available USB port on the computer. Windows will detect a "USB Composite Device". Click “Next”. On the next screen that appears, select "Search for the best driver for your device (Recommended)"...
  • Page 13 Capture as "Composite USB Device". Click “Next”. Hardware Installation (continued) Select "Search for the best driver for your device (Recommended)" and click “Next”. Insert the Belkin VideoBus II Driver CD into the CD-ROM drive. Check the "CD-ROM drive" and click “Next”. Windows 98 SE...
  • Page 14 Hardware Installation (continued) 10. Windows will find the drivers for the "Belkin USB VideoBus II, Audio". Click “Next”. 11. Windows will copy the necessary files. At this time, Windows may ask for the Windows 98 SE CD. If asked, insert the Windows 98 SE CD into the CD-ROM drive and follow the directions on the screen.
  • Page 15 Hardware Installation (continued) (continued) 15. Insert the Belkin VideoBus II Driver CD into the CD-ROM 17. After the files are copied, the installation of the VideoBus II drive. Check the "CD-ROM drive" and click “Next”. Video Capture driver is finished. Click “Finish”.
  • Page 16 F5U208 VideoBus II Hardware Installation Instructions for Windows 2000 ® Connect the Belkin USB VideoBus II into an available USB port on the computer. Windows will detect a "USB Composite Device" and automatically install the necessary drivers. The “Found New Hardware Wizard” screen will appear.
  • Page 17 A "Digital Signature Not Found" dialog will appear. Click “Yes”. Hardware Installation (continued) After the files are copied, the installation of the Belkin VideoBus II Audio Capture drivers is finished. Click “Finish”. IMPORTANT!!! Windows will ask if you want to restart the computer.
  • Page 18 11. Select "Search for a suitable driver for my device (recommended)" and click “Next”. Hardware Installation (continued) 12. Insert the Belkin VideoBus II Driver CD into the CD-ROM Drive. Check the "CD-ROM drive" and click “Next”. 13. Windows will find the drivers for the Composite USB Device. Click “Next”.
  • Page 19 Hardware Installation 14. A "Digital Signature Not Found" dialog will pop up. Click “Yes”. 15. After the files are copied, the installation of the Belkin VideoBus II Video Capture drivers is finished. Click “Finish”. 16. Restart the computer. 17. Installation of the Belkin USB VideoBus II is now complete.
  • Page 20 Recommendations Enhancing Capture Performance It is recommended that you perform the following steps to enable the DMA transfer on your PC. Enabling this feature lets the VideoBus II write data directly to the hard drive by bypassing the microprocessor. In most cases, this will improve the quality of the capture performance and provide for smooth, clear video captures.

  • Page 21: Troubleshooting

    If only VIDEO is selected, then only video will be captured. No Audio The Device settings may not be correct. Select the "Belkin VideoBus II, Audio" as the recording audio device. This is done in the recording menu of most video editing software.

  • Page 22: Fcc Statement

    Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
  • Page 23 Unit 13 • Gatelodge Close • Round Spinney Northampton • Northants • NN3 8RX • United Kingdom Belkin Components B.V. Hoofddorp • The Netherlands © 2000 Belkin Components. All rights reserved. All trade names are registered trademarks of belkin.com Belkin Components 501 West Walnut Street Tel: 310.898.1100...
