- Page 1 GARAGE BENCH DXSTFB048 INSTRUCTION IMPORTANT: Please read this manual carefully before assembling this MANUAL garage bench and save it for reference...
- Page 3 TABLE OF CONTENTS TECHNICAL SPECIFICATIONS SAFETY GUIDELINES PARTS LIST ASSEMBLY WARRANTY SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions. Read all instructions and follow them with use of this product.
-
Page 4: Technical Specifications
DXSTFB048 TECHNICAL SPECIFICATIONS SEAT CAPACITY 1,000 lb (454 kg) *WHEN WEIGHT IS EVENLY DISTRIBUTED SHELF CAPACITY 1,500 lb (680 kg) *WHEN WEIGHT IS EVENLY DISTRIBUTED HEIGHT 19.75" (50.16 cm) WIDTH 49.6" (126 cm) DEPTH 15" (38.1 cm) WEIGHT 48 lb (21.77 kg) -
Page 5: General Safety
GENERAL SAFETY • Keep work area clean and dry. • Use correct/recommended tools for the job. • Never leave unattended tools plugged in or running. • Never force a part into place. • Wear appropriate safety apparel for the job you are doing. •... -
Page 6: Before You Begin
DXSTFB048 Qty. No. Description Qty. No. Description Cushion Seat Safety Strap With Weld Nut Pre-Bolted Upright Assembly Safety Strap Bolt Wire Deck Locking Shelf Pin Crossbeam 4 mm Hex Key 4 mm Hex Bit Bench Top Support Strap (Black) Locking Grid Clip... - Page 7 Tools Required for Bench Assembly: 4 mm Hex Key (included) OR 4 mm Hex Bit (included); Rubber Mallet (not included), Flat-Head Screwdriver (not included)
- Page 8 DXSTFB048 CROSSBEAM INSTRUCTIONS • Note: It is recommended for one person to hold the pre-assembled upright frames in place while a second person installs the crossbeams. • Note: Keep the bolt heads of the diagonal pieces of the uprights LOCKING on the outside of the assembly (*see first image).
- Page 9 SAFETY STRAP AND SUPPORT STRAP INSTRUCTIONS • Note: There are two (2) safety straps with weld nuts and BENCH TOP three (3) recessed shelf support straps on the bottom set SUPPORT STRAPS (BLACK) of crossbeams. SAFETY STRAP WITH WELD NUT •...
- Page 10 DXSTFH048 WIRE GRID AND LOCKING SHELF PIN INSTRUCTIONS • Note: The wire grid consists of two sides – a “short” side and “long” side. If you plan on sliding objects on and off of the shelf from the front of the bench, then we recommend having the “short”...
-
Page 11: Two Year Limited Warranty
CUSHION SEAT INSTRUCTIONS • Note: Place onto the frame as evenly as possible to ensure the cushion seats properly. STEP 1 • Place cushion seat onto the assembled bench frame. The corner brackets of the cushion seat slide over the outer edges of the upright frame.
