- Page 1 USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS Caution Operating Guide Components Operation Instruction Cleaning & Maintenance Troubleshooting Technical Information... -
Page 3: Caution
CAUTION IMPORTANT: You must unscrew the tank base and remove the plate-sized plastic piece prior to first use. 5. Unplug the unit before filling with water or cleaning. 6. Stop operating this unit immediately if it functions abnormally. Contact info@brizacomfort.com for further instruction. 7. -
Page 4: Components
COMPONENTS FRONT SIDE Handles Vent Tank Cover 62.5 cm Side Panel Control Panel Water Tank Screw Water Level Scale 31 cm... - Page 5 COMPONENTS CONTROL PANEL REMOTE CONTROL Power ON/OFF Swing power Wind Speed speed cool Cooling swin g Power ON/OFF Swing Wind Speed Cooling...
-
Page 6: Operation Instruction
OPERATING INSTRUCTION NOTE When the “Cool” mode is activated, the water will be pumped up to saturate the filters. Water flowing through the filters mixes with the incoming air in turn, lowering the temperature. The effectiveness depends on humidity and ambient temperature when the unit is in “Cool”... -
Page 7: Cleaning & Maintenance
CLEANING & MAINTENANCE IMPORTANT: Always unplug the fan before cleaning, disassembling or servicing. Cleaning the Unit Body Use a 10:1 water and vinegar mixture and a soft towel. Cleaning the Water Tank Remove the 4 screws from the bottom of the water tank and clean the tank base with a soft, non abrasive towel with the water and vinegar mix. - Page 8 CLEANING & MAINTENANCE Cleaning the Filters Once a week (recommended), open the rear tank cover and slide the side panels as shown in the illustration below. Open the tank cover from here Remove filters, soak in vinegar-water (1:4 ratio) for 10-15 minutes. Let dry and wipe with soft cloth.
- Page 9 CLEANING & MAINTENANCE When putting the unit back together make sure to line up the markings on the side panels before you rotate them back into place. To put the rear panel back on, first placeing the bottom of the panel in before locking the top into place.
-
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTION The remote control is not working. Remote control batteries have run out. Replace batteries. The unit is making a clicking noise. Loose pump parts or vents. Make sure all pump parts and vent horizontal slats are securely in place. The unit is making a gurgling noise. - Page 11 Drain the tank and clean the unit more frequently. For further questions regarding the set up of your Briza or for troubleshooting tips please visit our website www.brizacomfort.com. You will find an informative video along with help for frequently asked questions in the FAQ section.
-
Page 12: Technical Information
TECHNICAL INFORMATION Air Volume 700 m Area Coverage 12 m Power 80 W Input Electricity 120 V / 60 Hz Current 0.66 A Water Tank Capacity Water Continuous Usage 6 - 8 h Water evaporation Rate 0.5 - 0.75 L/h Noise <...
