Summary of Contents for Smeva SC C3
- Page 1 User and maintenance manual Refrigerated service cabinet Smeva BV Address: J.F. Kennedylaan 27 5555 XC Valkenswaard Telephone: 040-2073200 Internet: www.smeva.nl Production date: June 2011 Specifications of the manual: Date: August 2011 Version: 1.0...
-
Page 2: Technical Data And Copyright
Controlling for temperature regulation. Copyright This manual is published by Smeva BV Valkenswaard, the Netherlands. No reproduction (including translation) is permitted in whole or in part e.g. photocopy, microfilming or storage on digital data processing equipment, with the express written consent of the publisher. -
Page 3: Table Of Contents
v.1.0 Refrigerated service cabinet Contents TECHNICAL DATA AND COPYRIGHT ....................... 2 SAFETY .................................. 4 APPLIANCE SPECIFICATIONS ........................... 6 1 INTRODUCTION ..............................9 2 INSTALLATION ..............................10 3 PUTTING INTO OPERATION ......................... 13 4 THERMOSTAT CONTROL ..........................15 5 CLEANING ................................ 17 6 GENERAL MAINTENANCE .......................... -
Page 4: Safety
v.1.0 Refrigerated service cabinet Safety This user and maintenance manual contains the basic guidelines that must be observed when using and operating this product. The user must therefore read and understand the manual completely before operating the product. The general safety instructions, as well as the specific safety instructions, labelled with a hazard symbol below, must be observed. - Page 5 v.1.0 Refrigerated service cabinet Safety during transport Loading and unloading must be carried out with suitable equipment such as a lift truck, • forklift, crane etc. Use suitable equipment for this purpose. People carrying out these activities should wear personal safety equipment (gloves, •...
-
Page 6: Appliance Specifications
Appliance specifications Model type: SC C3 & SC C4 SC C3 Service Cabinet 3 compartments per door model - height 707 mm (excl. countertop) SC C4 Service Cabinet 4 compartments per door model - height 867 mm (excl. countertop) Independent appliance units: 1000, 1500, 2000, 2500 and 3000 mm... - Page 7 v.1.0 Refrigerated service cabinet Refrigeration device: The refrigeration device is fitted with evaporative coolers that have ventilators for cold air circulation. An expansion vent is fitted in the coolant supply line to the evaporative coolers in order to regulate the coolant supply to the evaporative coolers.This vent is fitted with a magnetic valve which closes as soon as the refrigerated service cabinet has reached the desired temperature.
- Page 8 v.1.0 Refrigerated service cabinet Electrical specifications...
-
Page 9: Introduction
Refrigerated service cabinet 1 Introduction You have made a good choice by purchasing a Smeva refrigerated service cabinet. The name Smeva stands for quality and reliability. The refrigerated service cabinet is modularly designed; several units can be connected to each other. -
Page 10: Installation
v.1.0 Refrigerated service cabinet 2 Installation Appliance installation The refrigerated service cabinet is delivered from the factory up to six metres wide. More appliance units can be attached to it on site. The refrigerated service cabinet should be placed on a level surface. Horizontal Level Adjustable feet... - Page 11 v.1.0 Refrigerated service cabinet Attaching appliances Remove the skirting boards on the outer ends (definitively). Dismantle the countertop if present. Dismantle the skirting boards and the transport girders on the coupling face. Place both appliance units next to each other. Equal height Level Insert M8 threaded ends through the feet.
- Page 12 v.1.0 Refrigerated service cabinet Refrigeration installation The refrigeration installation is realised by connecting the refrigerated service cabinet to a remote cooling unit. The field connections of the cooling piping set are situated centrally and their standard location is underneath the first independent appliance unit on the left. The cooling pipes to a potential sequence of sections are situated under the appliance and should be connected at the site of the division line.
-
Page 13: Putting Into Operation
v.1.0 Refrigerated service cabinet 3 Putting into operation The refrigerated service cabinet can be put into operation after installation by an authorised refrigeration contractor, see Chapter 2. For the proper functioning of the refrigerated service cabinet take the following instructions into account. External influences Avoid direct sunlight. - Page 14 The direction that the doors open is determined beforehand and delivered as such from the factory. If the direction of the door opening must be altered, contact your Smeva dealer. Door handles Always open the doors using the handles. Avoid touching the door rubber sealers.
-
Page 15: Thermostat Control
v.1.0 Refrigerated service cabinet 4 Thermostat control Accessible thermostat control Each independent appliance unit has its own control. This is located under the second door from the left behind the transport girder. The standard setting of the set point is 0 ˚C. Remove the left skirting board and the outer skirting board by loosening the screws. - Page 16 v.1.0 Refrigerated service cabinet For setting/changing the control, refer to the appropriate manual depending on control that was chosen following the delivery specifications. The appliance is standardly equipped with one control unit for each independent appliance unit. Defrost programme The evaporative coolers are occasionally defrosted using the ambient air with the ventilators in operation (natural defrosting).
-
Page 17: Cleaning
v.1.0 Refrigerated service cabinet 5 Cleaning Always turn off the appliance before cleaning the refrigerated service cabinet. Clean with a cloth and warm soapy water. Then dry the appliance. Never use aggressive cleaners. Only use cleaners with a pH (degree of acid) from 4 to 9. - Page 18 v.1.0 Refrigerated service cabinet Exterior of the appliance (laminated plate) A pre-laminated plate can be cleaned in the usual way with a cloth and warm soapy water. Aggressive cleansers can scratch the surface of the laminated plate. Exterior of the appliance (RVS AFP) RVS AFP can be cleaned with a mild cleansing agent and hot water.
- Page 19 Free of dirt Defrosted Do not use any water spray. Contact your Smeva dealer if the air circuit of the evaporative cooler is dirty internally. Drain Clean the drain with a cloth and warm soapy water. Flush out with plenty of...
-
Page 20: General Maintenance
• system; cleaning and inspection of the drainage system. • Consult with your Smeva dealer about these maintenance schemes. Magnetic rubber door sealers The magnetic rubber sealers should be replaced when damaged or excessively worn out: Remove the screws behind the magnetic rubber sealers. -
Page 21: Termination Of Use; Disassembly And Removal
v.1.0 Refrigerated service cabinet 7 Termination of use; disassembly and removal The design and choice of material used for the construction of the refrigerated service cabinet have a life expectancy of 15 years. The life expectancy is dependent on the circumstances and intensity of its use. -
Page 22: Malfunctions
v.1.0 Refrigerated service cabinet 8 Malfunctions This list was drawn up for malfunctions with the assumption that the refrigerated service cabinet had functioned normally up to the moment that the malfunction occurred. General malfunction If nothing functions, check the power supply: Check the circuit breakers in the circuit breaker box and in particular the group of circuit breakers dedicated to the refrigerated service cabinet. -
Page 23: Technical Specifications
Technical specifications are displayed on the type plate, and are also available on the datasheet which is available by your Smeva dealer upon request. The electrical diagram and the manual for the thermostat control are located in the central...
