- Page 1 FGR-115RE LONG RANGE ETHERNET BRIDGE Addendum to the FreeWave Manual v 2.04 FreeWave Technologies Inc. 1880 S Flatiron Ct./ Suite F Boulder CO 80301 303-444-3862 LAD0001AB Rev A...
-
Page 2: Table Of Contents
FreeWave Technologies Ethernet Addendum 900 MHz V204 Table of Contents: Description:............................1 Back Panel:............................1 Front Panel: ............................. 3 Setup: .............................. 4 Menu 0, Sub Menu F....................... 4 Menu 1 ............................. 4 Menu 3 (for point to point)..................... 4 Menu 3 (for point to multipoint) .................... 5 Menu 5 (for point to multipoint) .................... -
Page 3: Description
900 MHz V204 Description: This is an addendum to the manual for the FreeWave Modems (the "Main Manual"). It covers details applicable specifically to using FreeWave Ethernet modems to create an Ethernet Bridge. Please use this addendum in conjunction with the Main Manual. The Data Port in a FreeWave Ethernet Modem is a 10Base-T RJ45 connector, to be used as part of an Ethernet LAN (Local Area Network). -
Page 4: Back Panel
FreeWave Technologies Ethernet Addendum 900 MHz V204 Back Panel: DIAG : 3-pin, RS-232-like connector for diagnostics and to program the radio. Adapter cables, part number ASC0409DC, are available from FreeWave. NORMAL/CROSSOVER: Switches the RJ45 connector from normal wiring to crossover wiring to avoid the need for a crossover cable. -
Page 5: Front Panel
FreeWave Technologies Ethernet Addendum 900 MHz V204 Front Panel: The modem has 2 rows of LEDs. The bottom row of LEDs is described in the Main Manual. The top row has 7 LEDs that indicate the state of the Ethernet Interface. -
Page 6: Setup
FreeWave Technologies Ethernet Addendum 900 MHz V204 Setup: To program the modem, proceed as described in the Main Manual, with the following exceptions: • Capital U on the diagnostics port brings up the setup menu. • You must use the diagnostic port (there's no RS232 Data Port in this modem) •... -
Page 7: Menu 3 (For Point To Point)
FreeWave Technologies Ethernet Addendum 900 MHz V204 Menu 3 (for point to point) RADIO PARAMETERS (0) FreqKey (1) Max Packet Size 9 Recommended: "9" (for best throughput) (2) Min Packet Size 1 Recommended: "1" (for best throughput) (3) Xmit Rate …... -
Page 8: Installation
Upon power up, the ethernet interface’s MAC filtering table can become corrupted, and must be reset, or allowed to timeout. After power up, press the reset button on the back of the FreeWave ethernet, or allow 4.5 minutes to pass and the table time to reset. - Page 9 FreeWave Technologies Ethernet Addendum 900 MHz V204 A data buffer is getting full. This typically only occurs if the settings in the radio are incorrect. This also occurs when the radio link, or the LAN link are not present. Check the radio settings, the Radio Link, and the LAN link.
-
Page 10: Glossary Of Terms
Ethernet Addendum 900 MHz V204 Glossary of Terms: Ethernet Modem: The entire FreeWave modem, which includes a Radio Modem and an Ethernet Interface. Ethernet Bridge: A bridge between to Ethernet LANs, using an Ethernet modem at each end. Radio Modem: The radio portion of the Ethernet Modem. - Page 11 FreeWave Technologies Ethernet Addendum 900 MHz V204 Notes: 9 of 9 LAD0001AB Rev A...
