Steelcase Currency Single Pedestal Desk Manual page 3

®
Leveler adjusts 1/8" in ANY direction.
Remove two (2) or four (4) screws,
that hold the drawer front to the
drawer body.
Alignment is done simply by
loosening the screw and retightening
when alignment has been made.
DRAWER FRONT
DRAWER BODY
O 25mm
12mm
Currency Adjustments for Drawer Fronts,
Level Glides and Removal of Box File Drawers
Pull the box or file drawer out until it stops.
Press down on the lock catch on each
side of drawer and pull out on the drawer
as shown.
Adjust glides on bottom of unit
until unit is level.
Apply stickers on all visible cam joint faces to
cover the connector faces, after assembly.
Page 3 of 4
939500298 Rev D
