Sealey ak7061.v2 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instruction protection
manual
1. SAFETY
WARNING! Ensure health & safety, local authority, & general workshop practice regulations are adhered to when using this
‰
staple/nail gun.
maintain the staple/nail gun in good condition, (use an authorised service agent).
9
Use this product in an adequate working area for its function, keep area clean, tidy and free from unrelated materials. Ensure there is adequate
9
lighting.
WARNING! Always wear approved eye or face protection when operating the staple/nail gun.
‰
Remove ill fitting clothing, ties, watches, rings, other loose jewellery, and tie back long hair.
9
Wear appropriate protective clothing.
9
maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT force this product to achieve a task it was not designed to perform.
8
DO NOT operate if any parts are damaged or missing. This may cause failure or possible injury.
8
DO NOT get the Stapler/Nailer wet or use in damp or wet locations.
8
DO NOT point at other persons or animals.
8
DO NOT operate if you are tired, under the influence of alcohol, drugs or intoxicating medication.
8
When not in use store in a safe, dry, child proof area.
9
2. INTRODUCTION
3-in-1 Staple and nail gun. Fitted with adjustable power control and staple remover. Features removable sole plate for easy clearance of
blockages. Supplied with starter pack of nails and staples. Suitable for a wide range of applications. Supplied in storage case.
3. SPECIFICATION
model no .............................................................. AK7061.V2
Crown size .................................................................. 9.5mm
Application/Fixing sizes:
Staple size:
Staples:4, 6, 8, 10, 12, 14mm
Hoop staples .................................................... 10, 12, 14mm
Nails ................................................................. 10, 12, 14mm
Consumables:
Staple 6mm pack of 500 ........................................ AK7061/8
Staple 8mm pack of 500mm ................................... AK7061/9
Staple 10mm pack of 500....................................... AK7061/2
Staple 12mm pack of 500....................................... AK7061/3
Nail 10mm 18SWG pack of 500 ............................. AK7061/1
Nail 12mm 18SWG pack of 500 ............................. AK7061/5
Nail 14mm 18SWG pack of 500 ............................. AK7061/7
Hoop 12mm pack of 500 ........................................ AK7061/6
© Jack Sealey Limited
HEAVY-DUTY STAPLE & NAIL GUN 4 - 14MM
Ak7061.V2
mODEL NO:
Original Language Version
AK7061.V2 | Issue:2 (H,F) 16/05/19
