Super Elite
Watch cleaning machine
Elma Order Nos
Super-Elite 230V
Super-Elite 115V
Manual watch cleaning machine for cleaning and drying
A low-price alternative for the cleaning of disassembled watch works. Charging of the 3 cleaning chambers by
hand; drying chamber for the spotless drying of the cleaning items.
Product features
• Motor with sliding shaft
• Adjustable rotational speed
• Timer
• Heating for drying chamber, seperatly switchable
Technical Data
Outer dimensions of unit ø/h (mm / inch)
Weight (kg / lbs)
Timer (min.)
Heating (W)
Motor (W)
301 000 0000
301 000 2000
Standard accessories
• 3 jars with lid
• screen basket:
- 1 basket frame
- 1 basket lid
- 2 insert 5 div. (h= 15mm)
- 1 insert 1 div. (h=15mm)
- 1 Miniature basket with lid
330 / 500 / 13 x 19 7/10
8.7 / 19.2
0 - 15
200
8
Pictured Super-Elite
product profile
Advertisement
Table of Contents
Related Manuals for Elma Super Elite
Summary of Contents for Elma Super Elite
- Page 1 Super Elite Watch cleaning machine Elma Order Nos Super-Elite 230V 301 000 0000 Super-Elite 115V 301 000 2000 Pictured Super-Elite Manual watch cleaning machine for cleaning and drying A low-price alternative for the cleaning of disassembled watch works. Charging of the 3 cleaning chambers by hand;...
- Page 2 ENGLISH Operating Instructions Super Elite Watch Cleaning Machine...
-
Page 3: Table Of Contents
CE conformity ...............3 Designation of the elements .........4 Technical details ............4 Putting into Operations ..........4 Working with the Elma Super Elite ......5 Placing the watch parts to the cleaned ......5 Cleaning Procedure ............6 Upkeep of the Machine ..........7 Putting out of action and waste disposal .... -
Page 4: Important Safety Warnings
Do not put the unit under water! In case of damages on the Super Elite or the mains cable do not connect the unit to the mains! The unit must be opened by authorized and specialized... -
Page 5: Designation Of The Elements
Mains frequency (Hz) 50 / 60 Power consumption of motor (Watt) Power consumption of heating (Watt) Outer dimensions of unit D / H (mm) 330 / 500 Weight (Kg) Material of housing Steel sheet painted BA/Super-Elite/GB/0104 © Elma GmbH & Co KG... -
Page 6: Putting Into Operations
Filling the jars 5. Fill the glass jars (8) in the following order: Fill glass jars (8) to the left of the heating tube (3) with elma cleaning concentrate 1:9 till the first level mark. Dilute up to the end of the hammered mark with ordinary tap-water. -
Page 7: Cleaning Procedure
2. Bring the raised basket (10) into the glass jar (8) filled up with ELMA Solution i.e. at the left of the heating tube (3). Fix the bracket (6) by turning the knob (7) to the left and dip in the basket in the liquid. -
Page 8: Upkeep Of The Machine
From time to time the basket must, therefore, be cleared of these dirt particle deposit and fibres, which become red by the Elma Solution, be means of a brush and petrol. Grease All the sliding parts of the machine should be cleaned from time to time, and slightly greased (19) and (16).
