Sipura SPA-1001
Simplified Users Guide
Version 1.1a
A Step by Step Introduction
Written by Jason
from
JMG Technology
http://www.jmgtechnology.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPA-1001 and is the answer not in the manual?

Questions and answers

Related Manuals for Sipura SPA-1001

Summary of Contents for Sipura SPA-1001

  • Page 1 Sipura SPA-1001 Simplified Users Guide Version 1.1a A Step by Step Introduction Written by Jason from JMG Technology http://www.jmgtechnology.com.au...

  • Page 2: Section 1 - Getting Started

    Setting up the hardware: Step 1: Connect the power cable to your SPA-1001 Step 2: Connect the network cable from your SPA-1001 to your DHCP enabled modem/router Step 3: Connect an analogue phone to the “Phone” port in the SPA-1001.

  • Page 3: Section 2 - Configuring The Spa-1001 Via The Web Interface

    Section 2 – Configuring the SPA-1001 via the Web Interface Once you have the IP address of your SPA-1001 you can access the web interface by opening a web browser and typing the following in the Address : http:// <IP Address of SPA-1001>...

  • Page 4: Section 3 - Regional Settings

    Section 3 – Regional Settings Click on the “Regional” tab. The following changes are optional, however they will make your SPA-3000 sound more Australian. Under the Call Progress Tones Distinctive Ring Patterns headings change: Dial tone: 400@-19,425@-19,450@-19;10(*/0/1+2+3) Busy Tone: 425@-19;10(.375/.375/1) Reorder Tone: 425@-19, 425@-29;60(.375/.375/1,.375/.375/2) Ring Back Tone:...
  • Page 5 The following changes are required under the Miscellaneous heading : FXS Port Impedance: 220+820||115nF If you would like to configure the Time and Daylight savings, see Appendix D. This is completely optional.

  • Page 6: Section 4 - Line 1 Or Line 2 Settings

    Section 4 – Line 1 or Line 2 Settings Click on the “Line 1” or “Line 2” tab. The settings for Line 1 and Line 2 are identical, so for each provider you want to register follow the instructions below: The first thing that needs to be changed is under the Proxy and Registration heading.
  • Page 7 The next thing that needs to be altered is under the Audio Configuration heading. The following change is required. Preferred Codec: G729a The final item that requires changing is under the Dial Plan heading. The dial plan will vary from provider to provider. The dial plan show below is an example only, and may require alteration depending on which VoIP provider you subscribe to.

  • Page 8: Section 5 - Phone Settings

    Everything should now be setup and ready to use. Make sure you press the Submit All Changes button to save the settings to the SPA-1001. The Submit All Changes button will save the changes on all pages. You can however hit that...

  • Page 9: Appendix A - Dial Plans

    Dial plans can be very confusing at first glance. However they are invaluable feature of the SPA-1001 so you should at least learn the basics of how they work. The following dial plans are to show how to use the various features of dial plans. You should play around with them to suit your needs.

  • Page 10: Appendix B - Factory Reset

    Appendix B - Factory Reset To perform a factory reset on your SPA-1001 dial **** on the phone. You should hear a Sipura message asking you to enter your selection. . Then dial 73738#. WARNING: This will restore your unit back to factory defaults, all your information will be lost.

  • Page 11: Appendix C - Upgrading Firmware

    In the example below the SPA-1001 is located at 192.168.1.35. Click on the OK button to begin so the program can find your SPA-1001. When the program locates the SPA, it will interrogate it and you will be shown a confirmation screen.
  • Page 12 Click on the Upgrade button to begin the upgrade procedure. The upgrade itself should only take a minute or so. Whatever you do don't turn the power of during this operation. Once the procedure has finished, you should be presented with the following screen and your upgrade has been completed.

  • Page 13: Appendix D - Setting Up A Time Server And Daylight Saving Rules

    Appendix D – Setting up a Time Server and Daylight Saving Rules You can configure the SPA-3000 to automatically retrieve the current date and time. (Including daylight savings). To do this you will need to enter in a NTP server. Some providers will provide you with one.

  • Page 14: Appendix E - Sipura Ivr (Phone Menu)

    Appendix E – Sipura IVR (Phone Menu) The Interactive Voice Response (IVR) capabilities of the SPA are designed to give the administrator and/or user basic read/write capabilities such that the unit can attain basic IP network connectivity and the more advanced browser-based configuration menu may be accessed.
  • Page 15 IVR Action IVR Menu Parameters Notes Choice Check Firmware None IVR will announce the Version version of the firmware running on the SPA. Check Primary DNS None IVR will announce the Server Setting current setting in the Primary DNS field. Set Primary DNS Server Enter IP address Will require password if set.

  • Page 16: Appendix F - Sipbroker

    Appendix F – Sipbroker Sipbroker is a free service that allows you to dial between certain VoIP providers. To use sipbroker you will need to add the following entry to your dial plan. <**,:>[x*][x*].<:@sipbroker.com> Please see http://www.sipbroker.com to read all about the great service provided my sipbroker.
