Derby 9

Item ref: 151.605UK

User Manual

LED Light Effect

Please read through this manual thoroughly before use, any damage

Caused by misuse of product will not be covered by warranty.

Thank you for choosing the Derby 9, a classic multi-colour derby effect with multiple beams twisting in formation. Nine

different coloured 3 Watt LEDs deliver vivid coloured patterns, split through precision optics for wide area coverage.

Control via DMX512 or infra-red remote control for auto program or sound activation offers versatile operation modes for

mobile discos, stage shows may form part of a larger lighting installation.

In the box:

Your Derby 9 should arrive with you in a single carton in good condition. The carton should contain

1 x main unit with bracket, 1x remote control, 1 x UK IEC mains lead and 1 x manual.

Warning:

To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event of a spillage,

disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then check the unit before

continuing use.

Please do not open cover, contains high voltage. This

product is not serviceable or repairable by the end user.

Please refer to qualified personnel for service and repair.

www.avsl.com

151.605UK User Manual

Need help?

Do you have a question about the Derby 9 and is the answer not in the manual?

Page 1 Caused by misuse of product will not be covered by warranty. Thank you for choosing the Derby 9, a classic multi-colour derby effect with multiple beams twisting in formation. Nine different coloured 3 Watt LEDs deliver vivid coloured patterns, split through precision optics for wide area coverage.
Page 2 Placement: • Use the included mounting bracket to fix to a stand or lighting truss • Use secondary safety fixings if mounting overhead • Keep away from damp or dusty environments • Ensure adequate air-flow around the fixture housings • Ensure adequate access to controls and connections Cleaning: •...
Page 3 Remote control: The Derby 9 is supplied with an I.R. remote control for quick access to most of the basic functions of the unit. This must be aimed at the front of the unit where there is a remote receiver and has a maximum range of approximately 4m.
Page 4 70-99 A3 - green/purple/UV - ON/motor speed from slow to fast 100-129 A4 - 9 colour jump change/motor speed from slow to fast 130-159 A5 - 3 colour jump change/motor speed from slow to fast Choose program 160-189 Gradual change 1/motor speed from slow to fast/with no strobe effects 190-219 Gradual change 2/motor speed from slow to...
