Summary of Contents for Fortis T3
- Page 1 T3 ULTRA SLIM FOLDABLE 2-IN-1 WALKING & RUNNING SMART TREADMILL FST3RUNPADA...
-
Page 3: Safety And Warnings
SAFETY & WARNINGS Note: Ensure you have read and fully understand the instructions for this device. Failure to do so could cause, damage or serious harm. • When you start training with this product, please consider your physical condition, train properly and regularly to ensure that you have enough physical strength to train. - Page 4 Important Notes • Place the treadmill in a place where the plug can be plugged into the socket. • Plug the device into a socket and ensure it is not loose. • Ensure the socket has been installed professionally. • If the plug and socket are not compatible, please do not change the plug by yourself.
- Page 5 COMPONENTS Treadmill Remote controller Silicone oil (x2) Installation tool Security lock...
- Page 6 OVERVIEW...
- Page 8 Name Name Linking Slider Connecting Tube Left Column Right Column Main Frame Digital Watch Holder Left Foot Combination Right Foot Combination Left Linkage Combination Right Linkage Combination Frame Folding Support Frame Left Handrail Fixing Motor Base Aluminium Parts Right Handrail Fixing Aluminium Left Aluminium Frame Parts Right Aluminium Frame...
- Page 9 Switch AC Branch Cable AC Connecting Wire (Black) AC Connecting Wire(Red) Grounding Wire Safety Lock Lower Communication Line 1, Digital Watch Core 200mm Lower Communication Line 2, Upper Communication Line 200mm 500mm Safety Lock Line 150mm Speed Switch Line 200mm Adapter Plate Remote Control Controller...
- Page 10 Mat Φ8-16*T1.5 Oil Cap Spring Pad Φ8-14*T2.0 Corrugated Pad Cross Screw M4*10 With Spring Locknut M6 Pad And Mat Locknut M8 Half-Round Screw M6*10 Half-Round Screw M6*20 Half-Round Screw M8*20 Half-Round Screw M8*45 Half-Round Screw M8*105 Hexagon Socket Head Cap Screw Hexagon Socket Head Cap M8*30 Screw M8*30...
-
Page 11: Installation
INSTALLATION The main structure of the treadmill you purchased has already been assembled in the factory. It can simply be used when plugged in. The following operations are how to use handrails and how to fold and unfold them. Lift the treadmill out of the box and place it on a level surface (Make sure there is a 50cm open space before and after the treadmill to fold and place the power cord. - Page 12 Folding the Treadmill Vertical First put the column folded on the running platform, then grab the tail of the running platform with both hands and lift it up. (Note: Unplug the power cord when folding) The treadmill is laid flat: Grab the tail of the treadmill with both hands, gently put it on the ground and follow the installation steps.
-
Page 13: Operation
OPERATION Operating Instructions in Manual Normal Mode When using the treadmill, you must use a power socket with grounding wires for your safety. Place the treadmill horizontally on the ground. Tum on the power, turn on the power switch. The power switch indicator lights up and the buzzer will sound once. - Page 14 Bluetooth Speaker Connection: Connection method Check your Mobile phone connection network - Wi-Fi, 3G or 4G. Turn on your mobile phones Bluetooth and search for the Treadmill Bluetooth connection (Bluetooth Name: ZLJ). After Bluetooth is connected, you will hear “Bluetooth connected successfully”. You can now enjoy the Bluetooth speaker.
- Page 15 Remote Button Function 1. “□”is start/stop button: This button can be used to stop the treadmill from running state and reset to zero during exercise. Use this button also as the start button when the power is on and the safety lock in its position. 2.
- Page 16 APP Guide Operation Download YPOO treadmill APP: Please enter YPOO in Apple APP Store or Google Play. Then you can download the treadmill app freely. Create your Account: Enter necessary information to create your sport account. Select Training Plan: Select training plan and create customised plan on the app, then you can control your treadmill from your smart phone remotely and do your customised exercise! Note:...
- Page 17 Numerical display range: Setting Start Default Setting range Display Range parameters Time (min : sec) 0:00 0:00-99:59 Incline (%) Speed (km/h) 1.0-12.0 1.0-12.0 Distance (km) 0:00 0.00-99.90 Heart rate (/MIN) Calorie(Kcal) 0.0-999.0 Treadmill Shut down instructions: The treadmill can be turned off at any time by turning off the power switch so that it does not damage the treadmill.
-
Page 18: Cleaning And Care
CLEANING & CARE Once the treadmill has been run on for 50km cumulatively (about 3 months), maintenance is needed. Put the lubricating oil (about one third each time) squeezed into the silicone oil valve and then the running belt will be automatically maintained. Tips: Do not use sandpaper or solvents to clean the treadmill. - Page 19 How to adjust the running belt? Insert the 6mm inner hexagonal wrench into the adjusting screw on the left side of the running belt and rotate the wrench clockwise for 1:4 turns to adjust the rear roller to tighten the running belt. Repeat step 1 to adjust the right screw.
-
Page 20: Specification
SPECIFICATION Colour Black Net weight 44kgs Running belt 45 x 126cm Product size 153 x 76 x 20cm Peak horsepower Peak 2.0hp Walking mode 1.0-6km/h Running mode 1.0-12km/h Bluetooth speaker Shock absorption Max user weight 220lbs Standing size 1530 x 760 x 1100mm Fold size 1530 x 760 x 200mm... - Page 21 NOTES...
- Page 24 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com...
